Fig. 39: Removing Vibration Damper/Belt Pulley
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove engine bracket from cylinder block.

Fig. 40: Removing Engine Bracket From Cylinder Block
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Mark direction of rotation of toothed belt.

z

Screw tensioning bolt T10092 into toothed belt tensioning element.

NOTE:

When loosening the front engine mount bolt the engine must be raised
slightly with the support bracket.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 41: Screwing Tensioning Bolt T10092 Into Toothed Belt Tensioning Element
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Align pressure piston using pointed pliers or wire before tensioning (hole in pressure piston must align
with hole in housing).

z

Tension piston of tensioning element just enough that the piston can be locked with locking pin T40011.

z

Remove toothed belt.

z

Turn crankshaft back slightly.

Installing

A - Toothed belt completely removed

If toothed belt has only been removed from camshaft. See B - TOOTHED BELT ONLY TAKEN OFF
CAMSHAFT SPROCKET .

Conditions

z

The pistons must not be positioned at TDC

Work sequence

z

Bring mark on camshaft in line with the mark on cylinder head cover.

NOTE:

When turning the camshaft the crankshaft must not be at TDC (danger of
damage valves/piston crown).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 42: Aligning Mark On Camshaft With The Mark On Cylinder Head Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Place toothed belt on crankshaft sprocket (observe direction of rotation).

z

Install engine mount to cylinder block.

Tightening torque: 45 N.m

z

Install lower part of toothed belt guard. Insert securing bolts with locking fluid "D 000 600 A2".

Tightening torque: 10 N.m

z

Secure vibration damper/belt pulley with one bolt (note fixing arrangement).

z

Turn crankshaft to TDC No. 1 cylinder.

Fig. 43: Turning Crankshaft To TDC No. 1 Cylinder

NOTE:

Before installing engine mount, insert bolts into mount.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install toothed belt onto coolant pump, tensioning roller and camshaft sprocket.

z

Tighten toothed belt. See TENSIONING TOOTHED BELT .

B - Toothed belt only taken off camshaft sprocket

z

Bring mark on camshaft in line with the mark on cylinder head cover.

Fig. 44: Aligning Mark On Camshaft With The Mark On Cylinder Head Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Turn crankshaft to TDC No. 1 cylinder.

z

Install toothed belt onto camshaft sprocket.

z

Tighten toothed belt. See TENSIONING TOOTHED BELT

Tensioning toothed belt

z

Tension toothed belt by pulling out locking pin T40011 and removing tensioning bolt T10092.
