Remove bolts (arrows).

z

Loosen bolt (arrow -A-).

z

Remove vibration damper/belt pulley.

Fig. 74: Removing Vibration Damper/Belt Pulley
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove engine bracket from cylinder block.

Fig. 75: Removing Engine Bracket From Cylinder Block
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

z

Only remove engine mounting when the engine is secured with
the support bracket 10-222A.

z

The engine bracket must be only released when the engine
mounting is removed.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



z

Remove toothed belt guard center and lower parts.

z

Mark direction of rotation of toothed belt.

z

Release tensioner and take off toothed belt.

z

Turn crankshaft back slightly.

Installing

Requirements

z

Pistons must not be positioned at TDC.

Work sequence

z

Place toothed belt on crankshaft pulley and coolant pump (observe direction of rotation).

Adjusting valve timing

z

Bring mark on camshaft into line with mark on toothed belt guard.

Engine installed:

Fig. 76: Aligning Mark On Camshaft With Mark On Toothed Belt Guard
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Turn crankshaft to TDC No. 1 cylinder (vehicles with manual transmission).

NOTE:

When loosening the front engine mounting bolt the engine must be raised
slightly with the support bracket.

NOTE:

z

Engine removed:

Begin by installing lower section of toothed belt guard as well as belt
pulley/vibration damper.

NOTE:

When the camshaft is turned, the crankshaft must not be at TDC. Danger of
damage to valves or piston crowns.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 77: Locating Mark For Positioning TDC No. 1 Cylinder (Vehicles With Manual Transmission)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Turn crankshaft to TDC No. 1 cylinder (vehicles with automatic transmission).

Fig. 78: Locating Mark For Positioning TDC No. 1 Cylinder (Vehicles With Automatic
Transmission)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Engine removed:

z

Position vibration damper at TDC No. 1 cylinder (arrows).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 79: Positioning Vibration Damper At TDC No. 1 Cylinder
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Place toothed belt on tensioning roller and camshaft pulley.

Tensioning toothed belt

Requirements

z

Engine must only be hand touch warm.

z

Camshaft sprocket is at TDC No. 1 cylinder.

z

Before tensioning toothed belt, turn tensioning roller on eccentric with pin wrench T10020 five times
fully onto limit stops in both directions.

Work sequence

z

Tension toothed belt by turning eccentric to left (direction of arrow) with 2-hole pin wrench T10020 onto
limit stop.

Fig. 80: Tensioning Toothed (Timing) Belt
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Release tension on toothed belt until notch -1- and indicator -2- align (use mirror).

z

Tighten securing nut to 20 N.m.
