Fig. 5: Evaporative Emissions (EVAP) Canister Purge Regulator Valve Hoses - Engine Codes AEG,
AVH, AZG
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Engine code BDC

z

Pull fuel supply line -1- as well as fuel return line -2- off fuel rail and collect fuel that leaks out with a
clean cloth.

z

Pull hose off Evaporative Emissions (EVAP) canister purge regulator valve -N80-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 6: Locating Fuel Supply/Return Lines & EVAP Canister Purge Regulator Valve - Engine Code BDC
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Engine codes BEV, BGD

z

Pull fuel supply line -1- off union by pressing locking ring -2- into union -3- and collect fuel that leaks
out with a clean cloth.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 7: Locating Fuel Supply Line Locking Ring - Engine Codes BEV, BGD
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Continuation for all models

z

Seal lines to avoid contamination of fuel system.

z

Pull vacuum and breather hoses off engine.

z

Remove air cleaner with intake hose and Mass Air Flow (MAF) -G70-.

z

Remove intake manifold upper part. See INTAKE MANIFOLD UPPER PART, REMOVING AND
INSTALLING .

Vehicles with manual transmission

z

Disconnect shift mechanism from transmission.

See SELECTOR MECHANISM

z

Remove hydraulic clutch slave cylinder:

See CLUTCH SLAVE CYLINDER .

Vehicles with automatic transmission

z

Remove selector lever cable from transmission:

For transmission 01M, see SELECTOR LEVER CABLE

z

Remove selector lever cable from transmission.

NOTE:

Seal the intake ports in the intake manifold lower section with clean cloths.

NOTE:

The clutch pedal must not be operated.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



For transmission 09G, see SELECTOR MECHANISM

Continuation for all models

z

Remove insulation tray.

See NOISE INSULATION, ASSEMBLY OVERVIEW

z

Drain coolant. See COOLING SYSTEM, DRAINING AND FILLING .

z

Remove ribbed belt. See RIBBED BELT, REMOVING AND INSTALLING .

z

Remove supplementary coolant fan on right side of vehicle, if part of original equipment.

z

Remove power steering pressure line securing clamps on engine and transmission.

z

Remove power steering pump from bracket and tie up to front panel; hoses remain connected.

See POWER STEERING PUMP, RESERVOIR, HYDRAULIC LINES .

Vehicles with air conditioning

z

Remove air conditioning compressor:

See CONDENSER, REMOVING AND INSTALLING .

z

Observe additional information and removal work. See ADDITIONAL INFORMATION AND
ASSEMBLY WORK ON MODELS WITH AN AIR CONDITIONING SYSTEM .

Continuation for all models

z

Disconnect inter-connecting, coolant, vacuum and intake lines on engine.

z

Separate connections on following components:

Ignition coils -N- and -N128- with

Final output stage -N122- or Ignition coils with

Final output stage -N70-, -N127-, -N291-; -N292-

Camshaft Position (CMP) sensor -G40-

Injectors -N30-...-N33-, release cable guide

Engine Coolant Temperature (ECT) sensor -G62-

Engine speed (RPM) sensor -G28-

Knock Sensor (KS) 1 -G61-
