Volkswagen New Beetle. Manual - part 1141

Fig. 106: Applying Silicone Sealing Bead On Oil Pan (1 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Apply silicone sealing bead as shown to the clean sealing surface of the oil pan. (illustration shows
position of sealant bead on cylinder block).

z

Immediately install oil pan and lightly tighten all bolts.

the oil pan and may block the suction pipe strainer.

NOTE:

The oil pan must be aligned flush with the cylinder block.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 107: Applying Silicone Sealing Bead On Oil Pan (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tighten oil pan bolts to 15 N.m (11 ft lb).

z

Tighten oil pan/transmission bolts to 45 N.m (33 ft lb).

Oil pressure and oil pressure switch, checking

Special tools and equipment

z

VAG 1342 Oil pressure gauge

NOTE:

z

After installing the oil pan, allow the sealant to dry for approx. 30
minutes before adding engine oil.

z

Assembly is the reverse of the disassembly sequence.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

VAG 1527 B Voltage tester

z

VW 1594 adapter kit

Fig. 108: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Test sequence

z

Remove oil pressure switch -F1- and screw into tester.

NOTE:

Functional check and servicing the optical and acoustic oil pressure
warning:
See appropriate WIRING DIAGRAM article



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 109: Checking Oil Pressure Switch
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Screw tester into filter bracket in place of pressure switch.

z

Connect brown tester wire to Ground.

z

Connect VAG 1527B Voltage tester between battery Plus and oil pressure switch using jumper wires
from VW 1594 adapter kit.

If LED lights up:

z

Replace oil pressure switch -F1-.

If LED does not light up:

z

Start engine and slowly increase engine speed.
