Volkswagen New Beetle. Manual - part 1110

Fig. 140: Mounting Fitting Tool 3362 On Cylinder Head With Fitting Tool Securing Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Position fitting tool for compressing valve springs to one of following positions:

Outer intake valves: lower position

Center intake valve: upper position

Exhaust valve: lower position

z

Connect pressure hose to compressed air system supplying at least 6 bar and remove valve springs.

z

Pull off valve stem seals with 3364.

Fig. 141: Pulling Off Valve Stem Seals With 3364
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Place plastic sleeve -A- supplied on appropriate valve stem. This will prevent new valve stem seal being
damaged.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 142: Placing Plastic Sleeve -A- Supplied On Appropriate Valve Stem
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Place new valve stem seal in fitting tool 3365.

z

Oil sealing lip of valve stem seal -B- insert in installation tool 3365 and press carefully onto valve guide.

The rest of the assembly is basically a reverse of the disassembling sequence.

ENGINE - LUBRICATION

LUBRICATION SYSTEM COMPONENTS, REMOVING AND INSTALLING

Checking oil pressure and oil pressure switch. See OIL PRESSURE AND OIL PRESSURE SWITCH,
CHECKING .

Oil system capacity:

z

Without oil filter: 4.0 liters

z

With oil filter: 4.5 liters (4.8 qt.)

NOTE:

z

If large quantities of metal particles or other deposits (caused, for
example, by partial seizure of the crankshaft or connecting rod bearings)
are found in the engine oil when performing repairs, clean the oil passages
thoroughly and replace the oil cooler in order to prevent further damage
from occurring later.

z

The oil level must not be above the max. mark, or there is danger of
damage to the catalyst! Marking. See Markings On Oil Dipstick .

{

Thoroughly clean oil passages

{

Replace oil spray jets, oil cooler, and oil filter



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Oil Capacities up to MY 2000

Checking oil pressure. See OIL PRESSURE AND OIL PRESSURE SWITCH, CHECKING .

Engine oil specifications:

The following terms must appear on the oil container singly or in combination with other designations:

z

VW 502 00 or VW500 00 or VW501 01

z

ACEA A2 or ACEA A3

z

API-SJ or API-SL

z

Engine oils are graded according to their viscosity. The proper grade to be used in your engine depends
on existing climatic or seasonal conditions.

z

The engine oil which was first put into your engine has a viscosity grade of SAE 5W-40. You can use this
oil over all temperature ranges for normal driving. If engine oil viscosity grade SAE 5W-40 is not
available, you can also use SAE 5W-30.

Part I

Part II, disassembly oil filter bracket. See PART II .

1. 15 N.m

2. Sealing flange

z

Must be located on dowel sleeves

z

Clean sealing surface before installing

z

Insert with silicone sealant D 176 404 A2. See FRONT SEALING FLANGE, REMOVING
AND INSTALLING .

z

Replacing crankshaft oil seal (pulley end). See CRANKSHAFT OIL SEAL (BELT PULLEY
END), REPLACING .

z

Removing and installing. See FRONT SEALING FLANGE, REMOVING AND
INSTALLING .

3. Chain tensioner with tensioning rail, 15 N.m

z

Check for wear

z

When installing, pretension spring and install

4. Chain sprocket

z

For oil pump drive

z

Check for wear

5. Cylinder block

z

Removing and installing crankshaft. See CRANKSHAFT, REMOVING AND INSTALLING .

NOTE:

The following list refers to items in Fig. 143 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



z

Disassembling and assembling pistons and connecting rods. See PISTONS AND CONNECTING
RODS, DISASSEMBLING AND ASSEMBLING .

6. Dipstick

z

Oil level must not be above max. mark!

z

Markings. See Markings On Oil Dipstick .

7. Guide

z

For dipstick

z

Pull off to extract oil

8. Guide tube

9. Oil spray jet

z

For piston cooling

10. Pressure relieve valve, 27 N.m

z

Opening pressure: 1.3 to 1.6 bar

11. 15 N.m

12. Suction pipe

z

Clean strainer if soiled

13. O-ring

z

Replace

14. Baffle plate

15. 15 N.m

z

Loosen and tighten with T-bar and socket, 10 mm 3185

z

Remove with hexagon key extension, 5 mm 3249

16. Oil pan

z

Clean sealing surface before installing

z

Install with silicone sealant D 176 404 A2. See OIL PAN, REMOVING AND INSTALLING .

z

Removing and installing. See OIL PAN, REMOVING AND INSTALLING .

17. Oil drain plug, 30 N.m

z

Replace if leaking. See Parts Catalog for correct application. In some cases, seal and drain plug are
combined; do not interchange with separate seal and drain plug.

z

If sealing ring is leaking nip open and replace.

18. Seal

z

Replace

19. Oil return pipe

z

From turbocharger

20. 10 N.m

21. Oil pump

z

With positive pressure relief valve 12 bar

z

Before installing, check that both dowel sleeves for centering oil pump/cylinder head are installed



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)
