Install guide sleeve from 2080 A onto crankshaft journal.

Fig. 51: Installing Guide Sleeve From 2080 A Onto Crankshaft Journal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Slide oil seal over guide sleeve onto crankshaft stub.

z

Press in seal with press sleeve from 3265. To do this use old central bolt for crankshaft toothed belt
sprocket.

Fig. 52: Pressing In Seal With Press Sleeve From 3265
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press sleeve in onto stop.

z

Install crankshaft toothed belt sprocket and hold with counter-hold tool 3099.

be replaced with a PTFE oil seal, but not vice versa.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 53: Installing Crankshaft Toothed Belt Sprocket And Holding With Counter-Hold Tool 3099
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tighten new central bolt to 90 N.m + 1/4 turn (90°) further.

z

Install toothed belt and adjust valve timing. See INSTALLING .

z

Install ribbed belt and tensioning element. See RIBBED BELT TENSIONER, REMOVING AND
INSTALLING .

Front sealing flange, removing and installing

Special tools and equipment

z

3099 Counter-hold tool

z

2080 A Fitting sleeve

z

VAG 1331 Torque wrench (5-50 N.m)

z

VAG 1332 Torque wrench (40-200 N.m)

z

D 176 404 A2 Silicone sealant

z

Hand drill with plastic brush wheel

z

Flat scraper

z

Protective glasses

NOTE:

z

When bolting on, place two washers between toothed belt pulley and
counter-hold.

z

Thread and shoulder must be free of oil and grease.
