Volkswagen New Beetle. Manual - part 1088

z

3090 Connecting rod support

Fig. 27: Identifying 3090 Connecting Rod Support
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing ribbed belt

z

Mark direction of rotation of ribbed belt.

z

To loosen ribbed belt turn tensioning element in direction of arrow.

Fig. 28: Loosening Ribbed Belt By Turning Tensioning Element In Direction Of Arrow
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lock tensioning device with 3090 Connecting rod support.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 29: Identifying Lock Tensioning Device With 3090 Connecting Rod Support
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove or install ribbed belt.

z

Remove insulation tray.

See PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING

z

Remove or install ribbed belt.

z

Start engine and check belt running.

Ribbed belt routing

Belt drive without air conditioning compressor

NOTE:

When installing ribbed belts ensure the belt seats correctly in the belt
pulley.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 30: Identifying Belt Drive Without Air Conditioning Compressor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Belt drive with air conditioning compressor

Fig. 31: Identifying Belt Drive With Air Conditioning Compressor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Toothed belt, removing, installing and tensioning

Special tools, workshop equipment, test and measuring appliances and aux. items required

z

10-222A Engine support bracket with 10-222A/8 adapter

z

3180 Retainer (for turbocharged engines)

z

T10092 Tensioning bolt

NOTE:

Engines with an air conditioning compressor are equipped with a double ribbed
belt.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



z

T40011 Locking pin

z

VAG1331 Torque wrench (5 to 50 N.m)

z

V.A.G 1332 Torque wrench (40 to 200 N.m)

z

D 000 600A2 Locking fluid

Fig. 32: Identifying Special Tools
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Note safety precautions before starting work. See SAFETY PRECAUTIONS WHEN WORKING ON
FUEL SUPPLY

z

Observe rules for cleanliness. See RULES OF CLEANLINESS .

z

Remove engine cover.

z

Remove right-hand insulation tray.

See PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING

z

Remove air duct to charge air cooler at bottom right of long member.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)
