Fig. 146: Loosening Bolt On Oil Pump Chain Sprocket
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Relieve tension on chain rail using a screwdriver (arrow) and lock rail using a 3 mm Allen key -1-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 147: Relieving Tension On Chain Rail
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove oil pump chain sprocket and take chain off balancer shaft gear assembly.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 148: Removing Chain From Balancer Shaft Gear Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Loosen securing bolts on balancer shaft gear assembly (starting at outer sides and working inward) and
remove them. Disassembling and assembling oil pump with balancer shaft gear assembly. See Oil pump
with balancer shaft gear assembly, disassembling and assembling (Engine codes BDC, BGD) .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 149: Loosening Securing Bolts On Oil Pump Balancer Shaft Gear Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing and adjusting oil pump with balancer shaft gear assembly

Requirements

z

Chain tensioner pre-tensioned. See PRE-TENSIONING CHAIN TENSIONER

z

Install oil pump with balancer shaft gear assembly. Tighten securing bolts (starting on inside and working
outward) to 15 N.m + 1/4 turn (90°) further.

Fig. 150: Locating Oil Pump With Balancer Shaft Gear Assembly Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Set crankshaft to TDC No. 1 cylinder.

NOTE:

Observe different lengths of bolts. See Fig. 137 .
