Cylinder head, removing and installing

Special tools and equipment

z

10-222A Engine support bridge

z

10-222 A/8 Adaptor

z

3035 Injector line wrench

z

3070 Guide pins & handle-1112 mm

z

T 10014 Engine support

z

VAG 1306 Drip tray for VAG 1202A

Fig. 70: Identifying Special Tools And Equipment (1 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VAG 1331 Torque wrench: 5 to 50 N.m (3.7 to 37 ft lb)

z

VAG 1332 Torque wrench: 40 to 200 N.m(30to148ftlb)

z

VAG 1921 Hose clip pliers



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 71: Identifying Special Tools And Equipment (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirements

z

Engine must NOT be more than warm to the touch.

z

Pistons must NOT be positioned at TDC.

Removing

z

With ignition switched OFF, disconnect battery Ground strap.

z

Remove engine cover.

z

Remove Air Cleaner.

z

Remove connecting pipe between Charge Air cooler and intake manifold/EGR Vacuum Regulator
Solenoid valve.

z

Remove sound dampening tray:

See NOISE INSULATION, ASSEMBLY OVERVIEW

z

Drain engine coolant. See COOLING SYSTEM, DRAINING AND FILLING

z

Disconnect fuel supply and return lines at fuel filter.

CAUTION: Obtain radio anti-theft code from customer before disconnecting battery

ground strap.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 72: Disconnecting Fuel Supply And Return Lines
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Seal lines so fuel system is not contaminated by dirt etc.

z

Remove front exhaust pipe. See FRONT EXHAUST PIPE AND CATALYST WITH
ATTACHMENTS

z

Remove ribbed belt. See RIBBED BELT TENSIONER, REMOVING AND INSTALLING

z

Unscrew wiper arms.

z

M8 hex nuts = 20 N.m (15 ft lb)

z

Remove plenum chamber cover.

WARNING:

Fire hazard! Do NOT have anything in the area that can ignite Diesel
fuel!



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



See PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING

z

Disconnect fuel supply and return lines at fuel filter.

z

Remove fuel filter with bracket

z

Disconnect all coolant, vacuum and breather hoses from engine.

z

Disconnect all wiring connections from transmission, Generator and starter and move to one side.

z

Loosely unscrew coolant reservoir and place to side.

z

Remove toothed belt guard upper section.

z

Remove valve cover.

z

Remove brake booster vacuum pump.

z

Unscrew turbocharger oil return line to cylinder block.

z

Unscrew oil supply line at turbocharger

z

Remove injection lines.

z

Remove return line from injector jets/injection pump.

z

Remove glowplug harness connector.

z

Install engine support bracket 10-222A with 10-222 A/1 legs.

Fig. 73: Installing Engine Support Bracket
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Loosely unscrew subassembly (engine side) from upper engine bracket (arrows).

z

Remove engine mount and engine bracket.

z

Lift engine again slightly using spindle -B-.

NOTE:

Always remove injection lines as a set. Use 3035 offset tubing wrench to
loosen/tighten the injection lines.

NOTE:

Both lifting eyes are located on the cylinder head, therefore an additional
