Piston ring gap, checking

z

Squarely insert ring into top of cylinder and push it down to approx. 15 mm from lower edge of cylinder.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 59: Checking Piston Ring Gap
Courtesy of VOLKSWAGEN OF AMERICA, INC.

PISTON RING END GAP DIMENSIONS

Ring to groove clearance, checking

Clean groove before checking.

Piston ring
Dimensions in mm

New

Wear limit

1st compression ring

0.20 to 0.40

1.0

2nd compression ring

0.20 to 0.40

1.0

Oil scraper ring

0.25 to 0.50

1.0



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 60: Checking Ring To Groove Clearance
Courtesy of VOLKSWAGEN OF AMERICA, INC.

RING TO GROOVE CLEARANCE DIMENSIONS



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Cylinder bores, checking

Special tools and equipment

z

Internal dial gauge 50 to 100 mm

z

Take measurements at 3 positions in both lateral -A- and longitudinal -B- directions, as illustrated.

z

Deviation from nominal dimension: 0.10 mm maximum

Fig. 61: Checking Cylinder Bores
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Piston installation position and piston/cylinder allocation

Piston in cylinders 1 and 2:

Larger intake valve chamber points toward flywheel (arrows)

Piston in cylinders 3 and 4:

Larger intake valve chamber points toward belt pulley side (arrows).

Piston ring
Dimensions in mm

New

Wear limit

1st compression ring

0.06 to 0.09

0.25

2nd compression ring

0.05 to 0.08

0.25

Oil scraper ring

0.03 to 0.06

0.15

NOTE:

Do NOT measure the cylinder bores when the block is mounted on a repair
stand using the VW 540 adaptor bracket. Bending stresses resulting from
the mass overhang will make incorrect measurements likely.
