– Unscrew positive wire -1- and disconnect connector from ter‐

minal 50 -2-.

– Remove noise insulation ⇒ General body repairs, exterior;

Rep. gr. 50 .

– Remove nut -1- from lower starter bolt.
– Remove wiring retainer -2-.

– Remove lower bolt -arrow- from starter.

following:
– Tighten threaded connections to specified torques

⇒ page 14

6.2.6

Vehicles with 1.9l diesel engine

Special tools and workshop equipment required
♦ Torque wrench -V.A.G 1331-

♦ Torque wrench -V.A.G 1332-

6. Starter B

⇒ page 4

– Pull engine cover upwards -arrows A- and forwards

-arrow B-.

– Disconnect connector -1- and release spring-type clip -2- us‐

ing spring type clip pliers -VAS 5024A- .

– Pull vacuum hose -arrow- off air filter housing.

– Pull hose -arrow- off air filter housing and remove.
– Pull air filter housing upwards out of brackets and remove.

– Push down protective cap in direction of -arrow- from solenoid

switch.

6. Starter B
