Volkswagen Golf Variant / Jetta. Manual - part 207
6-Speed 02Q FWD
Codes
JLW
JMA
KDN
Manufactured
from
through
05/2006
05/2007
06/2006
06/2007
05/2007
01/2008
Allocation
Type Jetta from MY 2005
Golf Wagon from MY
2007
Jetta from MY 2005
Jetta from MY 2005
Golf Wagon from MY
2007
Engine
2.0L - 147 kW
Turbo FSI
2.0L - 125 KW
Turbo diesel
2.0L - 100 kW
turbo diesel
2.0L - 103 kW
turbo diesel
Ratio: Z2 : Z1
Final drive I
1)
71 : 18 = 3.944
70 : 19 = 3.684
69 : 20 = 3.450
Final drive II
2)
71 : 23 = 3.087
70 : 24 = 2.917
69 : 25 = 2.760
Manual Transmission Capacity
Refer to ⇒ Fluid Ca‐
pacity Tables; Rep.
Gr. 03
Refer to ⇒ Fluid Ca‐
pacity Tables; Rep.
Gr. 03
Refer to ⇒ Fluid Ca‐
pacity Tables; Rep.
Gr. 03
Driveshaft Flange Diameter
107 mm
107 mm
107 mm
1)
Final drive for 1st to 4th gear
2)
Final drive for 5th/6th and reverse gears
• Refer to the Parts Catalog for the following information.
♦ The individual gear ratios
♦ Transmission fluid specification
♦ Clutch disc and pressure plate allocation
Manual Transmission
6-Speed 02Q FWD
Codes
KDQ
KDS
KNS
Manufactured
from
through
07/2007
03/2008
07/2007
06/2008
11/2007
10/2008
Allocation
Type Jetta from MY 2005
Golf Wagon from MY
2007
Jetta from MY 2005
Jetta from MY 2005
Golf Wagon from MY
2007
Golf Wagon from MY
10
Engine
2.0L - 147 kW
Turbo FSI
2.0L - 125 KW
Turbo diesel
2.0L - 100 kW
turbo diesel
2.0L - 103 kW
turbo diesel
Ratio: Z2 : Z1
Final drive I
1)
71 : 18 = 3.944
70 : 19 = 3.684
69 : 20 = 3.450
Final drive II
2)
71 : 23 = 3.087
70 : 24 = 2.917
69 : 25 = 2.760
Manual Transmission Capacity
Refer to ⇒ Fluid Ca‐
pacity Tables; Rep.
Gr. 03
Refer to ⇒ Fluid Ca‐
pacity Tables; Rep.
Gr. 03
Refer to ⇒ Fluid Ca‐
pacity Tables; Rep.
Gr. 03
Driveshaft Flange Diameter
107 mm
107 mm
107 mm
1)
Final drive for 1st to 4th gear
2)
Final drive for 5th/6th and reverse gears
• Refer to the Parts Catalog for the following information.
♦ The individual gear ratios
♦ Transmission fluid specification
♦ Clutch disc and pressure plate allocation
1. Transmission Identification, FWD
3
