of the clutch pedal -2-. ening specification. Refer to ⇒ “1.3.3 Tightening Specifications”, page 22 Securing with One Bolt ening specification. Refer to ⇒ “1.3.3 Tightening Specifications”, page 22 Continuation for All – Attach the cable guide -2- to the steering column. Removing, Jetta from MY 2011 . Vehicles with Knee Airbag ⇒ Body Interior; Rep. Gr. 69 . Continuation for All Refer to ⇒ Body Interior; Rep. Gr. 68 . – If disconnected, connect the battery. Refer to ⇒ Electrical Equipment; Rep. Gr. 27 ; Battery; Battery, Removing and In‐ stalling . 1.3.3 Tightening Specifications Component Nm Clutch pedal to mounting bracket ♦ Replace the self-locking nuts. 25 Impact bolster to mounting bracket/steering column (secured with two bolts) 10 Impact bolster to mounting bracket/steering column (secured with one bolt) 20 ♦ Replace the impact bolster bolts
22 |
