– On the side panel mark the area in which, for safety reasons

»crash safety«, no welding work may be carried out.

Dimension -a- = 45 mm
Dimension -b- = 145 mm

Note

The measurements given must be adhered to.

7.3.3

Moulded foam elements

Follow repair instructions.
Moulded foam element ⇒ General Information; Body Repairs,

General Body Repairs ; General Notes; Moulded foam elements

7.3.4

Welding in

– Place backing material behind parting cuts.

– Apply 1K assembly adhesive -D 190 MKD A3- (12 mm high

triangular shaped bead) in bonding area -1- and apply 2K body

Body Repairs - Edition 06.2010

7. Renewing side panel - partial renewal

225

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

adhesive -D 180 KD3 A2- in bonding area -2- (2 x 3.5 mm ∅

beads).

Note

♦

New part must be welded in within 90 minutes or adhesion of adhesive will be impaired.

♦

Before starting welding on the right-hand side panel, apply butyl sealing cord in the area of the fuel filler

neck.

– Adapt new part with vehicle standing on its wheels or on align‐

ment bracket set and fix in position.

– Check fit with bolt-on parts.

Note

Note that no welding work may be carried out in area -1-.

– Weld in side panel, RP spot weld seam and SG plug weld

seam.

Body Repairs - Edition 06.2010

226

     Rep. gr.53 - Body - rear

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

– Weld transition to side member reinforcement, staggered SG

continuous weld seam.

– Weld in parting cuts, SG stepped weld seam.
– Reform wheel housing flange.
– Wipe away excess adhesive and seal wheel arch.

7.3.5

Adapting sealing channel to fit and weld‐

ing in - partial renewal

– Adapt sealing channel to fit and hold in position.

– Weld in sealing channel, SG plug weld and SG stepped weld

seam.

Body Repairs - Edition 06.2010

7. Renewing side panel - partial renewal

227

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

– Reinstate original joint, RP spot weld seam.

Note

The optic of the original soldered seam must be recreated using

adhesive sealing compound -AKD 476 KD5 05- .

Body Repairs - Edition 06.2010
