Toyota Tundra (2019 year). Manual - part 21

321

Multimedia

5-6. Using an external device

Listening to an iPod .......... 347
Listening to a USB

memory device................ 351

Using the AUX port ........... 355

5-7. Connecting Bluetooth

Preparations to use

wireless
communication................ 356

Registering a Bluetooth

audio player
for the first time ............... 361

Registering a Bluetooth

phone for the first time ... 362

Registering a Bluetooth

device.............................. 363

Connecting a Bluetooth

device.............................. 365

Displaying a Bluetooth

device details .................. 367

Detailed Bluetooth

system settings ............... 368

5-8. Bluetooth

audio

Listening to Bluetooth

audio ............................... 369

5-9. Bluetooth

phone

Using a Bluetooth

phone.............................. 370

Making a call ..................... 372
Receiving a call................. 375
Speaking on the phone ..... 376
Bluetooth

phone

message function............ 379

Using the steering wheel

switches .......................... 383

Bluetooth

phone

settings ........................... 384

Contact/Call History

Settings........................... 386

What to do if...

(Troubleshooting)............ 395

5-10.Using the voice command

system

Voice command system.... 399

5-11.Bluetooth

Bluetooth

......................... 403

5-12.Antenna

Antenna............................. 408

322

5-1. Basic Operations

Multimedia system types



Entune Audio
P. 324



Entune Audio Plus
Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

323

5-1. Basic Operations

Mu
ltim



Entune Premium Audio
Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

324

5-1. Basic Operations

Entune Audio

button

Press this button to access the Bluetooth

hands-free system.

(

P. 370)

“SETUP” button
Press this button to customize the function settings. (

P. 329)

“AUDIO” button
Display the “Select Audio Source” screen or audio control
screen. (

P. 336)

“TRUCK” button
Press this button to access the fuel consumption information.
(

P. 107)

Operations such as listening to audio, using the hands-free
phone, confirming vehicle information and changing multimedia
system settings are started by using the following buttons.

Multimedia system operation buttons

325

5-1. Basic Operations

Mu
ltim

By touching the screen with your finger, you can control the Audio
system, hands-free system, etc.

■

Drag

Touch the screen with your finger and move the screen to the
desired position.
● Scrolling the lists
● Using scroll bar in lists

■

Flick

Touch the screen with your finger and then quickly move the
screen.
● Scrolling the main screen page
● Returning to the menu screen from the sub-menu screen (screen

one level below)

: The above operations may not be performed on all screens.

■

When using the touch screen

●

If the screen is cold, the display may be dark, or the system may seem to be
operating slightly slower than normal.

●

The screen may seem dark and hard to see when viewed through sun-
glasses. Change your angle of viewing, adjust the display on the “Display
Settings” screen (

P. 333) or remove your sunglasses.

■

Using cellular phones
Interference may be heard through the multimedia system's speakers if a cel-
lular phone is being used inside or close to the vehicle while the multimedia
system is operating.

Operating the touch screen

326

5-1. Basic Operations

WARNING

■

Laser product
THIS PRODUCT IS A CLASS I LASER PRODUCT. USE OF CONTROLS
OR  ADJUSTMENTS  OR  PERFORMANCE  OF  PROCEDURES  OTHER
THAN  THOSE  SPECIFIED  HEREIN  MAY  RESULT  IN  HAZARDOUS
RADIATION  EXPOSURE.  DO  NOT  OPEN  COVERS  AND  DO  NOT
REPAIR  BY  YOURSELF.  REFER  SERVICING  TO  QUALIFIED
PERSONNEL.

NOTICE

■

To avoid damaging the touch screen

●

To prevent damaging the screen, lightly touch the screen buttons with your
finger.

●

Do not use objects other than your finger to touch the screen.

●

Wipe off fingerprints using a glass cleaning cloth. Do not use chemical
cleaners to clean the screen, as they may damage the touch screen.

■

To prevent battery discharge
Do not leave the multimedia system on longer than necessary when the
engine is off.

■

To avoid damaging the multimedia system
Take care not to spill drinks or other fluids on the multimedia system.

327

5-1. Basic Operations

Mu
ltim

Steering wheel audio switches

Radio mode:

• Press: Selects a radio station
• Press and hold: Seeks up/

down

CD, MP3/WMA disc, Blue-
tooth

, iPod or USB mode:

• Press: Selects a track/file/

song

• Press and hold: Fast scroll thru the track/file/song list

Volume switch

• Increases/decreases volume
• Press and hold: Continuously increases/decreases volume

“MODE/HOLD” switch

• Changes audio source
• Press and hold this switch to mute or pause the current operation

To cancel the mute or pause, press and hold.

Some audio features can be controlled using the switches on
the steering wheel.
Operation may differ depending on the type of multimedia sys-
tem or navigation system. For details, refer to the manual pro-
vided with the multimedia system or navigation system.

Operating the multimedia system using the steering wheel
switches

WARNING

■

To reduce the risk of an accident
Exercise care when operating the audio switches on the steering wheel.

328

5-1. Basic Operations

USB Port/AUX Port

■

iPod
Open the cover and connect an
iPod using an iPod cable.

Turn on the power of the iPod if
it is not turned on.

■

USB memory
Open the cover and connect the USB memory device.

Turn on the power of the USB memory device if it is not turned on.

■

Portable audio player
Open the cover and connect the portable audio player.

Turn on the power of the portable audio player if it is not turned on.

■

AUX port
The AUX port only supports audio input.

Connect an iPod, USB memory device or portable audio player
to the USB/AUX port as indicated below. Select “iPod”, “USB” or
“AUX” on the “Select Audio Source” screen and the device can
be operated via multimedia system.

Connecting using the USB/AUX port

WARNING

■

While driving
Do not connect a device or operate the device controls.

329

5-2. Setup

Mu
ltim

Setup menu

Press the “SETUP” button to display the “Setup” screen.

Select to adjust the settings for
operation sounds, screen ani-
mation, etc. (

P. 330)

Select to set the voice settings.
(

P. 334)

Select to adjust the settings for
contrast and brightness of the
screen. (

P. 333)

Select to adjust the settings for registering, removing, connecting
and disconnecting Bluetooth

devices. (

P. 360, 36 5)

Select to adjust the settings for phone sound, contact, etc.
(

P. 384)

Select to set radio and external media settings. (

P. 332)

Select to turn the screen off.
Select to set the vehicle customization. (

P. 623)

You can adjust the multimedia system to your desired settings.

Display “Setup” screen

330

5-2. Setup

General settings

Press the “SETUP” button.
Select “General” on the “Setup”
screen.

Select to adjust the clock.
(

P. 331)

“English”,

“Français”

“Español” can be selected.
On/off  can  be  selected  to
sound beeps.
Select  to  change  the  screen
color.
Select  to  change  the  key-
board layout.
The  animation  effect  for  the
screen can be set to on/off.
Select  to  delete  personal
data (

P. 331)

Select to update program versions. For details, contact your
Toyota dealer.
Select to display the software information. Notices related to third
party software used in this product are enlisted. (This includes
instructions for obtaining such software, where applicable.)

■

To return to the default settings
Select “Default”, and then “Yes”.

Settings are available for adjusting the operation sounds,
screen animation, etc.

Screen for general settings

331

5-2. Setup

Mu
ltim

Select “Clock” on the “General Settings” screen.
Adjust the time, then select “OK”.

Select “Delete Personal Data” on the “General Settings” screen.
Select “Delete”.

Check carefully beforehand, as data cannot be retrieved once deleted.

A confirmation screen will be displayed. Select “Yes”.
The following personal data will be deleted or changed to its default
settings.

• Audio settings
• Phone settings

Setting the clock

Delete personal data

332

5-2. Setup

Audio settings

Press the “SETUP” button.
Select “Audio” on the “Setup” screen.

Select the number of radio
preset stations.
Select to display the cover
art.
Select “High”, “Mid”, “Low” or
“Off”.

■

About Automatic Sound Leveliser (ASL)
ASL automatically adjusts the volume and tone quality according to the vehi-
cle speed.

Settings are available for adjusting the radio operation, cover
art, etc.

Screen for audio settings

333

5-2. Setup

Mu
ltim

Display settings

Press the “SETUP” button.
Select “Display” on the “Setup” screen.

Adjust general screen con-
trast/brightness
Adjust camera screen con-
trast/brightness
Changes to day mode.

Select “General” or “Camera” on the “Display Settings” screen.
Adjust the display as desired by selecting “+” or “-”.

When the headlights are turned on, the screen dims.
However, the screen can be switched to day mode by selecting “Day
Mode”.

The screen will stay in day mode when the headlights are turned on until
“Day Mode” is selected again.

Settings are available for adjusting the contrast and brightness
of the screen.

Screen for display settings

Adjusting the screen contrast/brightness

Day mode

334

5-2. Setup

Voice settings

Adjust  the  voice  guidance  vol-
ume setting.
Set  the  voice  recognition
prompts “High”, “Low” or “Off”.
Set the train voice recognition.
Set  the  voice  prompt  interrupt
on/off.
Voice recognition tutorial

This screen is used for guidance for voice command systems
setting.

335

5-3. Using the audio system

Mu
ltim

Basic audio operations

Turn this knob to select radio station bands, tracks and files. Also
the knob can be used to select items in the list display.
Press the “

” or “” button to seek up or down for a radio station,

or to access a desired track or file.
Press to pause or resume playing music.
Press this knob to turn the multimedia system on and off, and
turn it to adjust the volume.
Press this button to eject a disc
Insert a disc into the disc slot
“Select Audio Source” screen appears (

P. 336)

Setting the Sound (

P. 339)

Pause or resume playing music
Select to enable repeat play
Select to enable random playback

Basic audio operations and functions common to each mode are
explained in this section.

Operating the multimedia system

336

5-3. Using the audio system

Selecting the audio source

Press the “AUDIO” button.
Select “Source” on the audio control screen or press the “AUDIO”
button again.
Select the desired audio
source.

■

Reordering the audio source

Select “Reorder”.
Select the desired audio source then

to reorder.

Select “OK”.

Switching between audio sources such as radio and CD are
explained in this section.

Selecting the audio source

Content .. 19 20 21 22 ..
