Toyota Sienna (2019 year). Manual - part 36

SIENNA_OM_OM08025U_(U)

561

Fo
r ow

ners

AVERTISSEMENT

Précautions relatives aux coussins gonflables SRS

Ne vous asseyez pas sur le bord du
siège et ne vous appuyez pas sur la
planche de bord.

Ne laissez pas un enfant se tenir face
au coussin gonflable SRS du passager
avant ni s’asseoir sur les genoux d’un
passager avant.

Ne laissez pas les occupants des
sièges avant tenir des objets sur leurs
genoux.

Ne vous appuyez pas sur la portière ou
sur le brancard de pavillon, ni sur les
montants avant, latéraux ou arrière.

Ne laissez personne s’agenouiller face
à la portière sur le siège du passager ni
sortir la tête ou les mains à l’extérieur
du véhicule.

562

SIENNA_OM_OM08025U_(U)

AVERTISSEMENT

Précautions relatives aux coussins gonflables SRS

Ne  fixez  et  n’appuyez  rien  sur  des
zones telles que la planche de bord, le
tampon  de  volant  ou  encore  la  partie
inférieure du tableau de bord.
Ces  objets  peuvent  se  transformer  en
projectiles  lorsque  les  coussins  gon-
flables  SRS  du  conducteur,  du  passa-
ger  avant  et  de  protection  des  genoux
du conducteur se déploient.

Ne  fixez  rien  sur  des  zones  telles  que
les  portières,  le  pare-brise,  les  glaces
de  portières,  les  montants  avant  ou
arrière, le brancard de pavillon et la poi-
gnée de maintien.

Véhicules non dotés du système Smart
key  :  N’accrochez  pas  d’objets  lourds,
pointus  ou  durs,  par  exemple  des  clés
ou des accessoires, à la clé. Ces objets
pourraient empêcher le déploiement du
coussin  gonflable  SRS  de  protection
des  genoux  ou  être  projetés  violem-
ment dans l’assise du siège du conduc-
teur  par  la  force  du  déploiement,  et
donc présenter un danger.

SIENNA_OM_OM08025U_(U)

563

Fo
r ow

ners

AVERTISSEMENT

Précautions relatives aux coussins gonflables SRS

N’accrochez pas de cintres ni d’autres objets rigides sur les crochets
porte-vêtements. Tous ces objets pourraient se transformer en projectiles
et vous occasionner des blessures graves, voire mortelles, en cas de
déploiement des coussins gonflables SRS en rideau.

Si un recouvrement de vinyle est placé sur la zone de déploiement du
coussin gonflable SRS de protection des genoux, veillez à le retirer.

N’utilisez pas d’accessoires recouvrant les parties du siège où les cous-
sins gonflables SRS latéraux et le coussin gonflable SRS du coussin de
siège se déploient, car ces accessoires pourraient entraver le déploiement
des  coussins  SRS.  De  tels  accessoires  peuvent  empêcher  les  coussins
gonflables  latéraux  et  le  coussin  gonflable  du  coussin  de  siège  de  se
déployer  correctement,  rendre  le  système  inopérant  ou  provoquer  acci-
dentellement le déploiement des coussins gonflables latéraux et du cous-
sin  gonflable  du  coussin  de  siège,  occasionnant  des  blessures  graves,
voire mortelles.

Ne frappez pas et n’appliquez pas une pression importante à l’emplace-
ment des composants de coussins gonflables SRS.
Cela peut provoquer un mauvais fonctionnement des coussins gonflables
SRS.

Ne touchez à aucun composant des coussins gonflables SRS immédiate-
ment après leur déploiement (gonflage), car ils pourraient être chauds.

Si vous avez de la difficulté à respirer après le déploiement des coussins
gonflables SRS, ouvrez une portière ou une glace pour laisser entrer l’air,
ou quittez le véhicule si vous pouvez le faire en toute sécurité. Dès que
possible, nettoyez tous les résidus afin d’éviter les irritations cutanées.

Si les emplacements de stockage des coussins gonflables SRS, tels que
le tampon de volant et les garnitures des montants avant et arrière, sont
endommagés ou fissurés, faites-les remplacer par votre concessionnaire
Toyota.

Ne placez aucun objet, par exemple un coussin, sur le siège du passager
avant. Cela disperserait le poids du passager, ce qui empêcherait le cap-
teur de le détecter correctement. Cela pourrait empêcher le déploiement
des coussins gonflables SRS du passager avant en cas de collision.

564

SIENNA_OM_OM08025U_(U)

AVERTISSEMENT

Modification et mise au rebut des composants du système de coussins
gonflables SRS
Ne mettez pas votre véhicule au rebut et n’effectuez aucune des modifica-
tions suivantes sans d’abord consulter votre concessionnaire Toyota.
Les coussins gonflables SRS pourraient fonctionner de manière incorrecte
ou se déployer (gonfler) accidentellement, ce qui serait susceptible d’occa-
sionner des blessures graves, voire mortelles.

Installation, retrait, démontage et réparation des coussins gonflables SRS

Réparations, modifications, retrait ou remplacement du volant, du tableau
de bord, de la planche de bord, des sièges ou du capitonnage des sièges,
des montants avant, latéraux et arrière, ou des brancards de pavillon

Réparations ou modifications de l’aile avant, du pare-chocs avant ou du
côté de l’habitacle

Installation d’une protection de calandre (barre safari, barre kangourou,
etc.), de lames de déneigement, de treuils ou d’un porte-bagages de toit

Modifications du système de suspension du véhicule

Installation d’appareils électroniques tels qu’un émetteur-récepteur radio
ou un lecteur de CD

Modifications à votre véhicule pour une personne aux capacités physiques
réduites

565

SIENNA_OM_OM08025U_(U)

Index

What to do if...

(Troubleshooting) .................... 566

Alphabetical index ..................... 570

For vehicles with an Entune Audio, Entune Audio Plus or
Entune Premium Audio, refer to the “NAVIGATION AND
MULTIMEDIA SYSTEM OWNER’S MANUAL” for information
regarding the equipment listed below.
• Navigation system
• Rear view monitor system
• Audio/visual system
• Panoramic view monitor
• Hands-free system (for cellular phone)
For details about AUTO ACCESS SEAT, refer to the “AUTO
ACCESS SEAT OWNER’S MANUAL”.

566

What to do if... (Troubleshooting)

SIENNA_OM_OM08025U_(U)

What to do if... (Troubleshooting)

? If you lose your keys or mechanical keys, new genuine keys or mechanical

keys can be made by your Toyota dealer. (

P. 107)

? If you lose your keys or electronic keys, the risk of vehicle theft increases

significantly. Contact your Toyota dealer immediately. (

P. 109)

? Is the key battery weak or depleted? (

P. 436)

? Vehicles with a smart key system

Is the engine switch in IGNITION ON mode?
When locking the doors, turn the engine switch off. (

P. 229)

? Vehicles with a smart key system

Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.

? The function may not operate properly due to the condition of the radio

wave. (

P. 107, 145)

? Is the child-protector lock set?

The sliding door cannot be opened from inside the vehicle when the lock is
set. Open the sliding door from outside and then unlock the child-protector
lock. (

P. 125)

If you have a problem, check the following before contacting
your Toyota dealer.

The doors cannot be locked, unlocked, opened or closed

You lose your keys

The doors cannot be locked or unlocked

The sliding door cannot be opened

567

What to do if... (Troubleshooting)

SIENNA_OM_OM08025U_(U)

? Is the shift lever in P? (

P. 225)

? Is the steering wheel unlocked? (

P. 226)

? Is the battery discharged? (

P. 505)

? Did you press the engine switch while firmly depressing the brake pedal?

(

P. 228)

? Is the shift lever in P? (

P. 228)

? Is the electronic key anywhere detectable inside the vehicle? (

P. 143)

? Is the steering wheel unlocked? (

P. 231)

? Is the electronic key battery weak or depleted?

In this case, the engine can be started in a temporary way. (

P. 503)

? Is the battery discharged? (

P. 505)

? Is the engine switch in the “ON” position (vehicles without a smart key sys-

tem) or IGNITION ON mode (vehicles with a smart key system)?
If you cannot release the shift lever by depressing the brake
pedal with the engine switch in the “ON” position (vehicles without a smart
key system) or IGNITION ON mode (vehicles with a smart key system).
(

P. 237)

If you think something is wrong

The engine does not start
(vehicles without a smart key system)

The engine does not start
(vehicles with a smart key system)

The shift lever cannot be shifted from P even if you depress
the brake pedal

568

What to do if... (Troubleshooting)

SIENNA_OM_OM08025U_(U)

? Vehicles without a smart key system:

It is locked to prevent theft of the vehicle if the key is removed from the
engine switch. (

P. 226)

? Vehicles with a smart key system:

It is locked automatically to prevent theft of the vehicle. (

P. 231)

? Is the window lock switch pressed?

The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. (

P. 184)

? The auto power off function will be operated if the vehicle is left in ACCES-

SORY or IGNITION ON mode (the engine is not operating) for a period of
time. (

P. 230)

? The seat belt reminder light is flashing

Are the driver and the front passenger wearing the seat belts? (

P. 473)

? The brake system warning light is on

Is the parking brake released? (

P. 240)

Depending on the situation, other types of warning buzzer may also sound.
(

P. 471, 481)

The steering wheel cannot be turned after the engine is
stopped

The windows do not open or close by operating the power
window switches

The engine switch is turned off automatically
(vehicles with a smart key system)

A warning buzzer sounds during driving

569

What to do if... (Troubleshooting)

SIENNA_OM_OM08025U_(U)

? Did anyone inside the vehicle open a door during setting the alarm?

The sensor detects it and the alarm sounds. (

P. 79)

To stop the alarm, turn the engine switch to the “ON” position (vehicles with-
out a smart key system) or IGNITION ON mode (vehicles with a smart key
system) or start the engine.

? Is the message displayed on the multi-information display?

Check the message on the multi-information display. (

P. 481)

? When a warning light turns on or a warning message is displayed, refer to

P. 471, 481.

Vehicles with run-flat tires:
Slow down the vehicle, drive with extra caution, and take your vehicle
to the nearest Toyota dealer or authorized tire dealer as soon as possi-
ble to have the tire replaced. (

P. 499)

Vehicles with a compact spare tire:
Stop the vehicle in a safe place and replace the flat tire with the spare
tire. (

P. 485)

? Try the procedure for when the vehicle becomes stuck in mud, dirt, or

snow. (

P. 512)

An alarm is activated and the horn sounds (if equipped)

A warning buzzer sounds when leaving the vehicle
(vehicles with a smart key system)

A warning light turns on or a warning message is displayed

When a problem has occurred

If you have a flat tire

The vehicle becomes stuck

570

Alphabetical index

SIENNA_OM_OM08025U_(U)

Alphabetical index

A/C .................................... 332, 341

Air conditioning filter ............. 434
Front automatic air

conditioning system............ 332

Rear automatic air

conditioning system............ 341

ABS (Anti-lock Brake

System) .................................. 323

Function ................................ 323
Warning light......................... 472

Active head restraint ............... 150
Active Torque Control

4WD system........................... 323

Function ................................ 323
Warning message................. 483

Air conditioning filter .............. 434
Air conditioning system

Air conditioning filter ............. 434
Front automatic air

conditioning system............ 332

Rear automatic air

conditioning system............ 341

Airbags ....................................... 38

Airbag operating

conditions ............................. 47

Airbag precautions

for your child......................... 41

Airbag warning light .............. 472
Correct driving posture ........... 28
Curtain shield airbag

operating conditions ............. 48

Curtain shield airbag

precautions........................... 41

Front passenger occupant

classification system............. 52

General airbag

precautions........................... 41

Locations of airbags................ 38
Modification and

disposal of airbags ............... 46

Side and curtain shield

airbags operating
conditions ............................. 48

Side and curtain shield

airbags precautions.............. 41

SRS airbag instructions

for Canadian owners .......... 555

SRS airbags ........................... 38

Alarm

Alarm ...................................... 79
Warning buzzer .................... 471

Anchor brackets ........................ 62
Antenna (smart key

system) .................................. 143

Anti-lock brake system

(ABS) ...................................... 323

Function................................ 323
Warning light......................... 472

Approach warning................... 297
Armrest..................................... 370
Assist grips.............................. 371
Audio input

Audio visual input

Audio/visual system

Automatic High Beam ............. 246

Warning message................. 483

Automatic light control

system.................................... 241

Automatic transaxle

Automatic transaxle .............. 233
If the shift lever cannot be

shifted from P ..................... 237

S mode ................................. 235

AUX port

Auxiliary box........................... 358
A/V input port

571

Alphabetical index

SIENNA_OM_OM08025U_(U)

Back door ................................. 133
Back-up lights

Replacing light bulbs............. 455
Wattage ................................ 525

Battery

Battery checking ................... 416
If the vehicle has

discharged battery.............. 505

Preparing and checking

before winter....................... 328

Warning light......................... 471
Warning message................. 484

Blind Spot Monitor (BSM) ....... 303
Bluetooth

audio

Bluetooth

phone

Bottle holder ............................ 356
Brake

Fluid ...................................... 415
Parking brake........................ 240
Warning light......................... 471
Warning message................. 484

Brake assist ............................. 323
Break-in tips............................. 195
Brightness control

Instrument light control ........... 91

BSM (Blind Spot Monitor) ....... 303

BSM function ........................ 307
RCTA function ...................... 310

Care

Aluminum wheels ................. 393
Exterior ................................. 392
Interior .................................. 395
Seat belts.............................. 396

Cargo capacity......................... 209
Cargo hooks ............................ 361
CD player

Chains ...................................... 329
Child restraint system............... 58

Booster seats, definition ......... 59
Booster seats, installation....... 70
Convertible seats,

definition............................... 59

Convertible seats,

installation ............................ 68

Front passenger occupant

classification system ............ 52

Infant seats, definition............. 59
Infant seats, installation .......... 68
Installing CRS with

LATCH anchors.............. 64, 66

Installing CRS with

seat belts.............................. 68

Installing CRS with

top tether strap ............... 71, 72

: Refer to “NAVIGATION AND MULTIMEDIA

SYSTEM OWNER’S MANUAL”

572

Alphabetical index

SIENNA_OM_OM08025U_(U)

Child safety ................................ 57

Airbag precautions.................. 41
Back door precautions .......... 139
Battery precautions........ 418,508
Child restraint system ............. 58
How your child should wear

the seat belt.......................... 34

Installing child restraints ......... 62
Moon roof precautions .......... 191
Power window lock switch .... 184
Power window precautions ... 186
Removed key battery

precautions......................... 438

Seat belt extender

precautions........................... 37

Seat belt precautions .............. 36
Seat heater precautions........ 344
Sliding door

child-protectors................... 125

Child-protectors....................... 125
Cleaning

Aluminum wheels.................. 393
Exterior ................................. 392
Interior................................... 395
Seat belts.............................. 396

Clock

Compass .................................. 381
Condenser................................ 415
Console box ............................. 352
Conversation mirror ................ 364
Cooling system........................ 413

Engine overheating............... 509

Cruise control

Dynamic radar cruise

control................................. 289

Warning message................. 300

Cup holders.............................. 354
Curtain shield airbags............... 38
Customizable features ............ 540

Daytime running light

system.................................... 244

Defogger

Outside rear view mirrors ..... 336
Rear window......................... 336
Windshield ............................ 336

Differential

Rear differential .................... 521

Dimension ................................ 516
Dinghy towing.......................... 224
Display

Drive information .................... 94
Dynamic radar cruise

control ................................ 289

Fuel consumption

information ........................... 99

LDA

(Lane Departure Alert) ....... 283

Multi-information display......... 92
Warning messages............... 481

Do-it-yourself maintenance .... 405
Door courtesy lights

Door courtesy lights.............. 347
Wattage ................................ 525

Doors

Automatic door locking

and unlocking system......... 115

Back door ............................. 133
Door lock .............. 110, 121, 133
Front doors ........................... 110
Outside rear view mirrors ..... 181
Sliding door

child-protectors................... 125

Sliding doors......................... 121

573

Alphabetical index

SIENNA_OM_OM08025U_(U)

Driving

Break-in tips.......................... 195
Correct posture ....................... 28
Procedures ........................... 194
Winter driving tips ................. 328

Driving position memory ........ 169

Driving position memory ....... 170
Memory recall function.......... 171
Power easy access

system ................................ 169

Dynamic radar cruise control

Function ................................ 289

DVD player

Eco Driving Indicator ................ 88
EDR (Event data recorder)........ 10
Electric power steering

(EPS)....................................... 323

Function ................................ 323
Warning light......................... 472

Electronic key

Battery-saving function ......... 145
If your electronic key does

not operate properly ........... 503

Replacing the battery............ 436

Emergency flashers ................ 462

Emergency, in case of

If a warning buzzer

sounds................................ 471

If a warning light turns on ..... 471
If a warning message is

displayed ............................ 481

If the battery is discharged ... 505
If the electronic key does

not operate properly ........... 503

If the engine will not start...... 501
If you have a flat tire .... 485, 499
If you lose your keys............. 107
If you think something is

wrong ................................. 469

If your vehicle becomes

stuck................................... 512

If your vehicle has to be

stopped in an emergency... 463

If your vehicle needs to be

towed.................................. 465

If your vehicle overheats....... 509

Engine

“ACC” position ...................... 225
Accessory mode ................... 229
Compartment........................ 410
Engine switch ............... 225, 228
Hood ..................................... 407
How to start the

engine ........................ 225, 228

Identification number ............ 517
If the engine will not start...... 501
Ignition switch

(engine switch) ........... 225, 228

Overheating .......................... 509

: Refer to “NAVIGATION AND MULTIMEDIA

SYSTEM OWNER’S MANUAL”

574

Alphabetical index

SIENNA_OM_OM08025U_(U)

Engine coolant

Capacity................................ 520
Checking............................... 413
Preparing and checking

before winter....................... 328

Engine coolant temperature

gauge........................................ 90

Engine immobilizer system ...... 77
Engine oil

Capacity................................ 518
Checking............................... 411
Oil pressure warning light ..... 471
Oil pressure warning

message............................. 484

Preparing and checking

before winter....................... 328

Engine switch .................. 225, 228
EPS (Electronic Power Steering)

Function ................................ 323
Warning light......................... 472

Event data recorder (EDR)........ 10

Flat tire ............................. 485, 499
Floor mats .................................. 26
Fluid

Automatic transaxle .............. 521
Brake .................................... 415
Transfer ................................ 521
Washer ................................. 419

Fog lights

Light switch........................... 251
Replacing light bulbs ............ 448
Wattage ................................ 525

Front automatic air

conditioning system ............. 332

Front doors .............................. 110
Front passenger occupant

classification system.............. 52

Front seats ............................... 149

Adjustment............................ 149
Cleaning ............................... 395
Correct driving posture ........... 28
Driver’s seat position

memory .............................. 169

Head restraints ..................... 173
Power easy access

system................................ 169

Seat heaters ......................... 344
Seat position memory........... 169

Front side marker lights

Light switch........................... 241
Replacing light bulbs .... 450, 452
Wattage ................................ 525

Front turn signal lights

Replacing light bulbs .... 450, 451
Turn signal lever ................... 239
Wattage ................................ 525

575

Alphabetical index

SIENNA_OM_OM08025U_(U)

Fuel

Capacity................................ 518
Fuel gauge.............................. 90
Fuel pump shut off system.... 470
Gas station information......... 584
Information............................ 526
Refueling............................... 258
Type...................................... 518
Warning light......................... 473

Fuel consumption

information .............................. 99

Fuel filler door.......................... 258

Refueling............................... 258

Fuel pump shut off system..... 470
Fuses ........................................ 439

Garage door opener ................ 374
Gauges ....................................... 89
Glove box ................................. 351
Grocery bag hooks.................. 373

Hands-free system

(for cellular phone)

HDMI port

Head restraints ........................ 173
Headlights

Automatic High Beam

system................................ 246

Discharge headlights

precautions......................... 459

Light switch........................... 241
Manual headlight leveling

dial...................................... 243

Replacing light bulbs .... 445, 447
Wattage ................................ 525

Heaters

Front automatic air

conditioning system............ 332

Heated steering wheel.......... 344
Outside rear view mirrors ..... 336
Rear automatic air

conditioning system............ 341

Seat heaters ......................... 344

Hill-start assist control ........... 323
Hood ......................................... 407
Hooks

Cargo.................................... 361
Grocery bag.......................... 373
Retaining hooks (floor mat) .... 26

Horn .......................................... 177

: Refer to “NAVIGATION AND MULTIMEDIA

SYSTEM OWNER’S MANUAL”

576

Alphabetical index

SIENNA_OM_OM08025U_(U)

I/M test ...................................... 404
Identification

Engine................................... 517
Vehicle .................................. 517

Ignition switch

(engine switch) .............. 225, 228

Illuminated entry system ........ 349
Indicators ................................... 84
Initialization

Items to initialize ................... 550
Maintenance data ................. 399
Power back door................... 138
Power sliding door ................ 128
Tire pressure warning

system ................................ 421

Inside rear view mirror ............ 179
Interior lights............................ 347

Wattage ................................ 525

Intuitive parking assist............ 315

Function ................................ 315
Warning message................. 484

Jack

Positioning a floor jack.......... 409
Vehicle-equipped jack........... 486

Jack handle .............................. 488
Jam protection function

Moon roof.............................. 190
Power back door................... 138
Power sliding doors .............. 127
Power windows..................... 185

Keyless entry

Smart key system ................. 143
Wireless remote control........ 105

Keys

Battery-saving function ......... 145
Electronic key ....................... 104
Engine switch ............... 225, 228
If you lose your keys............. 107
If the electronic key does

not operate properly ........... 503

Key number plate ................. 104
Keyless entry

................... 105, 110, 121, 133

Keys...................................... 104
Mechanical key..................... 104
Replacing the battery............ 436
Warning buzzer .................... 144
Wireless remote control........ 105

Knee airbags.............................. 38

Language (multi-information

display) .................................. 541

LATCH anchors ......................... 62
LDA

(Lane Departure Alert) .......... 279

Lever

Auxiliary catch lever.............. 407
Hood lock release lever ........ 407
Shift lever.............................. 233
Tilt and telescopic steering

lock release lever ............... 177

Turn signal lever ................... 239
Wiper lever ................... 252, 256

Content .. 34 35 36 37 ..
