Instru

Warning lights inform the driver of malfunctions in the indicated vehi-
cle’s systems.

Warning lights

(U.S.A.)

Brake system warning
light (

1, 2

PCS warning light
(

(Canada)

Brake system warning
light (

(Amber)

LDA indicator (

Charging system
warning light (

Slip indicator (

Low engine oil pressure
warning light (

Low fuel level warning
light (

(U.S.A.)

Malfunction indicator
lamp (

Seat belt reminder light
(

(Canada)

Malfunction indicator
lamp (

Low engine oil level
warning light (

SRS warning light
(

Master warning light
(

(U.S.A.)

ABS warning light
(

Tire pressure warning

light (

(Canada)

ABS warning light
(

Low windshield

washer fluid level

warning light (P. 474)

Electric power steering
system warning light
(

Third seat warning light
(

SIENNA_OM_OM08025U_(U)

: These lights turn on when the engine switch is turned to the “ON” position

(vehicles without a smart key system) or IGNITION ON mode (vehicles
with a smart key system) to indicate that a system check is being per-
formed. They will turn off after the engine is started, or after a few seconds.
There may be a malfunction in a system if a light does not come on, or if
the lights do not turn off. Have the vehicle inspected by your Toyota dealer.

: The light comes on or flashes to indicate a malfunction.

: This light illuminates on the multi-information display.

: If equipped

The indicators inform the driver of the operating state of the vehicle’s
various systems.

Brake Override System
warning light (

High coolant
temperature warning
light (

Indicators

Turn signal indicator
(

P. 239)

Cruise control indicator
(

P. 289)

(U.S.A.)

Headlight indicator
(

P. 241)

Dynamic radar cruise
control indicator
(

P. 289)

(Canada)

Tail light indicator
(

P. 241)

Cruise control “SET”
indicator (

P. 289)

Headlight high beam
indicator (

P. 242)

(White)

LDA indicator (

P. 279)

Automatic High Beam
indicator (

P. 246)

(Green)

LDA indicator (

P. 279)

Fog light indicator
(

P. 251)

2, 4

(Amber)

LDA indicator (

P. 279)

SIENNA_OM_OM08025U_(U)

Instru

: If equipped

: This light illuminates on the multi-information display.

: These lights turn on when the engine switch is turned to the “ON” position

: The light flashes to indicate that the system is operating.

: The light comes on when the system is turned off.

3, 4

Slip indicator (

P. 324)

3, 8

Eco Driving Indicator
Light (

P. 88)

3, 5

VSC OFF indicator
(

P. 324)

Low outside
temperature indicator
(

P. 91)

3, 5

PCS warning light
(

P. 267)

3, 9

(U.S.A.)

“AIR BAG ON/OFF”
indicator (

P. 52)

1, 6, 7

BSM (Blind Spot
Monitor) outside rear
view mirror indicators
(

P. 303)

1, 2

“BSM” (Blind Spot
Monitor) indicator
(

P. 303)

3, 9

(Canada)

“AIR BAG ON/OFF”
indicator (

P. 52)

1, 2

“RCTA” (Rear Cross
Traffic Alert) indicator
(

P. 303)

Security indicator
(

P. 77, 79)

“ECT PWR” indicator
(

P. 234)

SIENNA_OM_OM08025U_(U)

: In order to confirm operation, the BSM outside rear view mirror indicators

illuminate in the following situations:

• When the engine switch is turned to the “ON” position (vehicles without a

smart key system) or IGNITION ON mode (vehicles with a smart key sys-
tem) while the BSM function is turned on.

• When the BSM function is turned on while the engine switch is in the

“ON” position (vehicles without a smart key system) or IGNITION ON
mode (vehicles with a smart key system).

If the system is functioning correctly, the BSM outside rear view mirror indi-
cators will turn off after a few seconds.
If the BSM outside rear view mirror indicators do not illuminate or do not
turn off, there may be a malfunction in the system.
If this occurs, have the vehicle inspected by your Toyota dealer.

: This light illuminates on the outside rear view mirrors.

: The light does not turn on when the system is disabled.

: This light illuminates on the center panel.

Eco Driving Indicator Light

The vehicle is set to power mode. (

P. 234)

The vehicle speed is approximately 80 mph (130 km/h) or higher.

During  Eco-friendly  acceleration  (Eco
driving),  Eco  Driving  Indicator  Light  will
turn  on.  When  the  acceleration  pedal  is
depressed excessively, or when the vehi-
cle is stopped, the light turns off.
Eco Driving Indicator Light will not operate
in the following conditions:

The shift lever is in anything other than
D.

WARNING

If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS warning lights not
come on when you start the engine, this could mean that these systems are
not available to help protect you in an accident, which could result in death
or serious injury. Have the vehicle inspected by your Toyota dealer immedi-
ately if this occurs.

SIENNA_OM_OM08025U_(U)

Tachometer

Displays the engine speed in revolutions per minute

Multi-information display

Presents the driver with a variety of driving-related data (

P. 92)

Speedometer

Displays the vehicle speed

Fuel gauge

Displays the quantity of fuel remaining in the tank

Odometer/trip meter display change button
Outside temperature

P. 91

Odometer and trip meter display

Odometer:
Displays the total distance that the vehicle has been driven
Trip meter:
Displays the distance the vehicle has been driven since the meter was last
reset. Trip meters “A” and “B” can be used to record and display different
distances independently.

Shift position and range

P. 233

Meter panel lights control button

P. 91

Engine coolant temperature gauge

Displays the engine coolant temperature

Pressing  this  button  switches
among  the  odometer,  trip  meter
“A”  and  trip  meter  “B”  displays.
When the trip meter  is displayed,
pressing  and  holding  the  button
will reset the trip meter.

Changing the trip meter display

SIENNA_OM_OM08025U_(U)

Instru

The brightness of the meter panel lights can be adjusted.
Pressing the button will adjust the
brightness of the meter panel
lights.

The brightness level of the meters
when  the  surroundings  are  bright
(day mode) and dark (night mode)
can  be  adjusted  individually.  How-
ever, when in day mode, adjusting
the  brightness  level  will  also
change  the  brightness  level  of
night mode.

Outside temperature display

In the following situations, the correct outside temperature may not be dis-
played, or the display may take longer than normal to change.
• When stopped, or driving at low speeds (less than 12 mph [20 km/h])
• When the outside temperature has changed suddenly (at the entrance/

exit of a garage, tunnel, etc.)

The temperature range that can be displayed is from -40°F (-40°C) to 122°F
(50°C).
When the outside temperature drops below 37°F (3°C), the Low outside
temperature indicator will be displayed on the multi-information display.
(

P. 86)

When “--” or “E” is displayed, the system may be malfunctioning. Take your
vehicle to your Toyota dealer.

Meter panel light control

NOTICE

To prevent damage to the engine and its components

Do not let the indicator needle of the tachometer enter the red zone, which
indicates the maximum engine speed.

The engine may be overheating if the engine coolant temperature gauge is
in the red zone (H). In this case, immediately stop the vehicle in a safe
place, and check the engine after it has cooled completely. (

P. 509)

SIENNA_OM_OM08025U_(U)

Multi-information display

The

multi-information

display

presents the driver with a variety
of vehicle data.

Menu icons
Displays the following information when an icon is selected.
(

P. 93)

Some of the information may be displayed automatically depending
on the situation.

Drive information

Select to display various drive data. (

P. 94)

Navigation system-linked display (if equipped)

Select to display the following navigation system-linked information.

• Route guidance
• Compass display (north-up display/heading-up display)

Audio/visual system-linked display

Select to enable selection of an audio source or track on the meter
using the meter control switches.

Dynamic radar cruise control display

Select to display the information and operation procedures of the
dynamic radar cruise control. (

P. 289)

The

tab will change to

when the vehicle is in constant

speed control mode. (

P. 298)

Display contents

SIENNA_OM_OM08025U_(U)

Instru

Warning message display

Select to display warning messages and measures to be taken if a
malfunction is detected. (

P. 481)

When there is a warning message that can be displayed, the color of

changes to Amber.

Settings display

Select to change the meter display settings. (

P. 540)

Intuitive parking assist display (if equipped)
Automatically displayed when the system is used (

P. 315)

Power mode (

P. 234)

The multi-information display is
operated using the meter control
switches.

Enter/Set
Select an item/Change pages
Return to the previous screen
Press: Displays the screen reg-
istered as the top screen

When no screen has been registered, the drive information screen will be
displayed.

Press and hold: Registers the currently displayed screen as the top
screen

When the confirmation screen is displayed, select yes to register the
screen. If the selected screen cannot be registered, a registration failure
message will be shown.

Operating the meter control switches

SIENNA_OM_OM08025U_(U)

Average fuel economy

1, 2

Displays the average fuel consumption since the function was
reset.

Tank average fuel economy

1, 2

Displays the average fuel consumption since the vehicle was refu-
eled.

Trip average fuel economy

1, 2

Displays the average fuel consumption since the engine was
started.

Current fuel economy

1, 2

Displays the current rate of fuel consumption.

Distance to empty

Displays the estimated maximum distance that can be driven with
the quantity of fuel remaining.

• This distance is computed based on your average fuel consump-

tion. As a result, the actual distance that can be driven may differ
from that displayed.

• When only a small amount of fuel is added to the tank, the dis-

play may not be updated.
When refueling, turn the engine switch off. If the vehicle is refu-
eled without turning the engine switch off, the display may not be
updated.

Trip distance

Displays the driving distance after the engine was started.

Distance

Displays the driving distance since the function was reset.

Trip elapsed time

Displays the elapsed time since the function was reset.

Elapsed time

Displays the elapsed time since the engine was started.

Trip average speed

Displays the average vehicle speed since the function was reset.

Average speed

Displays the average vehicle speed since the engine was started.

Drive information

SIENNA_OM_OM08025U_(U)

Instru

AWD control (if equipped)
Displays the torque distribution between the front and rear axles of
the AWD control system

Digital speedometer

Display off
A blank screen is displayed.

: Can be registered to Drive information 1 through 3. (

P. 96)

: Use the displayed fuel consumption as a reference.

: Resetting procedures:

• Select a function to be reset using the meter control switches and then

press and hold to reset.

• If there is more than one function that can be reset, check boxes will be

displayed next to those functions.

SIENNA_OM_OM08025U_(U)
