369

5-1. Using the air conditioning system and defogger

rior

ures

CAMRY_U

■

Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow

immediately after

is pressed.

■

Fogging up of the windows

●

The windows will easily fog up when the humidity in the vehicle is high.

Turning

on will dehumidify the air from the outlets and defog the wind-

shield effectively.

●

If you turn

off, the windows may fog up more easily.

●

The windows may fog up if the recirculated air mode is used.

■

Outside/recirculated air mode

●

When driving on dusty roads such as tunnels or in heavy traffic, set the out-
side/recirculated air mode button to the recirculated air mode. This is effec-
tive in preventing outside air from entering the vehicle interior. During
cooling operation, setting the recirculated air mode will also cool the vehicle
interior effectively.

●

Outside/recirculated air mode may automatically switch depending on the
temperature setting or the inside temperature.

■

When the outside temperature exceeds 75°F (24°C) and the air condition-
ing system is on

●

In order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.

●

Vehicles without a smart key system:
Recirculated air mode is selected as a default mode when the engine switch
is turned to the “ON” position.
Vehicles with a smart key system:
Recirculated air mode is selected as a default mode when the engine
switch is turned to IGNITION ON mode.

●

It is possible to switch to outside air mode at any time by pressing

■

When the outside temperature is low

The dehumidification function may not operate even when

is pressed.

370

5-1. Using the air conditioning system and defogger

CAMRY_U

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning system to the outside air mode.

●

During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.

●

To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air

mode prior to turning the vehicle off.

• The start timing of the blower may be delayed for a short period of time

immediately after the air conditioning system is started in automatic
mode.

■

Air conditioning filter
P. 464

■

Customization
Some functions can be customized. (

P. 573)

WARNING

■

To prevent the windshield from fogging up

●

Do not use

during cool air operation in extremely humid weather.

The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.

■

To prevent burns (vehicles with outside rear view mirror defoggers)
Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.

NOTICE

■

To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the
engine is stopped.

●

Do not place anything on the instrument
panel  which  may  cover  the  air  outlets.
Otherwise,  air  flow  may  be  obstructed,
preventing  the  windshield  defoggers
from defogging.

371

5-1. Using the air conditioning system and defogger

rior

ures

CAMRY_U



Type A



Type B

Automatic air conditioning system

(with “SYNC” button)



: If equipped

Air outlets and fan speed are automatically adjusted according
to the temperature setting.

Air conditioning controls

372

5-1. Using the air conditioning system and defogger

CAMRY_U

■

Adjusting the temperature setting

To adjust the temperature setting, turn

clockwise to increase

the temperature and counterclockwise to decrease the tempera-
ture.

is not pressed, the system will blow ambient temperature air or

heated air.
The air conditioning system switches between individual and synchro-

nized modes each time

is pressed.

Synchronized modes (indicator on):

The driver’s side

dial can be used to adjust the temperature for

the driver’s and front passenger’s side. At this time, operate the front

passenger’s side

dial to enter individual mode.

Individual modes (indicator off):
The temperature for the driver’s and front passenger’s side can be
adjusted separately.

■

Fan speed setting

To adjust the fan speed, press

to increase the fan speed

and

to decrease the fan speed.

Press

to turn the fan off.

373

5-1. Using the air conditioning system and defogger

rior

ures

CAMRY_U

■

Change the airflow mode
To change the airflow mode,

press

The air outlets used are
switched each time the button is
pressed.

Air flows to the upper body.
Air  flows  to  the  upper  body
and feet.
Air flows to the feet.
Air  flows  to  the  feet  and  the
windshield  defogger  oper-
ates.

Press

The dehumidification function begins to operate. Air outlets and fan
speed are automatically adjusted according to the temperature set-
ting.
Adjust the temperature setting.

To stop the operation, press

■

Automatic mode indicator
If the fan speed setting or air flow modes are operated, the auto-
matic mode indicator goes off. However, automatic mode for func-
tions other than that operated is maintained.

Using automatic mode

374

5-1. Using the air conditioning system and defogger

CAMRY_U

■

Switching between outside air and recirculated air modes

Press

The mode switches between outside air mode (indicator off) and recir-

culated air mode (indicator on) each time

is pressed.

■

Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.

Press

The dehumidification function operates and fan speed increases.
Set the outside/recirculated air mode button to the outside air mode if
the recirculated air mode is used. (It may switch automatically.)
To defog the windshield and the side windows early, turn the air flow and
temperature up.

To return to the previous mode, press

again when the windshield

is defogged.

■

Defogging the rear window and outside rear view mirrors



Vehicles without outside rear view mirror defoggers

A defogger is used to defog the rear window.

Press

The defogger will automatically turn off after a period of time.



Vehicles with outside rear view mirror defoggers

Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.

Press

The defoggers will automatically turn off after a period of time.

Other functions

375

5-1. Using the air conditioning system and defogger

rior

ures

CAMRY_U

■

Location of air outlets
The air outlets and air volume
change

according

the

selected airflow mode.

■

Adjusting the position of and opening and closing the air out-
lets

Direct air flow to the left or right, up or down.
Turn the knob to open or close the vent.

Air outlets



Front



Rear

376

5-1. Using the air conditioning system and defogger

CAMRY_U

■

immediately after

is pressed.

■

Fogging up of the windows

●

The windows will easily fog up when the humidity in the vehicle is high.

Turning

on will dehumidify the air from the outlets and defog the

windshield effectively.

●

If you turn

off, the windows may fog up more easily.

●

The windows may fog up if the recirculated air mode is used.

■

Outside/recirculated air mode

●

Outside/recirculated air mode may automatically switch depending on the
temperature setting or the inside temperature.

■

When the outside temperature exceeds 75°F (24°C) and the air condition-
ing system is on

●

In order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.

●

Recirculated air mode is selected as a default mode when the engine switch
is turned to IGNITION ON mode.

●

It is possible to switch to outside air mode at any time by pressing

■

When the outside temperature is low

The dehumidification function may not operate even when

is pressed.

377

5-1. Using the air conditioning system and defogger

rior

ures

CAMRY_U

■

Operation of the air conditioning system in Eco drive mode (if equipped)

●

In the Eco drive mode, “ECO” is displayed on the air conditioning screen
and the air conditioning system is controlled as shown below to prioritize
fuel efficiency.
Fan speed restricted when automatic mode is selected

●

To improve air conditioning performance, perform the following operations:
• Adjust the fan speed
• Turn off Eco drive mode

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning system to the outside air mode.

●

During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.

●

To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air

mode prior to turning the vehicle off.

• The start timing of the blower may be delayed for a short period of time

immediately after the air conditioning system is started in automatic
mode.

■

Air conditioning filter
P. 464

■

Customization
Some functions can be customized. (

P. 573)

378

5-1. Using the air conditioning system and defogger

CAMRY_U

WARNING

■

To prevent the windshield from fogging up

●

Do not use

during cool air operation in extremely humid weather.

The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.

■

To prevent burns (vehicles with outside rear view mirror defoggers)
Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.

NOTICE

■

To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the
engine is stopped.

●

Do not place anything on the instrument
panel  which  may  cover  the  air  outlets.
Otherwise,  air  flow  may  be  obstructed,
preventing  the  windshield  defoggers
from defogging.

379

5-1. Using the air conditioning system and defogger

rior

ures

CAMRY_U

Each time the switch is pressed,
the operation condition changes
as follows.
Hi (3 segments lit)

 Mid (2 seg-

ments lit)

 Lo (1 segment lit) 

Off

The level indicator (amber) lights
up during operation.

Vehicles without a smart key system:
The seat heaters can be used when the engine switch is in the “ON” position.
Vehicles with a smart key system:
The seat heaters can be used when the engine switch is in IGNITION ON
mode.

Seat heaters



: If equipped

WARNING

●

Care should be taken to prevent injury if anyone in the following categories
comes in contact with the seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically chal-

lenged

• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping

drugs, cold remedies, etc.)

●

Observe the following precautions to prevent the minor burns or overheat-
ing
• Do not cover the seat with a blanket or cushion when using the seat

heater.

• Do not use seat heater more than necessary.

NOTICE

●

Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.

●

To prevent battery discharge, do not use the functions when the engine is
not running.

380

CAMRY_U

5-2. Using the interior lights

Front interior/personal lights (

P. 381 , 382)

Shift lever light (if equipped)
Inside door handle lights (if equipped)
Rear interior light (if equipped) (

P. 381)

Rear personal lights (if equipped) (

P. 382)

Door courtesy lights
Instrument panel ornament light (if equipped)
Front center console light (if equipped)
Footwell lights (if equipped)

Interior lights list

381

5-2. Using the interior lights

CAMRY_U

rior

ures

■

Front (if equipped)
The rear personal lights (if equipped) turn on/off together with the
front interior light.

Turns the lights on/off linked
to door positions
Turns the lights on/off

■

Rear (if equipped)

Turns the light off
Turns the light on/off linked to
door positions
Turns the light on

Interior lights

382

5-2. Using the interior lights

CAMRY_U

■

Front
Turns the lights on/off

■

Rear (if equipped)
Turns the lights on/off

●

Illuminated entry system:
Vehicles without a smart key system:
The lights automatically turn on/off according to the engine switch position,
whether the doors are locked/unlocked, and whether the doors are open/
closed.
Vehicles with a smart key system:
The lights automatically turn on/off according to the engine switch mode,
the presence of the electronic key, whether the doors are locked/unlocked,
and whether the doors are open/closed.

●

If the interior lights remain on when the engine switch is turned off, the lights
will go off automatically after 20 minutes.

●

Some functions can be customized. (

P. 573)

Personal lights

383

CAMRY_U

rior

ures

5-3. Using the storage features

List of storage features

Auxiliary boxes

(

P. 387)

Glove box

(

P. 384)

Bottle holders/door pockets

(

P. 385)

Cup holders

(

P. 386)

Console box

(

P. 384)

Auxiliary box/open tray

(

P. 387, 388)

Coin holder (if equipped)

(

P. 384)

WARNING

●

Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact

with other stored items.

• Lighters or spray cans may explode. If they come into contact with other

stored items, the lighter may catch fire or the spray can may release
gas, causing a fire hazard.

●

When driving or when the storage compartments are not in use, keep the
lids closed.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items stored inside.

384

5-3. Using the storage features

CAMRY_U

Unlock with the key (vehicles
without a smart key system) or
mechanical key (vehicles with a
smart key system)
Lock with the key (vehicles
without a smart key system) or
mechanical key (vehicles with a
smart key system)
Open (pull lever)

The glove box light turns on when the tail lights are on.

Push the knob.

Pull the lever to open.

Glove box

Console box

Coin holder (if equipped)

Content .. 22 23 24 25 ..
