5-2. Steps to take in an emergency
Stop the vehicle immediately.
The following warning indicates the possibility of damage to the vehi-
cle that may lead to an accident. Immediately stop the vehicle in a
safe place and contact your Toyota dealer.
Warning message
Details
Indicates that the engine is almost overheating.
(P. 449)
A buzzer also sounds.
(Comes on in red)
408
5-2. Steps to take in an emergency
Have the vehicle inspected immediately.
Failure to investigate the cause of the following warnings may lead to
the system operating abnormally and possibly cause an accident.
Have the vehicle inspected by your Toyota dealer immediately.
Warning message
Details
Indicates a malfunction in:
• The SRS airbag system;
• The seat belt pretensioner system;
• The front passenger occupant detection system.
A buzzer also sounds.
Indicates a malfunction in:
• The ABS;
• The brake assist system.
(U.S.A.)
A buzzer also sounds.
5
(Canada)
Indicates a malfunction in the EPS (Electric Power
Steering) system.
A buzzer also sounds.
409
5-2. Steps to take in an emergency
Warning message
Details
Indicates a malfunction in the smart key system.
A buzzer also sounds.
(Flashes)
(Flashes in yellow)
410
5-2. Steps to take in an emergency
Follow the correction procedures.
After taking the specified steps to correct the suspected problem,
check that the warning message and light go off.
Warning message
Details
Correction procedure
Indicates that one or
more of the doors is
not fully closed
The system also indi-
cates which doors are
not fully closed.
Make sure that both
If the vehicle reaches
side doors are closed.
a speed of 3 mph (5
km/h),
flashes to indicate that
the door(s) are not yet
fully closed.
Indicates that the trunk
is not fully closed
If the vehicle reaches
5
a speed of 3 mph (5
Close the trunk.
km/h),
flashes to indicate
that the trunk is not
yet fully closed.
411
5-2. Steps to take in an emergency
Warning message
Details
Correction procedure
Stop the vehicle in a
safe place and shift the
Indicates that the auto-
shift lever to P.
matic transmission fluid
If the message is
temperature is too
cleared after a little
high.
while, the vehicle can
A buzzer also
be driven. If the mes-
sounds.
sage is not cleared,
contact your Toyota
(Vehicles with an auto-
dealer.
matic transmission)
Indicates that the
“ENGINE START STOP”
switch is turned off and
the driver’s door is
Turn the lights off.
opened while the lights
are turned on.
(Flashes)
A buzzer also
sounds.
Indicates that remain-
ing fuel is approxi-
mately 1.8 gal. (7.0 L,
1.5 Imp. gal.) or less
The estimated
Refuel the vehicle.
remaining driving
range will be dis-
(Comes on in yellow)
played under this
warning message.*
Drive carefully avoiding
Roads may be icy due
sudden acceleration,
to the low outside tem-
sudden braking, sud-
perature.
den deceleration, and
sharp turns.
*:
This distance is computed based on your average fuel consumption. As a
result, the actual distance that can be driven may differ from that displayed.
412
5-2. Steps to take in an emergency
Have the malfunction repaired immediately.
After taking the specified steps to correct the suspected problem,
check that the warning message and light go off.
Interior
Exterior
Correction
Warning message
Details
buzzer
buzzer
procedure
Indicates that the
Confirm
electronic key is
the loca-
Once
not present when
tion of the
(Flashes)
attempting to
electronic
start the engine.
key.
(Flashes in yellow)
Indicates that a
door other than
the driver’s door
has been opened
and closed with
Confirm
the “ENGINE
the loca-
Once
3 times
START STOP”
tion of the
5
(Flashes)
switch in any
electronic
mode other than
key.
off and the elec-
(Flashes in yellow)
tronic key out-
side of the
detection area.
413
5-2. Steps to take in an emergency
Interior
Exterior
Correction
Warning message
Details
buzzer
buzzer
procedure
The electronic
key was carried
Turn the
outside the vehi-
“ENGINE
cle and the
START
driver’s door
STOP”
was opened
switch off
and closed
Once
3 times
(Flashes)
or bring
while the shift
the elec-
position P was
tronic key
(Flashes in yellow)
selected with-
back into
out turning off
(Vehicles with an auto-
the vehi-
the “ENGINE
matic transmission)
cle.
START STOP”
switch.
The electronic
key was carried
Turn the
outside the vehi-
“ENGINE
cle and the
START
driver’s door
STOP”
was opened
switch off
and closed
Once
3 times
or bring
(Flashes)
while the shift
the elec-
position N was
tronic key
(Flashes in yellow)
selected with-
back into
out turning off
(Vehicles with a manual
the vehi-
the “ENGINE
transmission)
cle.
START STOP”
switch.
414
5-2. Steps to take in an emergency
Interior
Exterior
Correction
Warning message
Details
buzzer
buzzer
procedure
An attempt was
made to exit the
Turn the
vehicle with the
“ENGINE
electronic key
Contin-
START
and touch the
uous
STOP”
Once
lock sensor to
(5 sec-
switch off
lock the doors
onds)
and lock
(Displayed alternately)
without first turn-
the doors
ing the “ENGINE
again.
(Flashes)
START STOP”
switch off.
(Flashes in yellow)
An attempt was
Confirm
made to drive
that the
Intermit-
when the regular
electronic
tently (7
key was not
key is
seconds)
(Flashes)
inside the vehi-
inside the
5
cle.
vehicle.
(Flashes in yellow)
415
5-2. Steps to take in an emergency
Interior
Exterior
Correction
Warning message
Details
buzzer
buzzer
procedure
The driver’s door
was opened
while any shift
position other
Shift the
Contin-
than P was
shift lever
uous
(Flashes)
selected without
to P.
turning off the
(Vehicles with an auto-
“ENGINE START
matic transmission)
STOP” switch.
The electronic
key was carried
outside the vehi-
• Shift the
cle and the
shift lever
driver’s door was
to P.
opened and
Contin-
Contin-
• Bring the
closed while any
uous
uous
electronic
(Displayed alternately)
shift position
key back
other than P was
into the
(Flashes)
selected without
vehicle.
turning off the
(Flashes in yellow)
“ENGINE START
STOP” switch.
(Vehicles with an auto-
matic transmission)
416
5-2. Steps to take in an emergency
Interior
Exterior
Correction
Warning message
Details
buzzer
buzzer
procedure
An attempt was
Retrieve
made to lock the
the elec-
Contin-
doors using the
tronic key
uous
smart key sys-
from the
(5 sec-
tem while the
vehicle
onds)
electronic key
and lock
(Flashes)
was still inside
the doors
the vehicle.
again.
An attempt was
made to lock
either door by
opening a door
Retrieve
and putting the
the elec-
Contin-
lock lever into the
tronic key
uous
lock position,
from the
Once
(5 sec-
then closing the
vehicle
onds)
door by pulling on
and lock
(Flashes)
the outside door
the doors
handle with the
again.
electronic key still
inside the vehi-
5
cle.
417
5-2. Steps to take in an emergency
Interior
Exterior
Correction
Warning message
Details
buzzer
buzzer
procedure
• When the doors
were unlocked
with the mechani-
cal key and then
the “ENGINE
Touch the
START STOP”
electronic
switch was
key to the
pressed, the
“ENGINE
electronic key
START
could not be
STOP”
Once
(Flashes)
detected in the
switch
vehicle.
while
(Flashes in yellow)
• The electronic
depress-
key could not be
ing the
(Vehicles with an auto-
detected in the
brake
matic transmission)
vehicle even after
pedal.
the “ENGINE
START STOP”
switch was
pressed two con-
secutive times.
418
5-2. Steps to take in an emergency
Interior
Exterior
Correction
Warning message
Details
buzzer
buzzer
procedure
• When the doors
were unlocked
with the mechani-
cal key and then
the “ENGINE
Touch the
START STOP”
electronic
switch was
key to the
pressed, the
“ENGINE
electronic key
START
could not be
STOP”
Once
(Flashes)
detected in the
switch
vehicle.
while
(Flashes in yellow)
• The electronic
depress-
key could not be
ing the
(Vehicles with a manual
detected in the
clutch
transmission)
vehicle even after
pedal.
the “ENGINE
START STOP”
switch was
pressed two con-
secutive times.
5
An attempt was
Shift the
made to start the
shift lever
Once
engine with the
to P and
shift lever in an
start the
(Flashes)
incorrect position.
engine.
(Vehicles with an auto-
matic transmission)
419
5-2. Steps to take in an emergency
Interior
Exterior
Correction
Warning message
Details
buzzer
buzzer
procedure
Next time
when
starting
the
engine,
increase
the engine
Power was
speed
turned off due to
slightly
the automatic
and main-
power off func-
tain that
tion.
level for
approxi-
mately 5
minutes to
recharge
the bat-
tery.
Replace
Indicates that the
the bat-
Once
electronic key
tery.
battery is low.
(P. 363)
(Flashes in yellow)
420
5-2. Steps to take in an emergency
Interior
Exterior
Correction
Warning message
Details
buzzer
buzzer
procedure
The driver’s door
was opened and
closed with the
Press the
“ENGINE START
“ENGINE
STOP” switch
START
turned off and
STOP”
then the
switch
“ENGINE START
while
STOP” switch
depress-
was put in
ing the
ACCESSORY
brake
mode twice with-
pedal.
out the engine
being started.
Once
Press the
(Flashes)
“ENGINE
During an engine
START
(Vehicles with an auto-
starting proce-
STOP”
matic transmission)
dure in the event
switch
that the electronic
while
key was not func-
depress-
5
tioning properly
ing the
(P. 441), the
brake
“ENGINE START
pedal
STOP” switch
within 10
was touched with
seconds
the electronic
of the
key.
buzzer
sounding.
421
5-2. Steps to take in an emergency
Interior
Exterior
Correction
Warning message
Details
buzzer
buzzer
procedure
The driver’s door
was opened and
closed with the
Press the
“ENGINE START
“ENGINE
STOP” switch
START
turned off and
STOP”
then the
switch
“ENGINE START
while
STOP” switch
depress-
was put in
ing the
ACCESSORY
clutch
mode twice with-
pedal.
out the engine
being started.
Once
Press the
(Flashes)
“ENGINE
During an engine
START
(Vehicles with a manual
starting proce-
STOP”
transmission)
dure in the event
switch
that the electronic
while
key was not func-
depress-
tioning properly
ing the
(P. 441), the
clutch
“ENGINE START
pedal
STOP” switch
within 10
was touched with
seconds
the electronic
of the
key.
buzzer
sounding.
422
5-2. Steps to take in an emergency
Interior
Exterior
Correction
Warning message
Details
buzzer
buzzer
procedure
Indicates that the
Release
steering lock has
the steer-
Once
not been
ing lock.
(Flashes)
released.
(P. 172)
(Flashes quickly in green)
The “ENGINE
START STOP”
Con-
switch has been
Shift the
tinu-
turned off with the
shift lever
ous
shift lever in a
to P.
(Flashes)
position other
(Vehicles with an auto-
than P.
matic transmission)
After the
“ENGINE START
STOP” switch
Turn the
5
has been turned
“ENGINE
Once
off with the shift
START
lever in a posi-
STOP”
(Flashes)
tion other than P,
switch off.
(Vehicles with an auto-
the shift lever has
matic transmission)
been shifted to P.
■ Warning buzzer
In some cases, the buzzer may not be heard because of noisy place or an
audio sound.
423
5-2. Steps to take in an emergency
If you have a flat tire
Your vehicle is equipped with a spare tire. The flat tire can be
replaced with the spare tire.
■ Before jacking up the vehicle
● Stop the vehicle in a safe place on a hard, flat surface.
● Set the parking brake.
● Shift the shift lever to P (vehicles with an automatic transmis-
sion) or R (vehicles with a manual transmission).
● Stop the engine.
● Turn on the emergency flashers. (P. 384)
■ Location of the spare tire, jack and tools
Jack handle
Towing eyelet
Wheel nut
Jack
wrench
Screwdriver
Spare tire
424
