Toyota Prius Plug-in Hybrid (2017 year). Manual - part 2
Pictorial index
17
5
Multi-information display
P. 215
Display
P. 215
Energy monitor
P. 218
When the warning messages are displayed
P. 650
6
Parking brake
P. 340
Applying/releasing
P. 340
Precautions against winter season
P. 498
Warning buzzer
P. 340
7
Turn signal lever
P. 339
Headlight switch
P. 341
Headlights/front position lights/tail lights/
daytime running lights
P. 341
Front fog lights/rear fog lights
P. 351
8
Windshield wipers and washer switch
P. 352
Usage
P. 352
Adding washer fluid
P. 578
9
Emergency flasher switch
P. 632
10
Fuel filler door opener
P. 357
11
Hood lock release lever
P. 563
12
Tilt and telescopic steering lock release lever
P. 302
13
Air conditioning system
P. 504
Usage
P. 504
Rear window defogger
P. 509
14
Audio system*
*: Refer to “Navigation system Owner’s manual”.
PRIUS PHV_OM_OM47A89E_(EE)
18
Pictorial index
■Switches (Left-hand drive vehicles)
1
Instrument cluster light control switch
P. 192
2
S-IPA (Simple Intelligent Parking Assist System)
switch*1
P. 459
3
VSC OFF switch
P. 493
4
Adaptive High-beam System switch
P. 346
5
“HUD” (Head-up display) switch*1
P. 251
6
Driving mode select switch
P. 412
7
EV/HV mode selection switch
P. 92
8
EV City mode switch
P. 92
9
Seat heater switches
P. 521
10
Charging timer switch
P. 166
11
Window lock switch
P. 307
12
Outside rear view mirror switches
P. 305
13
Door lock switches
P. 271
14
Power window switches
P. 307
PRIUS PHV_OM_OM47A89E_(EE)
Pictorial index
19
1
TRIP switch
P. 209
2
Audio remote control switches*2
3
Meter control switches
P. 191
4
Vehicle-to-vehicle distance switch
P. 404
5
LDA (Lane Departure Alert with steering control)
switch
P. 385
6
Cruise control switch
P. 397
7
Speed limiter switch
P. 414
8
Talk switch*2
9
Telephone switches*2
*1: If equipped
*2: Refer to “Navigation system Owner’s manual”.
PRIUS PHV_OM_OM47A89E_(EE)
20
Pictorial index
■Interior (Left-hand drive vehicles)
1
SRS airbags
P. 39
2
Floor mats
P. 30
3
Front seats
P. 296
4
Rear seats
P. 297
5
Head restraints
P. 299
6
Seat belts
P. 34
7
Console box
P. 526
8
Inside lock buttons
P. 271
9
Cup holders
P. 527
10
Assist grips
P. 543
PRIUS PHV_OM_OM47A89E_(EE)
Pictorial index
21
1
Inside rear view mirror
P. 304
2
Sun visors*1
P. 535
3
Vanity mirrors
P. 535
4
Interior lights*2
P. 523, 524
Personal lights
P. 523
*1: NEVER use a rearward facing child
restraint on a seat protected by an
ACTIVE AIRBAG in front of it,
DEATH or SERIOUS INJURY to the
CHILD can occur. (P. 60)
*2: The illustration shows the front, but they are also equipped in the rear.
PRIUS PHV_OM_OM47A89E_(EE)
22
Pictorial index
■Instrument panel (Right-hand drive vehicles)
1
Power switch
P. 327
Starting the hybrid system/changing the modes
P. 327
Emergency stop of the hybrid system
P. 633
When the hybrid system will not start
P. 676
Warning messages
P. 650
2
Shift lever
P. 333
Changing the shift position
P. 333
Precautions against towing
P. 634
3
P position switch
P. 334
4
Meters
P. 190
Reading the meters/adjusting the instrument
cluster light
P. 190, 192
Warning lights/indicator lights
P. 199
When the warning lights come on
P. 641
PRIUS PHV_OM_OM47A89E_(EE)
Pictorial index
23
5
Multi-information display
P. 215
Display
P. 215
Energy monitor
P. 218
When the warning messages are displayed
P. 650
6
Parking brake
P. 340
Applying/releasing
P. 340
Precautions against winter season
P. 498
Warning buzzer
P. 340
7
Turn signal lever
P. 339
Headlight switch
P. 341
Headlights/front position lights/tail lights/
daytime running lights
P. 341
Front fog lights/rear fog lights
P. 351
8
Windshield wipers and washer switch
P. 352
Usage
P. 352
Adding washer fluid
P. 578
9
Emergency flasher switch
P. 632
10
Fuel filler door opener
P. 357
11
Hood lock release lever
P. 563
12
Tilt and telescopic steering lock release lever
P. 302
13
Air conditioning system
P. 504
Usage
P. 504
Rear window defogger
P. 509
14
Audio system*
*: Refer to “Navigation system Owner’s Manual”.
PRIUS PHV_OM_OM47A89E_(EE)
24
Pictorial index
■Switches (Right-hand drive vehicles)
1
EV/HV mode selection switch
P. 92
2
EV City mode switch
P. 92
3
Driving mode select switch
P. 412
4
S-IPA (Simple Intelligent Parking Assist System)
switch*1
P. 459
5
VSC OFF switch
P. 493
6
“HUD” (Head-up display) switch*1
P. 251
7
Adaptive High-beam System switch
P. 346
8
Outside rear view mirror switches
P. 305
9
Window lock switch
P. 307
10
Power window switches
P. 307
11
Door lock switches
P. 271
12
Charging timer switch
P. 166
13
Seat heater switches
P. 521
PRIUS PHV_OM_OM47A89E_(EE)
Pictorial index
25
1
TRIP switch
P. 209
2
Audio remote control switches*2
3
Meter control switches
P. 191
4
Vehicle-to-vehicle distance switch
P. 404
5
LDA (Lane Departure Alert with steering control)
switch
P. 385
6
Cruise control switch
P. 397
7
Speed limiter switch
P. 414
8
Talk switch*2
9
Telephone switches*2
*1: If equipped
*2: Refer to “Navigation system Owner’s manual”.
PRIUS PHV_OM_OM47A89E_(EE)
26
Pictorial index
■Interior (Right-hand drive vehicles)
1
SRS airbags
P. 39
2
Floor mats
P. 30
3
Front seats
P. 296
4
Rear seats
P. 297
5
Head restraints
P. 299
6
Seat belts
P. 34
7
Console box
P. 526
8
Inside lock buttons
P. 271
9
Cup holders
P. 527
10
Assist grips
P. 543
PRIUS PHV_OM_OM47A89E_(EE)
Pictorial index
27
1
Inside rear view mirror
P. 304
2
Sun visors*1
P. 535
3
Vanity mirrors
P. 535
4
Interior lights*2
P. 523, 524
Personal lights
P. 523
*1: NEVER use a rearward facing child
restraint on a seat protected by an
ACTIVE AIRBAG in front of it,
DEATH or SERIOUS INJURY to the
CHILD can occur. (P. 60)
*2: The illustration shows the front, but they are also equipped in the rear.
PRIUS PHV_OM_OM47A89E_(EE)
28
Pictorial index
PRIUS PHV_OM_OM47A89E_(EE)
29
For safety and security
1
1-1. For safe use
Before driving
30
For safety drive
32
Seat belts
34
SRS airbags
39
Exhaust gas precautions
50
1-2. Child safety
Airbag manual on-off
system
51
Riding with children
53
Child restraint systems
54
1-3. Theft deterrent system
Immobilizer system
75
Double locking system
80
Alarm
81
PRIUS PHV_OM_OM47A89E_(EE)
30
1-1. For safe use
Before driving
Floor mat
Use only floor mats designed specifically for vehicles of the same
model and model year as your vehicle. Fix them securely in place
onto the carpet.
Insert the retaining hooks (clips)
1
into the floor mat eyelets.
Turn the upper knob of each
2
retaining hook (clip) to secure
the floor mats in place.
*
*: Always align the
marks.
The shape of the retaining hooks (clips) may differ from that shown in the
illustration.
PRIUS PHV_OM_OM47A89E_(EE)
1-1. For safe use
31
WARNING
Observe the following precautions.
Failure to do so may cause the driver’s floor mat to slip, possibly interfering
with the pedals while driving. An unexpectedly high speed may result or it may
become difficult to stop the vehicle. This could lead to an accident, resulting in
death or serious injury.
1
■ When installing the driver’s floor mat
●Do not use floor mats designed for other models or different model year
vehicles, even if they are Toyota Genuine floor mats.
●Only use floor mats designed for the driver’s seat.
● Always install the floor mat securely using the retaining hooks (clips) pro-
vided.
●Do not use two or more floor mats on top of each other.
●Do not place the floor mat bottom-side up or upside-down.
■ Before driving
●Check that the floor mat is securely
fixed in the correct place with all the
provided retaining hooks
(clips). Be
especially careful to perform this check
after cleaning the floor.
●With the hybrid system stopped and the
shift position in P, fully depress each
pedal to the floor to make sure it does
not interfere with the floor mat.
PRIUS PHV_OM_OM47A89E_(EE)
32
1-1. For safe use
For safety drive
For safe driving, adjust the seat and mirror to an appropriate
position before driving.
Correct driving posture
Adjust the angle of the seat-
1
back so that you are sitting
straight up and so that you do
not have to lean forward to
steer. (P. 296)
Adjust the seat so that you can
2
depress the pedals fully and so
that your arms bend slightly at
the elbow when gripping the
steering wheel. (P. 296)
Lock the head restraint in place with the center of the head restraint
3
closest to the top of your ears. (P. 299)
Wear the seat belt correctly. (P. 34)
4
Correct use of the seat belts
Make sure that all occupants are wearing their seat belts before driv-
ing the vehicle. (P. 34)
Use a child restraint system appropriate for the child until the child
becomes large enough to properly wear the vehicle’s seat belt.
(P. 54)
Adjusting the mirrors
Make sure that you can see backward clearly by adjusting the inside
and outside rear view mirrors properly. (P. 304, 305)
PRIUS PHV_OM_OM47A89E_(EE)
1-1. For safe use
33
WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.
●Do not adjust the position of the driver’s seat while driving.
Doing so could cause the driver to lose control of the vehicle.
●Do not place a cushion between the driver or passenger and the seatback.
1
A cushion may prevent correct posture from being achieved, and reduce
the effectiveness of the seat belt and head restraint.
●Do not place anything under the front seats.
Objects placed under the front seats may become jammed in the seat
tracks and stop the seat from locking in place. This may lead to an acci-
dent and the adjustment mechanism may also be damaged.
● Always observe the legal speed limit when driving on public roads.
●When driving over long distances, take regular breaks before you start to
feel tired.
Also, if you feel tired or sleepy while driving, do not force yourself to con-
tinue driving and take a break immediately.
PRIUS PHV_OM_OM47A89E_(EE)
