578
9-2. Customization
Customizable features
Your vehicle includes a variety of electronic features that can be
personalized to your preferences. The settings of these features
can be changed using the meter control switches, on the naviga-
tion/multimedia system screen or at any authorized Toyota
dealer or repairer, or another duly qualified and equipped pro-
fessional.
Customizing vehicle features
■ Changing on the navigation/multimedia system screen (vehi-
cles with a navigation/multimedia system)
1
Press the “SETUP” button.
2
Touch “Vehicle” on the “Setup” screen.
Select the desired item.
Various settings can be changed. Refer to the list of settings that
can be changed for details.
■ Changing using the meter control switches
P. 108
Customizable features
Some function settings are changed simultaneously with other func-
tions when customized. Contact any authorized Toyota dealer or
repairer, or another duly qualified and equipped professional for fur-
ther details.
Settings that can be changed on the navigation/multimedia system
1
screen (vehicles with a navigation/multimedia system)
Settings that can be changed using the meter control switches
2
Settings that can be changed by any authorized Toyota dealer or
3
repairer, or another duly qualified and equipped professional
Definition of symbols: O = Available, — = Not available
AURIS HV Touring
Sports_EE
(OM12L18E)
9-2. Customization
579
■ Gauges, meters and multi-information display (P. 102, 105)
Customized
Function*1
Default setting
setting
1
2
3
Language*2
English
*3
—
O
—
km (km/L)
km (L/100 km)
O
O
—
Units*2
miles (MPG)
°C
°F
O
O
—
EV indicator
On (Self-lighting)
Off
—
O
—
Current fuel consump-
tion (gauge display)
Drive information 1
*4
—
O
—
Average fuel economy
(after reset)
Distance
(driving range)
Drive information 2
*4
—
O
—
Average vehicle speed
(after reset)
Average fuel economy
(after start)
Drive information 3
*4
—
O
—
Distance
(after start)
Pop-up display*5
On
Off
—
O
—
*
1: For details about each function: P. 111
*2: The default setting varies according to country.
*3: German, French, Spanish, Italian, Portuguese, Dutch, Swedish, Norwe-
gian, Danish, Russian, Finnish, Greek, Polish, Ukrainian, Turkish, Hungar-
ian, Czech, Slovak, Romanian
9
*4: 2 of the following items: current fuel consumption (gauge display), current
fuel consumption (numerical display), average fuel economy (after reset),
average fuel economy (after start), average fuel economy (after refuel),
average vehicle speed (after reset), average vehicle speed (after start),
elapsed time (after reset), elapsed time (after start), distance
(driving
range), distance (after start), blank.
*5: If equipped
AURIS HV Touring
Sports_EE
(OM12L18E)
580
9-2. Customization
■ Smart entry & start system* and wireless remote control
(P. 124, 129, 134)
Customized
Function
Default setting
1
2
3
setting
Operation signal
On
Off
O
—
O
(Emergency flashers)
Time elapsed before
60 seconds
automatic door lock func-
tion is activated if door is
30 seconds
—
—
O
120 seconds
not opened after being
unlocked
Open door warning
On
Off
—
—
O
buzzer
*: If equipped
■ Smart entry & start system*1 (P. 124, 129, 134)
Customized
Function
Default setting
1
2
3
setting
Smart entry & start sys-
On
Off
O
—
O
tem
Number of consecutive
As many as
2 times
—
—
O
door lock operations*2
desired
*1: If equipped
*2: Left-hand drive vehicles
■ Push button start* (P. 155)
Customized
Function
Default setting
setting
1
2
3
Push button start
On
Off
O
—
O
*: If equipped
■ Wireless remote control (P. 120, 124)
Customized
Function
Default setting
setting
1
2
3
Wireless remote control
On
Off
—
—
O
AURIS HV Touring
Sports_EE
(OM12L18E)
9-2. Customization
581
■ Turn signal lever (P. 232)
Customized
Function
Default setting
setting
1
2
3
The number of times the
5
turn signal lights flash
automatically when the
3
7
—
—
O
turn signal lever is moved
to the first position during
a lane change
Off
■ Automatic light control system* (P. 234)
Customized
Function
Default setting
setting
1
2
3
Light sensor sensitivity
Standard
-2 to 2
O
—
O
*: If equipped
■ Follow me home system (P. 236)
Customized set-
Function
Default setting
ting
1
2
3
60 seconds
Time elapsed before
headlights automatically
30 seconds
90 seconds
—
—
O
turn off
120 seconds
■ LDA (Lane Departure Alert)* (P. 270)
Customized
Function
Default setting
setting
1
2
3
LDA warning sensitivity
High
Standard
—
O
—
*: If equipped
9
AURIS HV Touring
Sports_EE
(OM12L18E)
582
9-2. Customization
■ RSA (Road Sign Assist)* (P. 279)
Customized
Function
Default setting
setting
1
2
3
RSA system
On
Off
—
O
—
Display and
Notification method of
buzzer
Only display
—
O
—
excessive speed
Off
Display and
Notification
methods
buzzer
other than excessive
Only display
—
O
—
speed
Off
10 km/h (5 mph)
Notification
level
of
2 km/h (1 mph)
—
O
—
excessive speed
5 km/h (3 mph)
*: If equipped
■ Toyota parking assist-sensor*1 (P. 289)
Customized
Function
Default setting
setting
1
2
3
Toyota parking assist-
On
Off
—
O
—
sensor system
Detection distance of the
Far
Near
O
—
O
front center sensors*2
Detection distance of the
Far
Near
O
—
O
rear center sensors*2
Buzzer volume*2
5
1 to 4
O
—
O
All sensors
Display setting*2, 3
Display off
O
—
O
displayed
*
1: If equipped
*2: Vehicles with a navigation/multimedia system
*3: When Toyota parking assist-sensor is operating.
AURIS HV Touring
Sports_EE
(OM12L18E)
9-2. Customization
583
■ Automatic air conditioning system (P. 386)
Customized
Function
Default setting
setting
1
2
3
Switching between out-
side air and recirculated
On
Off
O
—
O
air
mode linked to
“AUTO” switch operation
■ Illumination (P. 396)
Customized
Function
Default setting
setting
1
2
3
Interior light illumination
On
Off
O
—
O
control*
7.5 seconds
Time elapsed before the
15 seconds
O*
—
O
interior lights turn off
30 seconds
Operation after the power
On
Off
—
—
O
switch is turned off
Operation when the
On
Off
—
—
O
doors are unlocked
Operation when you
approach the vehicle with
On
Off
—
—
O
the electronic key on your
person*
*: If equipped
■ Reverse warning buzzer (P. 228)
Customized
Function
Default setting
1
2
3
setting
Operation
signals
9
Beeps
(Buzzer) when shifting
Beeps once
—
—
O
repeatedly
into R
AURIS HV Touring
Sports_EE
(OM12L18E)
584
9-2. Customization
■ Vehicle customization
When the doors remain closed after unlocking the doors and the timer acti-
vated automatic door lock function activates, signals will be generated in
accordance with the operational signal (emergency flashers) function setting.
WARNING
■ During customization
As the engine needs to be running during customization, ensure that the
vehicle is parked in a place with adequate ventilation. In a closed area such
as a garage, exhaust gases including harmful carbon monoxide (CO) may
collect and enter the vehicle. This may lead to death or a serious health
hazard.
NOTICE
■ During customization
To prevent 12-volt battery discharge, ensure that the hybrid system is oper-
ating while customizing features.
AURIS HV Touring
Sports_EE
(OM12L18E)
9-3. Initialization
585
Items to initialize
The following item must be initialized for normal system opera-
tion after such cases as the 12-volt battery being reconnected,
or maintenance being performed on the vehicle:
Item
When to initialize
Reference
• When rotating front and rear
tires which have different tire
inflation pressures
Tire pressure warning sys-
• When changing the tire size
P. 453
tem*
• When changing the tire infla-
tion pressure by changing
traveling speed or load
weight, etc.
*: If equipped
9
AURIS HV Touring
Sports_EE
(OM12L18E)
586
9-3. Initialization
AURIS HV Touring
Sports_EE
(OM12L18E)
587
Index
What to do if...
(Troubleshooting)
588
Alphabetical index
591
AURIS HV Touring
Sports_EE
(OM12L18E)
588
What to do if... (Troubleshooting)
What to do if... (Troubleshooting)
If you have a problem, check the following before contacting any
authorized Toyota dealer or repairer, or another duly qualified
and equipped professional.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
● If you lose your keys or mechanical keys, new genuine keys or mechanical
keys can be made by any authorized Toyota dealer or repairer, or another
duly qualified and equipped professional. (P. 121)
● If you lose your keys or electronic keys, the risk of vehicle theft increases
significantly. Contact any authorized Toyota dealer or repairer, or another
duly qualified and equipped professional immediately. (P. 123)
The doors cannot be locked or unlocked
● Is the key battery weak or depleted? (P. 471)
● Vehicles with a smart entry & start system:
Is the power switch in ON mode?
When locking the doors, turn the power switch off. (P. 218)
● Vehicles with a smart entry & start system:
Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
● The function may not operate properly due to the condition of the radio
wave. (P. 137, 157)
The rear door cannot be opened
● Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. (P. 127)
AURIS HV Touring
Sports_EE
(OM12L18E)
What to do if... (Troubleshooting)
589
If you think something is wrong
The hybrid system does not start
● Did you press the power switch while firmly depressing the brake pedal?
(P. 216)
● Is the shift position in P? (P. 216)
● Is the electronic key anywhere detectable inside the vehicle?
(P. 134, 156)
● Is the electronic key battery weak or depleted?
In this case, the hybrid system can be started in a temporary way.
(P. 548)
● Is the 12-volt battery discharged? (P. 551)
The windows do not open or close by operating the power
window switches
● Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. (P. 187)
The power switch is turned off automatically
● The auto power off function will be operated if the vehicle is left in ACCES-
SORY or ON mode (the hybrid system is not operating) for a period of
time. (P. 219)
A warning buzzer sounds during driving
● The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? (P. 506)
● The brake system warning light (red indicator) is on
Is the parking brake released? (P. 233)
Depending on the situation, other types of warning buzzer may also sound.
(P. 503, 511)
AURIS HV Touring
Sports_EE
(OM12L18E)
590
What to do if... (Troubleshooting)
An alarm is activated and the horn sounds
(vehicles with an alarm)
● Did anyone inside the vehicle open a door or anything move inside the
vehicle* during setting the alarm?
The sensor detects them and the alarm sounds. (P. 89)
*: If the vehicle is equipped with intrusion sensor.
To stop the alarm, turn the power switch to ON mode or start the hybrid
system.
A warning buzzer sounds when leaving the vehicle
(vehicles with a smart entry & start system)
● Is the electronic key left inside the vehicle?
Check the message on the multi-information display. (P. 511)
A warning light turns on or a warning message is displayed
● When a warning light turns on or a warning message is displayed, refer to
P. 503, 511.
When a problem has occurred
If you have a flat tire
● Vehicles with a spare tire:
Stop the vehicle in a safe place and replace the flat tire with the spare tire.
(P. 520)
● Vehicles with an emergency tire puncture repair kit:
Stop the vehicle in a safe place and repair the flat tire temporarily with the
emergency tire puncture repair kit. (P. 532)
The vehicle becomes stuck
● Try the procedure for when the vehicle becomes stuck in mud, dirt, or
snow. (P. 560)
AURIS HV Touring
Sports_EE
(OM12L18E)
Alphabetical index
591
Alphabetical index
A
Alarm
89
A/C
386
Warning buzzer
503, 511
Air conditioning filter
469
Anchor brackets
60
ABS
Antennas
(Anti-lock Brake System)
310
(push button start)
134
Warning light
504
Antennas (smart entry &
Air conditioning filter
469
start system)
155
Air conditioning
Anti-lock Brake
system
386
System (ABS)
310
Air conditioning filter
469
Warning light
504
Airbag manual on-off system ... 48
Armrest
420
Airbags
38
Ashtrays
418
Airbag manual on-off
Assist grips
420
system
48
Audio input*
326
Airbag operating conditions
44
Audio system*
324
Airbag precautions for
Audio input
326
your child
40
AUX port/USB port
326
Correct driving posture
32
Bluetooth® audio
356
Curtain shield airbag
CD player
332
operating conditions
44
iPod
340
Curtain shield airbag
MP3/WMA disc
332
precautions
42
Optimal use
327
General airbag precautions
40
Portable music player
355
Locations of airbags
38
Radio
329
Modification and
Steering wheel audio
disposal of airbags
43
switch
325
Side airbag operating
USB memory
348
conditions
44
Automatic headlight leveling
Side airbag precautions
40
system
239
Side and curtain shield airbags
Automatic High Beam
275
operating conditions
44
Automatic light control
Side and curtain shield airbags
system
234
precautions
40
AUX port*
326
SRS airbags
38
Auxiliary boxes
404, 409
SRS warning light
504
*: For vehicles with navigation/multimedia system, refer to “Navigation
and multimedia system Owner’s manual”.
AURIS HV Touring
Sports_EE
(OM12L18E)
592
Alphabetical index
B
Child restraint system
51
Back door
129
Baby seats, definition
51
Back-up lights
Baby seats, installation
61
Replacing light bulb
479
Child seats, definition
51
Wattage
575
Child seats, installation
61
Battery (12-volt battery)
446
Installing CRS with ISOFIX
Battery checking
446
rigid anchors
65
If the 12-volt battery is
Installing CRS with
discharged
551
seat belts
61
Preparing and checking
Installing CRS with top strap... 66
before winter
319
Junior seats, definition
51
Battery (traction battery)
75
Junior seats, installation
63
Bluetooth®*
Child safety
50
Audio system
373
12-volt battery
Hands-free system
precautions
449, 555
(for cellular phone)
376
Airbag precautions
40
Bottle holders
402
Child restraint system
51
Brake
How your child should wear
Emergency brake signal
311
the seat belt
35
Fluid
571
Installing child restraints
60
Parking brake
233
Panoramic roof shade
Warning light
503
precautions
422
Brake assist
310
Power window lock switch
187
Break-in tips
193
Power window precautions...189
Brightness control
Rear door child-protectors
127
Meter light control
111
Removed electronic key
battery precautions
472
Seat belt precautions
37
C
Seat heater precautions
395
Care
424, 428
Child-protectors
127
Aluminum wheels
425
Exterior
424
Interior
428
Seat belts
429
Cargo hooks
405
CD player*
332
Chains
320
AURIS HV Touring
Sports_EE
(OM12L18E)
Alphabetical index
593
Cleaning
424, 428
Do-it-yourself maintenance
434
Aluminum wheels
425
Door lock
Exterior
424
Back door
129
Interior
428
Side doors
124
Seat belts
429
Smart entry & start
Clock
418
system
124, 129
Coat hooks
421
Wireless remote control
124
Condenser
444
Doors
Console box
401
Back door
129
Cooling system
443
Door lock
124, 129
Hybrid system overheating ...556
Door windows
187
Cruise control
285
Double locking system
95
Cup holders
403
Open door warning
Curtain shield airbags
38
buzzer
127, 130
Customizable features
578
Outside rear view mirrors
184
Rear door child-protector
127
Side doors
124
D
Double locking system
95
Daytime running light
Drive information
109
system
238
Deck board
406
Defogger
Outside rear view mirrors
390
Rear window
390
Windshield
390
Dimensions
564
Display
Multi-information display
105
Warning message
511
*: For vehicles with navigation/multimedia system, refer to “Navigation
and multimedia system Owner’s manual”.
AURIS HV Touring
Sports_EE
(OM12L18E)
594
Alphabetical index
Driving
192
If your vehicle becomes
Break-in tips
193
stuck
560
Correct driving posture
32
If your vehicle has to be
Hybrid vehicle driving tips
316
stopped in an emergency ... 495
Procedures
192
If your vehicle needs to be
Winter drive tips
319
towed
496
If your vehicle
overheats
556
E
Emergency brake signal
311
ECB (Electronically
Emergency flashers
494
Controlled Brake System)
310
Emergency tire puncture
Eco drive mode
227
repair kit
532
Electric motor
Energy monitor
114
(traction motor)
71
Engine
566
Electric Power Steering
ACCESSORY mode
218
(EPS)
311
Compartment
439
Warning light
504
Engine switch
216
Electronic key
120
Hood
436
Battery-saving
How to start the hybrid
function
136, 156
system
216
If the electronic key does not
Identification number
565
operate properly
548
If the hybrid system
Replacing the battery
471
will not start
546
Electronically Controlled
Ignition switch
Brake System (ECB)
310
(power switch)
216
Emergency, in case of
Overheating
556
If a warning buzzer
Power switch
216
sounds
503
Engine coolant
443
If a warning light turns on
503
Capacity
570
If a warning message is
Checking
443
displayed
511
Preparing and checking
If the 12-volt battery is
before winter
319
discharged
551
Warning light
504
If the electronic key does
Engine oil
440
not operate properly
548
Capacity
567
If the hybrid system
Checking
440
will not start
548
Preparing and checking
If you have a flat tire
520, 532
before winter
319
If you think something is
Engine switch
216
wrong
502
AURIS HV Touring
Sports_EE
(OM12L18E)
