5-6. Using Bluetooth® devices
357
Device registration/connection flow
1. Register a Bluetooth® device to be used with the audio
system (P. 362)
2. Connect a registered Bluetooth® device to be used
(P. 363, 364)
3. Set automatic connection of the device
(P. 366)
4. Check the Bluetooth® connection condition
5
(P. 358)
To be used for audio
To be used for hands-free phone
5. Use Bluetooth® audio
5. Use Bluetooth® phone
(P. 373)
(P. 376)
AURIS HV Touring
Sports_EE
(OM12L18E)
358
5-6. Using Bluetooth® devices
Audio unit
1
Bluetooth® connection status
If
“BT” is not displayed, the
Bluetooth® audio/phone cannot
be used.
2
Display
A message, name, number, etc.
is displayed.
Lower-case characters and special
characters cannot be displayed.
3
Displays the set up menu/inputs the selected item
4
Select items such as menu and number
5
Off-hook switch
Turns the hands-free system on/starts a call
6
On-hook switch
Turns the hands-free system off/ends a call/refuses a call
Displays information that is too long to be displayed at one time on
7
the display (press and hold)
Select speed dials
8
Microphone
AURIS HV Touring
Sports_EE
(OM12L18E)
5-6. Using Bluetooth® devices
359
Menu list of the Bluetooth® audio/phone
To enter a menu, press the “SETUP/ENTER” button and navigate
menus by using the “<SELECT”, “TUNE>” and “SETUP/ENTER” but-
tons:
First menu
Second menu
Third menu
Operation details
Register
a
“Pairing”
-
Bluetooth®
device
List the regis-
“List phone”
-
tered
cellular
phones
List the regis-
“List audio”
-
tered
portable
players
Change
the
“Passkey”
-
passkey
“Bluetooth*”
Set
automatic
5
“BT power”
-
connection of the
device on or off
“Device Name”
Display
the
“Bluetooth* info”
“Device
device status
Address”
Set the auto-
matic connec-
“Display setting”
-
tion confirmation
display on or off
Initialize the set-
“Reset”
-
tings
AURIS HV Touring
Sports_EE
(OM12L18E)
360
5-6. Using Bluetooth® devices
First menu
Second menu
Third menu
Operation details
Add a new num-
“Add contacts”
ber
Register a speed
“Add SD”
dial
Delete a number
“Delete call his-
stored in the call
“Phonebook”
tory”
history
Delete a number
“Delete contacts”
stored in the
“PHONE”
or
phonebook
“TEL”
“Delete
other
Delete a phone-
PB”
book’s data
“Call volume”
Set call volume
“HF sound set-
“Ringtone vol-
Set ringtone vol-
ting”
ume”
ume
“Ringtone”
Set the ringtone
Transfer the call
“Transfer history”
-
histories
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
■Bluetooth® audio/phone system functions
Depending on the Bluetooth® device, certain functions may not be available.
AURIS HV Touring
Sports_EE
(OM12L18E)
5-6. Using Bluetooth® devices
361
Using the steering wheel switches
The steering wheel switches can be used to operate a connected
cellular phone or portable digital audio player (portable player).
Operating a Bluetooth® phone using the steering wheel switches
1
Volume
The voice guidance volume
cannot be adjusted using these
buttons.
Off-hook switch
2
Turns the hands-free system
on/starts a call
On-hook switch
3
Turns the hands-free system off/ends a call/refuses a call
4
Talk switch
5
A message will be displayed.
AURIS HV Touring
Sports_EE
(OM12L18E)
362
5-6. Using Bluetooth® devices
Registering a Bluetooth® device
Before using the Bluetooth® audio/phone, it is necessary to reg-
ister a Bluetooth® device in the system. You can register up to 5
Bluetooth® devices.
How to register a Bluetooth® device
1
Press the “SETUP/ENTER” button and select “Bluetooth*” using
the “<SELECT” or “TUNE>” button.
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
2
Press the “SETUP/ENTER” button and select “Pairing” using the
“<SELECT” or “TUNE>” button.
A passkey will be displayed.
3
SSP (Secure Simple Pairing) incompatible Bluetooth® devices:
Input the passkey into the device.
SSP (Secure Simple Pairing) compatible Bluetooth® devices:
Select
“Yes” to register the device. Depending on the type of
device, it may register automatically.
If a Bluetooth® device has both music player and cellular phone func-
tions, both functions will be registered at the same time. When delet-
ing the device, both functions will be deleted at the same time.
If the off-hook switch is pressed and the “PHONE” or “TEL” mode is
entered when no phones have been registered, the registration
screen will be automatically displayed.
AURIS HV Touring
Sports_EE
(OM12L18E)
5-7. “SET UP” menu
363
Using the “SET UP” menu (“Bluetooth*”
menu)
Registering a Bluetooth® device in the system allows the system
to function. The following functions can be used for registered
devices:
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Registering a portable player
Select
“Pairing” using the
“<SELECT”,
“TUNE>” and
“SETUP/
ENTER” buttons (P. 359), and perform the procedure for registering
a portable player. (P. 362)
Listing the registered cellular phones
Select “List phone” using the “<SELECT”, “TUNE>” and “SETUP/
ENTER” buttons. (P. 359) The list of registered cellular phones will
5
be displayed.
● Connecting the registered cellular phone to the audio system
Select the name of the cellular phone to be connected using the
1
“<SELECT”, “TUNE>” and “SETUP/ENTER” buttons.
Select “Select” using the “<SELECT”, “TUNE>” and “SETUP/
2
ENTER” buttons.
● Deleting a registered cellular phone
1
Select the name of the cellular phone to be deleted using the
“<SELECT”, “TUNE>” and “SETUP/ENTER” buttons.
2
Select “Delete” using the “<SELECT”, “TUNE>” and “SETUP/
ENTER” buttons.
3
Press
“Yes”.
AURIS HV Touring
Sports_EE
(OM12L18E)
364
5-7. “SET UP” menu
● Disconnecting the registered cellular phone from the audio system
Select the name of the cellular to be disconnected using the
1
“<SELECT”, “TUNE>” and “SETUP/ENTER” buttons.
2
Select
“Disconnect” using the
“<SELECT”,
“TUNE>” and
“SETUP/ENTER” buttons.
3
Press
“Yes”.
Listing the registered portable players
Select “List audio” using the
“<SELECT”, “TUNE>” and “SETUP/
ENTER” buttons. (P. 359) The list of registered portable players will
be displayed.
● Connecting the registered portable player to the audio system
Select the name of the portable player to be connected using the
1
“<SELECT”, “TUNE>” and “SETUP/ENTER” buttons.
Select “Select” using the “<SELECT”, “TUNE>” and “SETUP/
2
ENTER” buttons.
● Deleting the registered portable player
1
Select the name of the portable player to be deleted using the
“<SELECT”, “TUNE>” and “SETUP/ENTER” buttons.
2
Select “Delete” using the “<SELECT”, “TUNE>” and “SETUP/
ENTER” buttons.
3
Press
“Yes”.
AURIS HV Touring
Sports_EE
(OM12L18E)
5-7. “SET UP” menu
365
● Disconnecting the registered portable player from the audio system
Select the name of the portable player to be disconnected using
1
the “<SELECT”, “TUNE>” and “SETUP/ENTER” buttons.
2
Select
“Disconnect” using the
“<SELECT”,
“TUNE>” and
“SETUP/ENTER” buttons.
3
Press
“Yes”.
● Selecting the connection method
Select the name of the desired portable player using the
1
“<SELECT”, “TUNE>” and “SETUP/ENTER” buttons.
Select “Connection method” using the “<SELECT”, “TUNE>” and
2
“SETUP/ENTER” buttons.
Select “From vehicle” or “From audio” using the “<SELECT”,
3
“TUNE>” and “SETUP/ENTER” buttons.
Changing the passkey
1
Select “Passkey” using the “<SELECT”, “TUNE>” and “SETUP/
5
ENTER” buttons. (P. 359)
2
Input a 4 to 8-digit passkey using the “<SELECT”, “TUNE>” and
“SETUP/ENTER” buttons.
Input the number 1 digit at a time.
3
When the entire number to be registered as a passkey has been
input, press
“Enter”.
If the passkey to be registered has 8 digits, pressing
“Enter” is not
necessary.
AURIS HV Touring
Sports_EE
(OM12L18E)
366
5-7. “SET UP” menu
Setting automatic connection of the device on or off
If
“BT power” is set to on, the registered device will be connected
automatically when the power switch is turned to ACCESSORY
mode.
1
Select “BT power” using the “<SELECT”, “TUNE>” and “SETUP/
ENTER” buttons. (P. 359)
Select “On” or “Off” using the “SETUP/ENTER” button.
2
Displaying the device status
Select “Bluetooth* info” using the “<SELECT”, “TUNE>” and “SETUP/
ENTER” buttons. (P. 359)
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
● Displaying the device name
Select
“Device name” using the
“<SELECT”,
“TUNE>” and
“SETUP/ENTER” buttons.
● Displaying the device address
Select
“Device address” using the
“<SELECT”,
“TUNE>” and
“SETUP/ENTER” buttons.
Setting the automatic connection confirmation display to on or
off
If the “Display setting” is set to on, the portable player connection sta-
tus will be displayed when the power switch is turned to ACCESSORY
or ON mode.
1
Select
“Display setting” using the
“<SELECT”,
“TUNE>” and
“SETUP/ENTER” buttons. (P. 359)
2
Select “On” or “Off” using the “SETUP/ENTER” button.
AURIS HV Touring
Sports_EE
(OM12L18E)
5-7. “SET UP” menu
367
Initialization
Select “Reset” using the “<SELECT”, “TUNE>” and “SETUP/ENTER”
buttons. (P. 359)
● Initializing the sound settings
Select
“Sound settings” using the
“<SELECT”,
“TUNE>” and
“SETUP/ENTER” buttons and press
“Yes”.
For details about sound settings: P. 371
● Initializing the device information
Select
“Car Device Info” using the
“<SELECT”, “TUNE>” and
“SETUP/ENTER” buttons and press
“Yes”.
The user set passkey and automatic confirmation display will be returned
to their default settings.
● Initializing all the settings
Select “Reset all” using the “<SELECT”, “TUNE>” and “SETUP/
ENTER” buttons and press
“Yes”.
5
AURIS HV Touring
Sports_EE
(OM12L18E)
368
5-7. “SET UP” menu
Using the “SET UP” menu (“Phone” menu)
Adding a new phone number
Select “Add contacts” using the “<SELECT”, “TUNE>” and “SETUP/
ENTER” buttons. (P. 359)
● Transferring all contacts from the cellular phone
Select “Overwrite all” using the “<SELECT”, “TUNE>” and “SETUP/
ENTER” buttons and press
“Yes”.
● Transferring one contact from the cellular phone
Select “Add contact” using the “<SELECT”, “TUNE>” and “SETUP/
ENTER” buttons and press
“Yes”.
Setting speed dials
1
Select “Add SD” using the “<SELECT”, “TUNE>” and “SETUP/
ENTER” buttons. (P. 359)
2
Select the desired data using the
“<SELECT”,
“TUNE>” and
“SETUP/ENTER” buttons.
3
Press and hold the desired preset button.
For details about setting speed dials from the call history: P. 377
For details about deleting speed dials: P. 376
AURIS HV Touring
Sports_EE
(OM12L18E)
5-7. “SET UP” menu
369
Deleting call histories
Select
“Delete call history” using the
“<SELECT”, “TUNE>” and
“SETUP/ENTER” buttons. (P. 359)
● Deleting outgoing call history
1
Select
“Outgoing calls” using the
“<SELECT”, “TUNE>” and
“SETUP/ENTER” buttons.
2
Select the desired phone number using the
“<SELECT”,
“TUNE>” and “SETUP/ENTER” buttons and press
“Yes”.
To delete all outgoing call history data, press
“All” and then
press
“Yes”.
● Deleting incoming call history
1
Select
“Incoming calls” using the
“<SELECT”, “TUNE>” and
“SETUP/ENTER” buttons.
2
Select the desired phone number using the
“<SELECT”,
5
“TUNE>” and “SETUP/ENTER” buttons and press
“Yes”.
To delete all incoming call history data, press
“All” and then
press
“Yes”.
AURIS HV Touring
Sports_EE
(OM12L18E)
370
5-7. “SET UP” menu
● Deleting missed call history
1
Select
“Missed calls” using the
“<SELECT”,
“TUNE>” and
“SETUP/ENTER” buttons.
2
Select the desired phone number using the
“<SELECT”,
“TUNE>” and “SETUP/ENTER” buttons and press
“Yes”.
To delete all missed call history data, press
“All” and then
press
“Yes”.
● Deleting a number from all call histories (Outgoing calls, Incoming
calls and Missed calls)
1
Select “All calls” using the “<SELECT”, “TUNE>” and “SETUP/
ENTER” buttons.
2
Select the desired phone number using the
“<SELECT”,
“TUNE>” and “SETUP/ENTER” buttons and press
“Yes”.
To delete all of the call histories data, press
“All” and then
press
“Yes”.
AURIS HV Touring
Sports_EE
(OM12L18E)
5-7. “SET UP” menu
371
Deleting a registered phone number
1
Select
“Delete contacts” using the
“<SELECT”,
“TUNE>” and
“SETUP/ENTER” buttons. (P. 359)
2
Select the desired phone number using the “<SELECT”, “TUNE>”
and “SETUP/ENTER” buttons and press
“Yes”.
To delete all of the registered phone numbers, Press
“All”
and then press
“Yes”.
Press
“A-Z” to display the registered names in alphabetical
order of the initial.
Deleting another cellular phone’s phonebook
1
Select
“Delete other PB” using the
“<SELECT”, “TUNE>” and
“SETUP/ENTER” buttons. (P. 359)
2
Select the desired phonebook using the “<SELECT”, “TUNE>” and
5
“SETUP/ENTER” buttons and press
“Yes”.
Setting call volume
1
Select “Call volume” using the “<SELECT”, “TUNE>” and “SETUP/
ENTER” buttons. (P. 359)
2
Change the call volume.
To decrease the volume: Press the “<SELECT” button.
To increase the volume: Press the “TUNE>” button.
To set the volume, press
“Back”.
AURIS HV Touring
Sports_EE
(OM12L18E)
372
5-7. “SET UP” menu
Setting ringtone volume
1
Select
“Ringtone volume” using the “<SELECT”, “TUNE>” and
“SETUP/ENTER” buttons. (P. 359)
2
Change the ringtone volume.
To decrease the volume: Press the “<SELECT” button.
To increase the volume: Press the “TUNE>” button.
To set the volume, press
“Back”.
Setting ringtone
1
Select “Ringtone” using the “<SELECT”, “TUNE>” and “SETUP/
ENTER” buttons. (P. 359)
2
Using the “<SELECT” or “TUNE>” button, select a ringtone (1 - 3).
To set the selected ringtone, press
“Back”.
Transferring call histories
Select
“Transfer history” using the
“<SELECT”,
“TUNE>” and
“SETUP/ENTER” buttons and press
“Yes”.
■Phone number
Up to 1000 names can be stored.
■ Call history
Up to 10 numbers can be stored in each of the outgoing, incoming and
missed call history memories.
■Limitation of number of digits
A phone number that exceeds 24 digits cannot be registered.
AURIS HV Touring
Sports_EE
(OM12L18E)
5-8. Bluetooth® Audio
373
Operating a Bluetooth® enabled portable
player
1
Display text message
6
Playback
2
Playback/pause
7
Select a track, fast-forward or
5
reverse
3
Select an album
8
Volume
4
Repeat play
9
Power
5
Random playback
AURIS HV Touring
Sports_EE
(OM12L18E)
