Toyota FJ Cruiser (GSJ 10, 15 series). Manual - part 414
MT–2
RA61F MANUAL TRANSMISSION – MANUAL TRANSMISSION OIL
MT
MANUAL TRANSMISSION OIL
ON-VEHICLE INSPECTION
1.
INSPECT TRANSMISSION OIL
(a) Park the vehicle in a level place.
(b) Remove the transmission filler plug and gasket.
(c) Check that the oil surface is within 5 mm (0.20 in.) of
the lowest point of the transmission filler plug
opening.
NOTICE:
•
Problems may occur when the oil level is too
high or low.
•
After replacing the oil, drive the vehicle and
check the oil level again.
(d) Check for oil leakage when the oil level is low.
(e) Install the transmission filler plug and a new gasket.
Torque: 37 N*m (377 kgf*cm, 27 ft.*lbf)
0 to 5 mm
(0 to 0.20 in.)
D025304E01
