PREPARATION  –  STEERING COLUMN

PP–51

PP

(09951-05010)

Hanger 150

(09952-05010)

Slide Arm

(09953-05020)

Center Bolt 150

(09954-05021)

Claw No.2

PP–52

PREPARATION  –  STEERING COLUMN

PP

RECOMMENDED TOOLS

09031-00030

Pin Punch

09042-00010

Torx Socket T30

(09043-20060)

Socket Hexagon Wrench 6

09904-00010

Expander Set

(09904-00050)

No. 4 Claw

PREPARATION  –  STEERING COLUMN

PP–53

PP

EQUIPMENT

Torque wrench

PP–52

PREPARATION  –  POWER STEERING

PP

PREPARATION

PREPARATION

POWER STEERING

SST

09023-12701

Union Nut Wrench 17mm

09023-38201

Union Nut Wrench 12mm

09612-00012

Rack & Pinion Steering Rack
Housing Stand

09616-00011

Steering Worm Bearing Adjusting
Socket

09628-62011

Boll Joint Puller

09630-00014

Power Steering Gear Housing
Overhaul Tool Set

(09631-00132)

Vane Pump Bracket

09631-00350

Steering Rack Cover 35

09631-12071

Steering Rack Oil Seal Test Tool

(09633-00010)

Packing

09631-20120

Cylinder End Stopper Nut Wrench
