DI-65 Rear Differential (VA-type) DIFFERENTIALS 11) Remove the hypoid driven gear by loosening 12) Remove the self-locking nut while holding the 498427200 FLANGE WRENCH 13) Extract the companion flange with a puller. 14) Removes the drive pinion shaft. 15) Remove the rear bearing cone from drive pin- NOTE: 398517700 REPLACER 16) Remove the front oil seal from differential carri- 18) When replacing the bearings, hit out the front (A) Companion flange (B) Puller DI-00371 DI-00372 ST (B) (A) DI-00394 (A) Pilot bearing (B) Spacer (C) Front bearing (D) Rear bearing cup (A) 2 cutout portions along diagonal lines (B) Tap alternately with brass bar. DI-00373 ST (B) (A) (C) (D) DI-00374 (B) (A) DI-00077 |
