4AT-112 AT Main Case AUTOMATIC TRANSMISSION C: DISASSEMBLY 1. HIGH CLUTCH AND REVERSE CLUTCH 1) Remove the snap ring, and then take out the re- 2) Remove the snap ring, and then take out the re- 3) Using the ST1 and ST2, remove the snap ring. 398673600 COMPRESSOR ST2 498627100 SEAT 4) Take out the clutch cover, spring retainer, high 5) Remove the seal ring and lip seal from the high (A) Snap ring (A) Snap ring (A) Snap ring AT-00236 (A) AT-00237 (A) AT-00238 (A) ST1 ST2 (A) Reverse clutch piston (B) Clutch cover (C) Return spring (A) High clutch piston (B) Reverse clutch piston AT-00239 (A) (B) (C) AT-00240 (A) (B) |
