SE-40
Power Seat System
SEATS
D: ADJUSTMENT
NOTE:
The calibration procedures apply only to the mem-
ory-equipped seat on the driver’s side.
1. CONDITIONS FOR INITIALIZATION
Perform the initializing operation to the memory
module when the following conditions are met.
• When the seat was removed from vehicle.
• When the memory module was replaced.
• When the slide rail assembly or reclining motor
assembly was removed or replaced.
• When the pulse generated while the seat is mov-
ing differs from the actual distance. (When memory
replay operation is not normally carried out)
2. INITIALIZATION PROCEDURE
NOTE:
• Initialize the records inside the module by per-
forming all the following steps regardless the item
order.
• Buzzer sounds once when keeping the switch
operation for three seconds with each seat in lock*
status.
• After the completion of all items for initialization
process, the buzzer sounds three times when fin-
ishing the final operation and turning the switch
from ON to OFF.
1) Move the seat rearward using the slide switch,
and keep the seat lock* status for 3 seconds or
more.
2) Move the seat downward using tilt switch, and
keep the seat lock* status for three seconds or
more.
3) Move the seat downward using lifter switch, and
keep the seat lock* status for three seconds or
more.
4) Tilt the seatback forward using reclining switch,
and keep the seat lock* status for three seconds or
more.
*: Seat lock is the status that there is no pulse out-
put from the encoder within the specified period of
time although it reaches the movable position end.
NOTE:
When the following conditions are met, the initializ-
ing operation is cancelled even though the proce-
dure is carried out halfway.
• Any operation interval between each initialization
procedures from 1) to 4) exceeded 10 seconds.
• All operations throughout initialization procedure
1) to 4) was not performed.
• During initialization procedure, power supply
was cut off, or the voltage to the memory module
exceeded the range of operating voltage.
