LU(H4SO)-17 Oil Pan and Strainer LUBRICATION 18) Insert the oil pan cutter blade into the gap be- CAUTION: B: INSTALLATION NOTE: NOTE: 2) Install the baffle plate. Tightening torque: 6.4 N·m (0.7 kgf-m, 4.7 ft-lb) 3) Install the oil strainer to the cylinder block. NOTE: Tightening torque: 10 N·m (1.0 kgf-m, 7.4 ft-lb) 4) Tighten the oil strainer stay together with the baf- Tightening torque: 6.4 N·m (0.7 kgf-m, 4.7 ft-lb) 5) Apply liquid gasket to the mating surfaces of oil NOTE: Liquid gasket: THREE BOND 1217G (Part No. K0877Y0100) (A) Oil pan (B) Oil strainer (C) Baffle plate (D) Cylinder block (A) (C) (D) (B) LU-02334 (A) Gasket LU-00052 (A) LU-02353 (A) |
