TRANSFER CASE

TC

Page

1.

General Description ....................................................................................2

2.

Transfer Case and Extension Case Assembly............................................3

3.

Transfer Clutch............................................................................................4

4.

Extension Case ...........................................................................................5

5.

Extension Case and Intermediate Case......................................................6

6.

Oil Seal........................................................................................................7

7.

Transfer Drive Gear ....................................................................................8

8.

Transfer Driven Gear ..................................................................................9

9.

Reduction Drive Gear................................................................................10

10.

Center Differential Carrier .........................................................................11

11.

Reduction Driven Gear..............................................................................12

12.

Center Differential .....................................................................................13

13.

Transfer Clutch Pressure Test ..................................................................14

TC-2

Vehicle-id:
SIE-id:S302001a15:A:NOTE
∼

TRANSFER CASE

General Description

1. General Description

A: NOTE

For general description, refer to “4AT”, “5AT” or
“5MT” section.
4AT model:
<Ref. to 4AT-2, General Description.>
5AT model:
<Ref. to 5AT-2, General Description.>
5MT model:
<Ref. to 5MT-2, General Description.>

TC-3

TRANSFER CASE

Transfer Case and Extension Case Assembly

2. Transfer Case and Extension

Case Assembly

A: NOTE

For removal, installation and inspection, refer to
“5MT” section. <Ref. to 5MT-43, Transfer Case and
Extension Case Assembly.>

TC-4

Vehicle-id:
SIE-id:S302588a15:A:NOTE
∼

TRANSFER CASE

Transfer Clutch

3. Transfer Clutch

A: NOTE

For removal, installation and inspection, refer to
“4AT” or “5AT” section.
4AT model:
<Ref. to 4AT-87, Transfer Clutch.>
5AT model:
<Ref. to 5AT-73, Transfer Clutch.>
