FU(H6DO)-41
FUEL INJECTION (FUEL SYSTEMS)
Fuel Tank
13) Remove the rear brake caliper and tie it to the
vehicle body side.
14) Remove the parking brake cable from parking
brake assembly. <Ref. to PB-6, REMOVAL, Park-
ing Brake Assembly (Rear Disc Brake).>
15) Remove the rear exhaust pipe.
<Ref. to EX(H6DO)-7, REMOVAL, Rear Exhaust
Pipe.>
16) Remove the propeller shaft. <Ref. to DS-10,
REMOVAL, Propeller Shaft.>
17) Remove the heat shield cover.
18) Disconnect the connector from rear ABS wheel
speed sensor.
19) Remove the bolts which install the parking
brake cable clamp.
20) Remove the rear suspension assembly.
CAUTION:
A helper is required to perform this work.
(1) Support the rear differential with transmis-
sion jack.
(2) Remove the bolt which installs the rear
shock absorber to rear suspension arm.
FU-00462
FU-01129
FU-01130
FU-01131
FU-01132
