EN(H4SO 2.0)(diag)-37 ENGINE (DIAGNOSTICS) Drive Cycle 3. DRIVE ACCORDING TO THE FOLLOWING DRIVE PATTERN (A) Idle engine for 1 minute. (E) Drive the vehicle at 65 km/h (40 (G) Stop vehicle with throttle fully (B) Accelerate the vehicle to 96 km/h (F) Accelerate the vehicle to 96 km/h (H) Vehicle speed km/h (MPH) (C) Drive the vehicle at 96 km/h (60 (I) Sec. (D) Decelerate the vehicle to 65 km/h DTC Item Condition *P0030 HO2S Heater Control Circuit (Bank 1 Sensor 1) — P0130 O2 Sensor Circuit (Bank1 Sensor1) — *P0139 O2 Sensor Circuit Slow Response (Bank 1 Sensor 2) — P0301 Cylinder 1 Misfire Detected Diagnosis frequency is different P0302 Cylinder 2 Misfire Detected Diagnosis frequency is different P0303 Cylinder 3 Misfire Detected Diagnosis frequency is different P0304 Cylinder 4 Misfire Detected Diagnosis frequency is different P0400 Exhaust Gas Recirculation Flow — P0700 Transmission Control System (MIL Request) — P1134 A/F Sensor Micro-Computer Problem — P1492 EGR Solenoid Valve Signal #1 Circuit Malfunction (Low Input) — P1493 EGR Solenoid Valve Signal #1 Circuit Malfunction (High Input) — P1494 EGR Solenoid Valve Signal #2 Circuit Malfunction (Low Input) — P1495 EGR Solenoid Valve Signal #2 Circuit Malfunction (High Input) — P1496 EGR Solenoid Valve Signal #3 Circuit Malfunction (Low Input) — P1497 EGR Solenoid Valve Signal #3 Circuit Malfunction (High Input) — P1498 EGR Solenoid Valve Signal #4 Circuit Malfunction (Low Input) — P1499 EGR Solenoid Valve Signal #4 Circuit Malfunction (High Input) — P1521 Brake Switch Circuit Range/Performance Problem (High Input) — P2504 Charging System Voltage High — 50 100 150 0 65 (40) 96 (60) (I) (H) (A) (B) (C) (D) (E) (F) (G) EN-00195 |
