Wiring Diagram for Power Supplies  5-51

Electrical Wiring Diagram

(LHD)

A. CONNECTOR INFORMATION

B. CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION

Connector Number

(Pin Number, Color)

Engine Room Fuse Box - Engine

Engine Room Fuse Box - Engine

Engine Room Fuse Box - Main

Engine Room Fuse Box - Main

Engine Room Fuse Box - Main

Main - Roof

Main - W/H Air-Bag

W/H Air-Bag - W/H Blower

Main - Floor (RH)

Main - Floor (RH)

Floor (RH) - RR A/C

W/H Main

W/H Main

W/H Main

C102 (20Pin, White)

C104 (20Pin, White)

C105 (22Pin, White)

C107 (14Pin, White)

C109 (16Pin, White)

C201 (26Pin, White)

C211 (16Pin, White)

C211A (13Pin, White)

C218 (20Pin, Red)

C221 (20Pin, Gray)

C305 (6Pin, Colorless)

G201

G202

G204

Connecting Wiring

Harness

Engine Room Fuse Box

Engine Room Fuse Box

Engine Room Fuse Box

Engine Room Fuse Box

Engine Room Fuse Box

Behind Parking Brake

Behind RR A/V Unit

Behind RR Glove Box

Inside Passenger Side Cowl PNL

Inside Passenger Side Cowl PNL

RR Right Quarter Trim

Inside Driver Side Cowl PNL

Inside Driver Side Cowl PNL

W/H Main

Remark

Connector Position

FATC

Power Seat (Seat Warmer)

Dual A/C
