12-8

4) Recovery of Set Speed (RESUME)

Even if the cruise control is cancelled, the previous set cruise speed can be recovered by pushing

(Type A) or pulling (Type B) toward the cruise control lever when the current vehicle speed is over 36

km/h without an acceleration intervention. But if you turn off the ignition switch, the memorized set

speed is cleared and you cannot recover the previous set speed.

The resume position should only be used if the driver is fully aware of this speed and wishes to

resume this particular speed.

12-9

8510-23

5) Normal Cancellation of the Cruise Control

The cruise control system will be canceled when one or more items of the following conditions are

applied;

Keep the main cruise control switch in the neutral position when not using the cruise control.

When the brake pedal is depressed.

When the cruising speed is downed less than 38 km/h.

When the OFF switch is operated by pulling the cruise control lever (Type A) or by pushing the ON-

OFF switch of the cruise control lever (Type B).

When ESP is activated.

When applying the parking brake when driving.

When using the clutch in order to shift (M/T only).

And the cruise control system can be operated again in driving state.

1.

2.

3.

4.

5.

6.

12-10

(2) Using the Cruise Control on Hills

How well the cruise control works on hills depends on the speed, load, and the steepness of the hill.

When going up steep hills, you may have to depress the accelerator pedal to maintain your speed.

When going downhill, you may have to brake or shift to a lower gear to keep your speed down.

Applying the brake takes you out of the cruise control.

And the cruise control system cannot be operated again in driving state. In this case, you should stop

the vehicle, and turn off the ignition switch and then turn it on again. After you do that, you can use the
cruise control system again. But if the cruise control system isn’t recovered, you should contact

a Ssangyong Dealer for diagnosis of the cruise control system.

Abnormal changes of the gear selector lever can damage the engine. Do not move the gear shift

lever to Neutral while driving at the set speed. Automatic transmission damage may result.

The speed that has been set may not be maintained on uphill or downhill slopes.

The speed may drop to less than the set speed on a steep uphill grade. The accelerator must be

used if you want to maintain that speed.

The speed may increase to more than the set speed on a steep downhill grade. When the speed

increases too much, turn off the cruise control.

-

 -

-

 -

(1) Abnormal Cancellation of the Cruise Control

When the rapid deceleration is applied without braking.

When the rapid acceleration is applied without acceleration pedal intervention.

When the cruise control lever is failed.

When the brake switch and the brake light switch input signal are implausible.

1.

2.

3.

4.

13-3

1793-00

1. SPECIFICATION

Item

Specification

E-EGR valve

Motor

EGR response time

50 ms

Driven by

DC motor

Valve

EGR gas flow rate

120 Kg/h

Position sensor

Sensing type

Hole sensor

Supplied voltage

5V ± 10%

Maximum signal

range

5% ~ 95%

Maximum power

consumption

＜15mA

E-EGR cooler

Cooling capacity

8.3 kW or more

Cooling fin type

Wavy fin

Cooler type

U-shaped

E-EGR bypass valve

Driven by

Vacuum

(Solenoid valve)
