MANUAL TRANSMISSION 5B-21 SSANGYONG Y200 Pre-Installation Checks Checking Procedure 1. Separate the clutch release fork from the pivot and remove the pivot from the clutch housing. 2. Check the pivot. Fork and release bearing. 3. Check the pressure plate spring. Notice: Inspect each parts and replace the 4. Check the clutch housing alignment as follows : • Place the magnetic base on the pressure plate • Check the housing bore alignment. YAD5B350 YAD5B360 YAD5B370 YAD5B380 - Place the dial indicator on the bore. - By rotating the crankshaft one revolution, record the dial indicator reading. |
