SSANGYONG Y200 1B3-84 DIESEL ENGINE MECHANICAL YAD1BFG0 YAD1BFH0 YAD1BFJ0 YAD1BFK0 Tools Required 000 589 04 14 00 Tensoning Strap 001 589 53 21 00 Dial Gauge 363 589 02 21 00 Dial Gauge Holder Removal Procedure 1. Remove combustion residues from the cylinder bores. 2. Remove the connecting rod bolts (12) and then remove the connecting rod bearing caps (11). 5. Remove the snap ring (4) and pull out the piston pin (5). 6. Separate the piston and connecting rod. 4. Remove the piston (6) and connecting rod (8). 3. Remove the connecting rod bearing shells (9, 10). Notice: Be careful not mix the bearing caps and |
