M161 ENGINE MECHANICAL 1B2-95 SSANGYONG Y200 YAD1B8A0 OIL DIPSTICK GUIDE TUBE Removal & Installation Procedure 1. Pull out the oil dipstick level gauge (1). 2. Unscrew the bolt (4) and remove the oil dipstick guide tube (2). Installation Notice 1 Oil Dipstick Level Gauge 4 Bolt (M6 X 16, 1 piece) .................................... 9 - 11 N•m (80 - 97 lb-in) 5 Clamp It is very hard to remove the oil dipstick guide 3. Installation should follow the removal procedure in the reverse order. 4. Check for leaks by starting the engine. Tightening Torque 9 - 11 N•m (80 - 97 lb-ft) |
