M161 ENGINE MECHANICAL 1B2-3 SSANGYONG Y200 YAD1B020 YAD1B4T0 YAD1B4U0 YAD1B040 Removal & Installation Procedure 1. Disconnect the negative terminal of battery. 2. Remove the hood. 3. Remove the under cover. Installation Notice 4. Disconnect the coupling of HFM sensor and remove the air cleaner cross pipe. 5. Remove the air cleaner cover. Remove the mounting bolts and air cleaner housing and 6. Loosen the radiator drain cock and drain the coolant. Notice: Open the coolant reservoir cap. Tightening Torque 28 - 47 N•m (21 - 35 lb-ft) |
