06-3

8510-01

1. MAJOR CHANGES

Manual air conditioner controller

Previous

Current

Driving circuit for the ambient temperature sensor added to the manual air conditioner controller for
ambient temperature display on the instrument cluster

Lower main panel switch

Previous

Current

Changed layout due to addition of steering wheel heating switch

Steering wheel heating switch

06-4

Audio remote control switch

Previous

Current

Bluetooth handsfree function added and button logo design changed

06-5

8510-00

1. OVERVIEW

Door panel switch (driver)

Door panel switch (passenger)

Door panel switch (rear)

IP panel switch

Steering wheel switch

Front console switch

Trunk switch

Headlining switch

1.

2.

3.

4.

5.

6.

7.

8.

1) Mounting Locations

06-6

Steering wheel remote

control switch

Passenger door switch

Lower main panel

switch

Start/stop switch

Cruise control switch

Hazard warning switch

bezel assembly

Multifunction switch

FATC switch

Drive door main switch

& outside mirror switch

Switch layout

▶
