4.2 BONNET (1/2) Unlocking the bonnet catch To release it, lift tab 2. Opening the bonnet Lift the bonnet; you will need to guide it as it is held by a strut. To open, pull handle 1, located on the left-hand side of the dashboard. 1 2 Do not press down on the bonnet: there is a risk that the bonnet may accidentally close. The engine may be hot when carrying out opera- tions in close proximity. In addition, the engine cooling fan can come on at any moment. Risk of injury. Before performing any action in the engine com- partment, the ignition must be switched off by pressing the engine stop button (please see the information on “Starting, stop- ping the engine” in Section 2). When working in the engine compartment, ensure that the windscreen wiper stalk is in the park position. Risk of injury. |
