Dacia SuperNova (engine E7J). Service manual - part 125

82A

HORN - ENGINE IMMOBILISER

82A - 33

ALP4. CONTA CT ON. THE AN TI STARTI NG I NDI CATOR BLINKS
QUICKLY (the engine doesn’t start)

RECOMMENDATION

-

Set the contact on.
Connect the CLIP tester.
Is there any communication between the tester
and  E.C.U. decoder ?

Is the state 19D is ACTIVE?

Check the continuity and the isolation related
to the ground and to the + 12V of the wiring
between A6 decoder pin and injection
computer pin 58.
 Is the wiring good?

See ALP 1.

Check the  correct memorisation of
the  anti starting code by the  E.C.U.
decoder ; if not, replace the decoder.

Fix the electric wiring.

Perform the impulse detection test by means
of the CLIP tester connected to the E.C.U.
decoder A6 pin.
Set the  contact on and check impulses
presence.
Are there any impulses?

Replace the injection computer.

Replace E.C.U. decoder or see the “ Kit
replacement procedure “.

Perform a conformity checking.

AFTER REPAIRING

Check the operation of the anti starting system.
Remove by means of the CLIP tester the possible memorised failures.

No

Yes

No

Yes

Yes

No

Yes

No

DIAGNOSTIC

82A

HORN - ENGINE IMMOBILISER

82A - 34

    ALP5. THE VEHICLE DOES NOT START

RECOMMENDATION

-

Is there the failure “SIGNAL MISSING ON
THE  CODED LINE E.C.U. DECODER –
COMPUTER INJECTION?”



There is a problem at the shock sensor.

There is an engine problem.

No

Yes

Perform a conformity checking.

AFTER REPAIRING

Check the operation of the anti starting system.
Remove by means of the CLIP tester the possible memorised failures.

DIAGNOSTIC

82A

HORN - ENGINE IMMOBILISER

82A - 35

ALP6. BLOCKING/UNLOCKING DOORS NOT OPERATING

RECOMMENDATION Check with the CLIP tester the absence of the failures.

If there are memorised failures, these must be removed.

Are the doors blocking mechanisms correctly
operating ?

Repair the damaged mechanisms.

No

Check the continuity and the isolation related to the ground
of the wiring between :

E.C.U.  decoder

pin B8               actuators
Pin B9              doors

Is the wiring in good condition?

Fix the wiring.

No

Check the continuity and the isolation related
to the ground of the wiring between
E.C.U.

pin B8

switch

decoder

pin B9

blocking doors

Is the wiring in good condition?

Repair.

Disconnect the E.C.U.  decoder, then supply
the wiring connector with  +12 V at pin B9 and
the ground at the pin B8, than versa (+ 12 V at
pin B8 and the ground at pin B9).
Are the actuators blocking/unlocking the
doors?

Damaged actuators.

Replace them.

Replace the E.C.U. decoder, then perform  the  “E.C.U. decoder replacement
procedure”.

No

Yes

Yes

No

Yes

Yes

AFTER REPAIRING

Perform a conformity checking.
Check the operation of the anti starting system.

DIAGNOSTIC

82A

HORN - ENGINE IMMOBILISER

82A - 36

ALP7. UNLOCKING DOORS NOT OPERATING BY RF REMOTE CONTROL

RECOMMENDATION Check the absence of failures with the CLIP tester.

If there are memorised failures, these must be repaired.

Are the states 11G and 11D ACTIVE when
the RF remote control is activated?

See the treatment states 11G and
11D cf. Chapter “Diagnostic”.

No

Check the fuse F15 ( up to 01.06.2001) or
F07 (after 01.06.2001).
Is it good?

Replace the fuse.

No

Yes

Yes

Activate the doors’ locking switch from the
dashboard.
Are the doors blocking/ unlocking ?

See the treatment of the failure
“Doors blocking contact” and the
state 14  G  cf.  Chapter “Diagnostic”.

See ALP 6.

Yes

No

AFTER REPAIRING

Perform a conformity checking.
Check the operation of the anti starting system.

DIAGNOSTIC
