80 BATTERY - FRONT HEADLIGHTS 80 - 7 HEADLAMPS ADJUSTMENT MEETING LIGHTS ADJUSTMENT (LOW BEAM) This is performed by acting upon the V screw (vertically plane adjustment) or H (horizontally Check if the lighted area is centered on the vertical axis and if the optical separation at 15° A lighting beam displaced towards left has the aspect shown in (pict.a) and a lighting beam ROAD LIGHTS ADJUSTMENT (LONG BEAM) Check the position to coincide with the adjustment performed for low beam and with When checking the long beam, the lighting center of the ellipse, must be located on the If a major deviation compared with the low beam is noticed, it is recommended the bulb replacement, this one being in most of the cases, responsible for such defect. pict.a pict.b |
