10 10 - 10 ENGINE AND LOWER ENGINE UNITS PARTICULARS ON REMOUNTING Check the existance of the two bushings by means of which the clutch casing is centered on the block. Slightly grease ( thin coat) the clutch shaft grooves with Li Ca Pb type II grease. - the filling with oil of the engine; Adjust the engine running (ignition ,carburation). E NGINE
MOUNTING - DISMOUNTING Caps to bearings
5,50 - 6,50 Caps to connecting rods
4,00 - 4,50 Flywheel 5 Cylinder head to casing ( at cold)
5,50 - 6,50 Cylinder head cap
0,15 - 0,45 Tilter shaft support
1,50 - 1,75 Camshaft pinion
2,70 - 3,20 Camshaft clip
0,80 - 1,00 Oil pump on casing
0,70 - 1,00 Lower casing
1,20 +/- 0,40 Clutch mechanism φ 180 DBR
1,00 - 1,20 Clutch mechanism φ 200 DBR/ φ 200 GR 1,50 - 2,00 Distribution cap
0,70 - 1,00 Oil emptying plug
max. 3,5 Pump and water pump cap
0,70 Fan 2,00 - 2,50 Starter screen 2 - 3 Fuel pump 1,50 - 2,00 Thermocontact 1,50 - 2,00 Oil pressure trasmitter 2 Carburettor 1,50 - 2,00 Crankshaft pulley 6,50 Alternator support 1,00 - 1,75 ENGINE DISMOUNTING - REMOUNTING F IXING T IGHTENING
MOMENTS (daN.m) |
