Peugeot Traveller (2016 year). Manual

169

Audio and Telematics

Transversal-Peugeot_en_Chap03_RD6_ed01-2016

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Select the "YES" tab in the screen
using the buttons.

Confirm with OK.

Press this button at the steering
mounted controls to accept the call.

Making a call

In the "Telephone" menu.

Select "Call".

Select "Calls list".

Select "Dial".

Select "Directory".

Press this button for more than two
seconds for access to your directory,
then navigate using the thumb wheel.

In the "Telephone" menu.

Select "End call".

Ending a call

During a call, press one of the
buttons for more than 2 seconds.

Confirm with OK to end the call.

The system accesses the telephone's
contacts directory, depending on its
compatibility, and while it is connected
by Bluetooth

With certain telephones connected by
Bluetooth, you can send a contact to
the directory of the audio system.
Contacts imported in this way are
saved in a permanent directory
visible to all, whatever the telephone
connected.
The menu for the directory is not
accessible if it is empty.

170

Audio and Telematics

During a call, press OK to display the
contextual menu.

In the contextual menu, select "End
call

" to end the call.

Managing calls

Hang up

(so that the caller cannot hear)

In the contextual menu:
- select "Micro OFF" to switch off

the microphone.

- deselect "Micro OFF" to switch

the microphone on.

In the contextual menu:
- select "Telephone mode" to

transfer the call to the telephone
(for example, to leave the vehicle
while continuing a conversation).

- deselect "Telephone mode" to

transfer the call to the vehicle.

Microphone off

Telephone mode

If the contact has been cut off, when you
reconnect on returning to the vehicle,
the Bluetooth connection will be restored
automatically and sound returned to the
system (depending on the compatibility of the
telephone).
In some cases telephone mode must be
activated from the telephone.

From the contextual menu, select
"DTMF tones" and confirm to use
the digital keypad to navigate in the
interactive voice response menu.

From the contextual menu, select
"Switch" and confirm to return to a
call left on hold.

Interactive voice response

Dual call

Confirm with OK.

171

Audio and Telematics

Transversal-Peugeot_en_Chap03_RD6_ed01-2016

To modify the contacts saved in the
system, press MENU then select
"Telephone" and confirm.
Select "Directory management"
and confirm.
You can:
- "Consult an entry",
- "Delete an entry",
- "Delete all entries".

Make a long press on SRC/TEL.

The system accesses the telephone's
contacts directory, depending on
its compatibility, and while it is
connected by Bluetooth.

With certain telephones connected
by Bluetooth you can send a contact
to the directory of the audio system.
Contacts imported in this way are
saved in a permanent directory
visible to all, whatever the telephone
connected.
The menu for the directory is not
accessible if it is empty.

Select "Directory" to see the list of
contacts.

Directory

Confirm with OK.

Voice recognition

This function allows you to use your
smartphone's voice recognition via the system.

To start voice recognition, depending on the
type of steering mounted controls:

Make a long press on the end of the lighting
control stalk.

Press this button.

Voice recognition requires the use of a
compatible smartphone first connected
to the vehicle by Bluetooth.

172

Audio and Telematics

The table below gives answers to the most frequently asked questions on your audio system.

QUESTION

ANSWER

SOLUTION

With the engine off, the
audio system switches off
after a few minutes of use.

When the engine is switched off, the audio system operating time
depends on the state of charge of the battery.
The switch-off is normal: the audio equipment switches to economy
mode and switches off to prevent discharging of the vehicle's
battery.

Start the vehicle's engine to increase the battery
charge.

The message "the audio
system is overheated"
appears on the display.

In order to protect the installation if the surrounding temperature
is too high, the audio system switches to an automatic thermal
protection mode leading to a reduction in volume or CD play
stopping.

Switch the audio system off for a few minutes to
allow the system to cool.

Frequently asked questions

QUESTION

ANSWER

SOLUTION

There is a difference in
sound quality between the
different audio sources
(radio, CD...).

For optimum sound quality, the audio settings (Volume, Bass,
Treble, Ambience and Loudness) can be adapted to the different
sound sources, which may result in audible differences when
changing source (radio, CD...).

Check that the audio settings (Volume, Bass,
Treble, Ambience and Loudness) are adapted to
the sources listened to. It is advisable to set the
audio functions (Bass, Treble, Front-Rear Balance
and Left-Right Balance) to the middle position,
select the musical ambience "None" and set the
loudness correction to the "Active" position in CD
mode or to the "Inactive" position in radio mode.

Radio

173

Audio and Telematics

Transversal-Peugeot_en_Chap03_RD6_ed01-2016

QUESTION

ANSWER

SOLUTION

The preset stations do
not function (no sound,
87.5 Mhz is displayed...).

An incorrect waveband is selected.

Press the BAND button to return to the waveband
(FM, FM2, DAB, AM) on which the stations are
preset.

The traffic announcement
(TA) is displayed. I do
not receive any traffic
information.

The radio station is not part of the regional traffic information
network.

Tune to a radio station which broadcasts traffic
information.

The quality of reception of
the radio station listened
to gradually deteriorates
or the stored stations do
not function (no sound,
87.5 Mhz is displayed...).

The vehicle is too far from the transmitter used by the station
listened to or there is no transmitter in the geographical area
through which the vehicle is travelling.

Activate the RDS function to enable the system
to check whether there is a more powerful
transmitter in the geographical area.

The environment (hills, buildings, tunnels, underground car parks...)
block reception, including in RDS mode.

This phenomenon is normal and does not indicate
a fault in the audio system.

The aerial is absent or has been damaged (for example when going
through an automatic car wash or into an underground car park).

Have the aerial checked by a franchised dealer.

Sound cut-outs of 1 to
2 seconds in radio mode.

During this brief sound cut-out, the RDS searches for another
frequency giving better reception of the station.

Deactivate the RDS function if the phenomenon is
too frequent and always on the same route.

174

Audio and Telematics

Media

QUESTION

ANSWER

SOLUTION

The Bluetooth connection
is broken.

The state of charge of the device may be too low.

Charge the battery of the portable device.

The message "USB device
error" is displayed in the
screen.

The USB memory stick is not recognised.
The USB memory stick may be corrupt.

Reformat the USB memory stick.

The CD is ejected every
time or is not played.

The CD is upside down, cannot be read, does not contain audio
files or contains audio files of a format not recognised by the audio
system.
The CD is protected by an anti-pirating system not recognised by
the audio system.

- Check that the CD is inserted in the player the

right way up.

- Check the condition of the CD: the CD cannot

be played if it is too damaged.

- Check the content in the case of a recorded

CD: consult the advice in the "Audio" section.

- Due to their quality level, certain writeable

CDs will not be played by the audio system.

The sound from the CD is
poor.

The CD used is scratched or of poor quality.

Insert a good quality CD and store them in
suitable conditions.

The audio settings (base, treble, ambience) are unsuitable.

Return bass and treble settings to 0, without
selecting an ambience.

I am unable to play
the music files on my
smartphone via the USB
port.

Depending on the smartphone, access by the audio system to music
on the smartphone may have to be approved on the latter.

Manual activate the MTP profile on the
smartphone (USB settings menu).

175

Audio and Telematics

Transversal-Peugeot_en_Chap03_RD6_ed01-2016

QUESTION

ANSWER

SOLUTION

I am unable to access my
voicemail.

Few telephones or service providers allow the use of this function.

Call your voicemail box, via the telephone menu,
using the number supplied by your service
provider.

I am unable to access my
directory of contacts.

Check the compatibility of your telephone.

You did not give access to your contacts when pairing the telephone. Accept or confirm access by the system to the

contacts on your telephone.

I am unable to continue a
conversation when getting
into my vehicle.

Telephone mode is activated.

Deselect telephone mode to transfer the call to
the vehicle.

I am unable to pair my
telephone by Bluetooth.

Telephones (models, versions of operating systems) have their own
specific aspects in the pairing procedure and some telephones are
not compatible.

Before starting the pairing procedure, delete the
pairing of the telephone from the system and of
the system from the telephone, so as to see the
compatibility of the telephones.

Telephone

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

PEUGEOT Connect Radio

Multimedia audio system - Applications - Bluetooth

telephone

Contents

First steps

Steering mounted controls - Type 1

100

Steering mounted controls - Type 2

101

Menus 102
Applications 104
Radio Media

112

Telephone 124
Settings 138
Frequently asked questions

149

The system is protected in such a way
that it will only operate in your vehicle.
The display of the Energy Economy
Mode message signals that a change
to standby is imminent.

The different functions and settings
described vary according to the version
and configuration of your vehicle.

The link below gives access to OSS
(Open Source Software) codes for the
system.
http://www.psa-peugeot-citroen.com/oss

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-
free system of your audio system must
be done with the vehicle stationary
and the ignition on.

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

First steps

With the engine running, a press
mutes the sound.
With the ignition off, a press turns the
system on.

Volume.

Use the buttons either side of or below the
touch screen for access to the menus, then
press the virtual buttons in the touch screen. All
of the touch areas of the screen are white.
Press in the grey zone to go back a level or
confirm.
Press the back arrow to go back a level or
confirm.

The touch screen is of the "capacitive"
type.
To clean the screen, use a soft, non-
abrasive cloth (spectacles cloth) with
no additional product.
Do not use sharp objects on the
screen.
Do not touch the screen with wet
hands.

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Select the audio source (depending on
version):
- FM / DAB* / AM* stations.
- Telephone connected by Bluetooth* and

using Bluetooth* audio streaming.

-  CD player.
-  USB memory stick.
-  Media player connected to the auxiliary

socket (Jack, cable not supplied).

* Depending on equipment.

Certain information is displayed permanently in
the upper band of the touch screen:
- Reminder of the air conditioning

information, and direct access to the
corresponding menu.

- Reminder of the Radio Media and

Telephone menu information.

- Access to the Settings of the touch screen

and digital instrument panel.

In very hot conditions, the volume may
be limited to protect the system. It may
go into standby (screen and sound off)
for at least 5 minutes
The return to normal takes place when
the temperature in the passenger
compartment has dropped.

In the "Settings" menu you can create
a profile for just one person or a group
of people with common points, with the
possibility of entering a multitude of
settings (radio presets, audio settings,
ambiences, ...); these settings are
taken into account automatically.

100

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Steering mounted controls - Type 1

Radio

Short press: display the list of radio
stations.
Long press: update the list.
Media

Short press: display the list of folders.
Long press: display the sorting
options.

Decrease volume.

Radio

Select the previous / next preset
radio station.
Select the previous / next item in a
menu or a list.
Media

Select of the previous / next track
Select the previous / next item in a
menu or a list.

Mute / Restore sound by
simultaneously pressing the increase
and decrease volume buttons.

Change audio source (Radio; USB;
AUX (if a device is connected); CD;
Streaming)

Confirm a selection.

Increase volume.

101

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Media

(short press): change the

multimedia source.
Telephone

(short press): call.

Call in progress

(short press):

access to telephone menu.
Telephone

(long press): reject an

incoming call, end call, access to
telephone menu.

Decrease volume.

Voice commands

Short press, smartphone voice
commands via the system.

Mute/ Restore the sound.
Or
Mute by pressing the volume
increase and decrease buttons
simultaneously.
Restore the sound by pressing one of
the two volume buttons.

Radio

(rotate): previous / next preset.

Media

(rotate): previous / next track,

move in a list.
Short press

: confirm a selection;

other than selection, access to
presets.

Radio

: display the list of stations.

Media

: display the list of tracks.

Radio

(press and hold): update the

list of stations received.

Increase volume.

Steering mounted controls - Type 2

102

21,5

18,5

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Menus

Radio Media

Applications

Select an audio source or radio station.

Access configurable equipment.

Air conditioning

Manage the different temperature and air flow
settings.

Navigation

Configure the guidance and select your
destination via MirrorLink

or CarPlay

According to version.

103

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Settings

Driving

Telephone

Configure a personal profile and/or configure
the sound (balance, ambience, ...) and the
display (language, units, date, time, ...).

Activate, deactivate or configure certain vehicle
functions.

Connect a telephone by Bluetooth

Operate certain applications on a smartphone
connected via MirrorLink

or CarPlay

104

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Applications

According to version / according to equipment.

105

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Comments

Applications

Scented air

freshener

Select the fragrance.

OFF

Deactivate the scented air freshener.

Low

Adjust the intensity of diffusion of the fragrance.

Medium

High

Confirm the selection and the settings.

Applications

Temperature
conditioning

State

Activate/deactivate the temperature conditioning.

Settings

Configure the pre-conditioning

Save the parameters.

Confirm the settings.

Applications

i-Cockpit Amplify

Relax

Select an ambience combining each of the
equipment pre-sets and/or save it in a user profile.

Boost

Profile management

i-Cockpit Amplify

Relax

Select an ambience combining each of the
equipment pre-sets and/or save it in a user profile.

Boost

Profile management

Peugeot Traveller (2016 year). Manual - part 35
