PEUGEOT Connect Radio

Settings

QUESTION

RESPONSE

SOLUTION

When changing the setting of treble and bass
the equalizer setting is deselected.
When changing the equalizer setting, the treble
and bass settings are reset.

The selection of an equalizer setting imposes
the settings for treble and bass and vice versa.

Modify the treble and bass or equalizer settings
to obtain the desired musical ambience.

When changing the balance setting, distribution
is deselected.
When changing the distribution setting, the
balance setting is deselected.

The selection of a distribution setting imposes
the balance settings and vice versa.

Modify the balance setting or the distribution
setting to obtain the desired sound quality.

There is a difference in sound quality between
the different audio sources.

To allow for optimal listening quality, the
audio settings can be tailored to different
sound sources, which can generate audible
differences when changing source.

Check that the audio settings are adapted to the
sources listened to. Adjust the audio functions
to the middle position.

When the engine is off, the system stops after
several minutes of use.

When the engine is switched off, the system's
operating time depends on the state of charge
of the battery.
In normal off state, the system automatically
goes into energy economy mode to maintain an
adequate charge in the battery.

Turn the ignition on to increase the charge of
the battery.

PEUGEOT Connect Radio

PEUGEOT Connect Radio

Bluetooth

audio system

Bluetooth

audio system

Contents

First steps

Steering mounted controls

Menus

Radio

DAB radio (Digital Audio Broadcasting)

Media

Telephone

Frequently asked questions

The different functions and settings
described vary according to the version
and configuration of your vehicle.

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-free
system of your audio system must be
done with the vehicle stationary and the
ignition on.

Your audio system is coded in such a way
that it will only operate in your vehicle.
All work on the system must be
carried out exclusively by a dealer or a
qualified workshop, to avoid any risk of
electrocution, fire or mechanical faults.

To avoid discharging the battery, the audio
system may switch off after a few minutes
if the engine is not running.

Bluetooth

audio system

First steps

Press: On / Off.
Rotate: adjust volume.

Short press: change audio source
(radio; USB; AUX (if equipment
connected); CD; streaming).
Long press: display the Telephone
menu (if a telephone is connected).

Adjust audio settings:
Front/rear fader; left/right balance;
bass/treble; loudness; audio
ambience.
Activation / Deactivation of
automatic volume adjustment (linked
to the speed of the vehicle).

Radio:
Short press: display the list of radio
stations.
Long press: update the list.
Media:
Short press: display the list of
folders.
Long press: display the available
sorting options.

Select the screen display mode,
between:
Date; Audio functions; Trip
computer; Telephone.

Confirm or display contextual menu.

Buttons 1 to 6.
Short press: select the preset radio
station.
Long press: preset a radio station.

Radio:
Automatic step by step search up /
down for radio stations.
Media:
Select previous / next CD, USB,
streaming track.
Scroll in a list.

Radio:
Manual step by step search up /
down for radio stations.
Select previous / next MP3 folder.
Media:
Select previous/next folder / genre /
artist / playlist on the USB device.
Scroll in a list.

Abandon the current operation.
Go up one level (menu or folder).

Access to the main menu.

Activate / Deactivate TA (traffic
announcements).
Long press: select type of
announcement.

Selection of FM / DAB / AM
wavebands.

Bluetooth

audio system

Steering mounted controls

Steering mounted controls
– Type 1

Radio:
Select the previous / next preset
radio station.
Select the previous / next item in a
menu or a list.
Media:
Select the previous / next track.
Select the previous / next item in a
menu or a list.

Radio:
Short press: display the list of radio
stations.
Long press: update the list.
Media:
Short press: display the list of
folders.
Long press: display the available
sorting options.

Other than telephone call:
Short press: changing audio source
(radio; USB; AUX (if equipment
connected); CD; streaming),
confirmation if the "Telephone"
menu is open.
Long press: open the "Telephone"
menu.
In the event of a telephone call:
Short press: accept the call.
Long press: reject the call.
During a telephone call:
Short press: open the contextual
telephone menu.
Long press: end the call.

Confirm a selection.

Increase volume.

Decrease volume.

Mute / Restore sound by
simultaneously pressing the
increase and decrease volume
buttons.

Steering mounted controls
– Type 2

Access to the main menu.

Increase volume.

Mute / Restore the sound.

Decrease volume.

Bluetooth

audio system

Start voice recognition on your
smartphone via the system.

Radio:
Short press: display the list of radio
stations.
Long press: update the list.
Media:
Short press: display the list of
folders.
Long press: display the available
sorting options.

Menus

Depending on version.

"Multimedia": Media settings, Radio
settings.

"Telephone": Call, Directory
management, Telephone
management, Hang up.

"Trip computer".

"Maintenance": Diagnosis, Warning
log, etc .

"Connections": Manage
connections, search for devices.

"Personalisation-configuration":
Define the vehicle parameters,
Choice of language, Display
configuration, Choice of units, Date
and time adjustment.

Press the "MENU" button.

Move from one menu to another.

Enter a menu.

Radio

Selecting a station

Press the SOURCE button
repeatedly and select the radio.

Press this button to select a
waveband (FM / AM / DAB).

Press one of the buttons for an
automatic search for radio stations.

Press one of the buttons to carry out
a manual search up / down for radio
frequencies.

Press this button to display the list of
stations received locally.
To update this list, press for more
than two seconds. The sound is cut
while updating.

Bluetooth

audio system

RDS

The external environment (hills, buildings,
tunnels, basement car parks, etc.) may
block reception, including in RDS mode.
This is a normal effect of the way in
which radio waves are transmitted and
does not indicate any failure of the audio
equipment.

If RDS is not available, the RDS symbol
appears barred in the screen.

The RDS, if activated, enables you to
continue listening to the same station
by automatic retuning to alternative
frequencies. However, in certain
conditions, coverage of an RDS station
may not be assured throughout the entire
country as radio stations do not cover
100% of the territory. This explains the
loss of reception of the station during a
journey.

Short procedure

In "Radio" mode, press the OK button to
activate or deactivate RDS directly.

Select "Audio functions".

Press OK.

Select the "FM waveband
preferences" function.

Press OK.

Select "Frequency tracking
(RDS)".

Press OK, RDS is displayed on the
screen.

Play TA messages

The TA (Traffic Announcement) function
gives priority to TA alert messages.
To operate, this function needs good
reception of a radio station that carries
this type of message. When a traffic
report is transmitted, the current audio
source (Radio, CD, etc.) is interrupted
automatically to play the TA message.
Normal play of the media previously
playing is resumed at the end of the
message.

Take care when increasing the volume
while listening to TA messages. The
volume may prove too high on return to
the original audio source.

Press the TA button to activate or
deactivate traffic messages.

Long procedure

Press the MENU button.

Bluetooth

audio system

Receiving INFO messages

The INFO function gives priority to TA
alert messages. To be active, this function
needs good reception of a radio station
that transmits this type of message. When
a message is transmitted, the current
audio source (Radio, CD, USB, etc.) is
interrupted automatically to receive the
INFO message. Normal play of the media
previously playing is resumed at the end
of the message.

Make a long press on this button to
display the list of categories.

Select or deselect categories.

Activate or deactivate the reception
of the corresponding messages.

Display TEXT INFOS

Radio text is information transmitted by
the radio station related to the station's
current programme or song.

When the radio station is displayed
in the screen, press OK to display
the contextual menu.

Select "RadioText (TXT) display"
and confirm OK to save.

DAB (Digital Audio
Broadcasting) radio

According to version

If the current "DAB" radio station is not
available on "FM", "DAB FM" is struck out.

Option display: if active but not available,
the display will be struck out.

Display of the name of the current station.

Preset stations, buttons 1 to 6.
Short press: select the preset radio
station.
Long press: memorise a radio station.

Display the name of the "multiplex"
service being used, also called
"ensemble".

Display RadioText (TXT) for the current
radio station.

Represents the signal strength for the
band being listened to.

Bluetooth

audio system

Display of the list of all radio stations
and "multiplexes".

Terrestrial digital radio

Digital radio provides a superior audio
quality and also additional categories of
traffic announcements (TA INFO).
The different "multiplex services" offer a
choice of radio stations in alphabetical
order.

Change of band (FM1, FM2, DAB,
etc.)

Change of station within the same
"multiplex service".

Starting of a search for the previous
/ next "multiplex service".

Long press: selection of the
categories of news desired among
Transport, News, Entertainment and
Special Flash (available according to
the station).

When the radio station is displayed in
the screen, press "OK" to display the
contextual menu.
(Frequency search (RDS), DAB / FM
auto tracking, RadioText (TXT) display,
Information on the station, etc.)

DAB/FM station tracking

"DAB" does not have 100% coverage of
the country.
When the digital signal is weak,
"DAB / FM auto tracking" allows you to
continue listening to the same station,
by automatically switching to the
corresponding analogue "FM" station (if
it exists).
When the "DAB / FM auto tracking" is
active, the DAB station will be selected
automatically.

Press the MENU button.

Select "Multimedia" and confirm.

Select "DAB / FM auto tracking"
and confirm.

If "DAB / FM auto tracking" tracking is
enabled, there is a lag of a few seconds
when the system switches to analogue
radio "FM" sometimes with a change in
volume.

If the "DAB" station you are listening to is
not available on "FM" ("DAB/FM" option
barred), or if "DAB / FM auto tracking"
is not on, the sound will be cut when the
digital signal is too weak.

When changing region, an update of the
list of preset radio stations is advisable.

Bluetooth

audio system

Media

USB port

To protect the system, do not use a USB
hub.

Any additional equipment connected to
the system must conform to the standard
of the product or standard IEC 60950-1.

Playlists are updated every time a new USB
memory stick is connected.

When the USB port is used, the portable
device charges automatically.

Play mode

The play modes available are:
- Normal: the tracks are played in order,

depending on the classification of the
selected files.

- Random: the tracks in an album or folder

are played in a random order.

- Random on all media: all of the tracks

saved in the media are played in random
order.

- Repeat: the tracks played are only those

from the current album or folder.

Press this button to display the
contextual menu for the Media
function.

Press this button to select the
chosen play mode.

Press this button to confirm.

Insert the USB memory stick into the USB port
or connect the USB device to the USB port
using a suitable cable (not supplied).
The system changes automatically to "USB"
source.

The system builds playlists (in temporary
memory), an operation which can take from
a few seconds to several minutes at the first
connection.
Reduce the number of non-music files and the
number of folders to reduce the waiting time.

The choice made is displayed at the top of the
screen.

Choosing a track to play

Press one of these buttons to go to
the previous / next track.

Press one of these buttons to go to
the previous / next folder.

File classification

Make a long press on this button to
display the different classifications.

Select by "Folder" / "Artist" /
"Genre" / "Playlist".
Depending on availability and type
of device used.

Press OK to select the desired
classification, then press OK again
to confirm.

Bluetooth

audio system

Playing files

Make a short press on this button to
display the chosen classification.

Navigate in the list using the left /
right and up / down buttons.

Confirm the selection by pressing
OK.

Press one of these buttons to go to
the previous / next track in the list.
Press and hold one of these buttons
for fast forward or rewind.

Press one of these buttons to go
to the next "Folder" / "Artist" /
"Genre" / "Playlist"* previous / next
in the list.

Jack Input AUX (AUX)
socket

(depending on model / depending on equipment)

Any additional equipment connected to
the system must conform to the standard
of the product or standard IEC 60950-1.

Press the SOURCE button several
times in succession and select
"AUX".

First adjust the volume on your portable device
(to a high level). Then adjust the volume of your
audio system. Display and management of the
controls are via the portable device.

Do not connect a device to both the Jack
auxiliary socket and the USB port at the
same time.

CD player

Insert circular compact discs only.
Some anti-pirating systems, on original discs
or CDs copied using a personal recorder, may
cause faults which are no reflection on the
quality of the original player.
Insert a CD in the player, play begins
automatically.

External CD players connected via the
USB port are not recognised by the
system.

To play a disc which has already
been inserted, press the SOURCE
button several times in succession
and select "CD".

Press one of the buttons to select a
track on the CD.

Press the LIST button to display the
list of tracks on the CD.

Press and hold one of these buttons
for fast forward or rewind.

* Depending on availability and the type of

device used.

Connect the portable device (MP3 player, etc.)
to the auxiliary Jack socket using an audio
cable (not supplied).

Bluetooth

audio system

Playing an MP3 compilation

Insert an MP3 compilation in the CD player.
The audio equipment searches for all of the
music tracks, which may take anything between
a few seconds and several tens of seconds,
before play begins.

On a single disc, the CD player can
read up to 255 MP3 files spread over
8 directory levels.
However, it is advisable to keep to a limit
of two levels to reduce the access time
before the CD is played.
The folder structure is not observed during
playback.
All of the files are displayed on a single
level.

To play a disc which has already
been inserted, press the SOURCE
button several times in succession
and select "CD".

Press one of the buttons to select a
folder on the CD.

Press one of the buttons to select a
track on the CD.

Press the LIST button to display
the list of directories of the
MP3 compilation.

Press and hold one of these buttons
for fast forward or rewind.

Bluetooth

audio streaming

Streaming allows music files on the telephone
to be played via the vehicle's loudspeakers.

Connect the telephone.
(Refer to the "Pairing a telephone" section).

Activate the streaming source by
pressing SOURCE.
In certain cases, play of the audio
files must be initiated from the
keypad.

Audio files can be selected using the buttons
on the audio system control panel and the
steering mounted controls The contextual
information can be displayed in the screen, if
the telephone supports the function. The audio
quality depends on the quality of transmission
by the telephone.

Connecting Apple

players

Connect the Apple

player to the USB port

using a suitable cable (not supplied).
Play starts automatically.

Control is via the audio system.

The classifications available are those of the
portable device connected (artists / albums /
genres / playlists).

The version of software in the audio system
may not be compatible with the generation of
your Apple

player.

Information and advice

The CD player can play files with ".mp3",
".wma", ".wav" and ".aac" file extensions, with a
bit rate of 32 to 320 Kbps.
It also supports TAG mode (ID3 tag, WMA
TAG).
No other file types (.mp4, etc.) can be read.
Files of the ".wma" type should be to the wma
9 standard.
The sampling rates supported are 11, 22,
44 and 48 kHz.

Bluetooth

audio system

File names should have fewer than
20 characters, avoiding special characters (e.g.
" ? ; ù) so as to avoid any reading or display
problems.

In order to be able to play a burned CDR or
CDRW, select standards ISO 9660 level 1, 2 or
Joliet if possible when burning the CD.
If the disc is burned in another format, it may
not be played correctly.
It is recommended that the same burning
standard is always used on an individual disc,
with the lowest speed possible (4x maximum)
for the best acoustic quality.
In the particular case of a multi-session CD, the
Joliet standard is recommended.

To protect the system, do not use a USB hub.

Use only USB memory sticks formatted
FAT 32 (File Allocation Table).

It is recommended that you use genuine
Apple

USB cables for correct operation.

Telephone

Pair a Bluetooth

telephone

As a safety measure and because they
require prolonged attention on the part
of the driver, the operations for pairing
of the Bluetooth mobile telephone with
the Bluetooth hands-free system of your
audio system must be carried out with the
vehicle stationary and the ignition on.

Activate the telephone's Bluetooth
function and ensure that it is "visible to all"
(telephone configuration).

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth telephone
used.
Check the instructions for your telephone
and with your service provider for the
services to which you have access.

Procedure from the telephone

Select the name of the system in the
list of devices detected.

Via the USB port, the system can play audio
files with the ".mp3", ".wma", ".wav", ".cbr",
and ".vbr" extension with a bit rate of 32 to
320 Kbps.
No other file types (".mp4", etc.) can be read.
Files of the ".wma" type should be to the wma
9 standard.
The sampling rates supported are 11, 22,
44 and 48 kHz.

Bluetooth

audio system

Procedure from the system

Press the MENU button.

Select "Connections".

Confirm with OK.

Select "Search for a device".

Confirm with OK.

A window is displayed with a search in progress
message.

In the list of devices detected, select a
telephone to pair. Only one telephone can be
paired at a time.

Completing the pairing

To complete the pairing, whichever
procedure used (from the telephone or
from the system), ensure that the code
is the same in the system and in the
telephone.

If pairing fails, the number of attempts is not restricted.
A message appears in the screen confirming the
pairing.

Information and advice

The "Telephone" menu gives access to the
following functions in particular: "Directory", if
your telephone equipment is fully compatible,
"Call log", "View paired devices".
Depending on the type of telephone, you may
be asked to accept or confirm access by the
system to each of these functions.

Go to the Brand's website for more
information (compatibility, more help, etc.).

Manage connections

The telephone connection automatically
includes hands free operation and audio
streaming.
The ability of the system to connect to just
one profile depends on the telephone.
Both profiles may connect by default.

Press the MENU button.

Select "Connections".

Confirm with OK.

Select "Connections
management" and confirm. The list
of paired devices is displayed.

Confirm with OK.

Indicates that a device is connected.

A number indicates the profile of the
connection with the system:
- 1 for media or 1 for telephone.
- 2 for media and telephone.

Indicates connection of the audio
steaming profile.

Indicates the hands-free telephone
profile.

Select a telephone.

Confirm with OK.

Content .. 22 23 24 25 ..
