Peugeot 5008 (2017 year). Manual

Dashboard instruments

Warning / indicator lamp

State

Cause

Action / Observations

Brakes

Fixed.

A minor fault with the braking
system.

Drive carefully.
Have the system checked by a PEUGEOT dealer or a
qualified workshop as soon as possible.

Fixed.

The brake fluid level has
dropped significantly.

You must stop as soon as it is safe to do so.
Top up with brake fluid approved by PEUGEOT.
If the problem persists, have the system checked by a
PEUGEOT dealer or a qualified workshop.

Fixed, associated
with the ABS warning
lamp.

The electronic brake force
distribution (EBFD) system has
a fault.

You must stop as soon as it is safe to do so.
Have it checked by a PEUGEOT dealer or a qualified
workshop.

Anti-lock
Braking System
(ABS)

Fixed.

The anti-lock braking system
has a fault.

The vehicle retains conventional braking.
Drive carefully at reduced speed and contact a
PEUGEOT dealer or a qualified workshop without
delay.

Dynamic
stability control
(DSC/ASR)

Flashing.

The DSC/ASR regulation is
operating.

The system optimises traction and improves the
directional stability of the vehicle in the event of loss
of grip or trajectory.

Fixed.

The DSC/ASR system has a
fault.

Have the system checked by a PEUGEOT dealer or a
qualified workshop.

Dashboard instruments

Warning / indicator lamp

State

Cause

Action / Observations

Service

Temporarily on, with a
message displayed.

One or more minor faults for
which there is no specific
warning lamp have been
detected.

Identify the cause of the fault using the message
displayed in the instrument panel.
You can deal with some problems yourself, such
as a door open or the start of saturation of the
particle filter (as soon as the traffic conditions allow,
regenerate the filter by driving at a speed of at least
40 mph (60 km/h), until the warning lamp goes off).
For any other problems, such as a fault with the tyre
under-inflation detection system, contact a PEUGEOT
dealer or a qualified workshop.

Fixed, accompanied
by the display of a
message.

One or more major faults for
which there is no specific warning
lamp have been detected.

Identify the cause of the fault using the message
displayed in the instrument panel; you must then
contact a PEUGEOT dealer or a qualified workshop.

Fixed, associated with
the flashing and then
fixed display of the
service indicator spanner.

The servicing interval has been
exceeded.

Only on BlueHDi Diesel versions.
Your vehicle must be serviced as soon as possible.

Distance alert /
Active Safety
Brake

Flashing.

The system is operating.

The system brakes briefly so as to reduce the speed
of collision with the vehicle ahead.

Fixed, accompanied
by a message and an
audible signal.

The system has a fault.

Have the system checked by a PEUGEOT dealer or a
qualified workshop.

Dashboard instruments

Warning / indicator lamp

State

Cause

Action / Observations

Distance alert /
Active Safety
Brake

Fixed, accompanied
by a message.

The system has been
deactivated, via the vehicle
configuration menu.

For more information on the Distance alert / Active
Safety Brake system, refer to the corresponding
section.

Lane Departure
Warning System

Flashing,
accompanied by an
audible signal.

A lane marking has been
crossed on the left or right.

Turn the steering wheel in the opposite direction to
return to the correct trajectory.
For more information on the Lane Departure
Warning System, refer to the corresponding section.

Fixed, accompanied
by the display of a
message.

The system has a fault.

Be vigilant and drive carefully.
Have the system checked by a PEUGEOT dealer or a
qualified workshop.

Active Lane
Departure
Warning System

Fixed.

The system has been
automatically deactivated or
placed on standby.

For more information on the Active Lane Departure
Warning System, refer to the corresponding section.

Flashing.

You are about to cross a broken
lane marking without operating
the direction indicators.

The system is activated, then corrects the trajectory
on the side of the lane marking detected.

Fixed, accompanied
by the display of
a message, an
audible signal and
the Service warning
lamp.

The system has a fault.

Be vigilant and drive carefully.
Have the system checked by a PEUGEOT dealer or a
qualified workshop.
For more information on the Active Lane Departure
Warning System, refer to the corresponding section.

Dashboard instruments

Warning / indicator lamp

State

Cause

Action / Observations

Airbags

Temporarily on.

This warning lamp comes on for
a few seconds when you turn on
the ignition, then goes off.

This warning lamp should go off when the engine is started.
If it does not go off, contact a PEUGEOT dealer or a
qualified workshop.

Fixed.

One of the airbag or seat belt
pretensioner systems has a fault.

Have them checked by a PEUGEOT dealer or a
qualified workshop.

Under-inflation

Fixed.

One or more wheels has
insufficient pressure.

Check the pressure of the tyres as soon as possible.
This check should preferably be carried out when the
tyres are cold.

Flashing then fixed,
accompanied by the
Service warning lamp.

The tyre pressure monitoring
system is faulty.

Under-inflation detection is no longer assured.
Have the system checked by a PEUGEOT dealer or a
qualified workshop.

Passenger's
front airbag

Fixed, in the seat belt
and passenger's front
airbag warning lamps
display.

The control switch, located in
the glove box, is set to the "OFF"
position.
The passenger's front airbag is
deactivated.
You may install a rearward
facing child seat, unless there is
a fault with the airbags (airbag
warning lamp on).

Set the control to the "ON" position to activate the
passenger front airbag. In this case, do not install a
rearward facing child seat on this seat.

Dashboard instruments

Warning / indicator lamp

State

Cause

Action / Observations

Passenger's
front airbag

Fixed, in the seat belt
and passenger's front
airbag warning lamps
display.

The control switch, located in the
glove box, has been placed in
the ON position.
The passenger's front airbag is
activated.

In this case, do not install a rearward facing child seat
on this seat.
Move the control switch to the OFF position to
deactivate the passenger's front airbag. In this case,
you may install a rearward facing child seat, unless
there is a fault with the airbags (airbag warning lamp
on).

Low fuel level

Fixed, with reserve
level shown in red,
with the display of
a message and an
audible signal.

When it first comes on there
remains approximately 6 litres
of fuel in the tank.

You must refuel as soon as possible to avoid running
out of fuel.
This warning lamp will come on every time the
ignition is switched on, accompanied by a message
and an audible signal, until a sufficient addition of fuel
is made.
This audible signal and message are repeated with
increasing frequency as the fuel level drops and
approaches "0".
Fuel tank capacity: approximately 56 litres.
Never continue to drive until you run out of fuel as
this could damage the emission control and injection
systems.

Engine
diagnostic
system

Flashing.

The engine management system
has a fault.

There is a risk that the catalytic converter will be destroyed.
Have it checked by a PEUGEOT dealer or a qualified
workshop.

Fixed.

The emission control system has
a fault.

The warning lamp should go off when the engine is started.
If it does not go off, contact a PEUGEOT dealer or a
qualified workshop without delay.

Dashboard instruments

Warning / indicator lamp

State

Cause

Action / Observations

AdBlue

(BlueHDi Diesel)

Fixed, on switching
on the ignition,
accompanied by an
audible signal and a
message indicating the
remaining driving range.

The remaining driving range is
between 375 miles (600 km) and
1,500 miles (2,400 km).

Top up the AdBlue

to the required level as soon as

possible or contact a PEUGEOT dealer or a qualified
workshop.
You can add up to 10 litres of AdBlue

to its tank.

Flashing,
accompanied by an
audible signal and a
message indicating
the remaining driving
range.

The driving range is less than
375 miles (600 km).

You must top up the AdBlue

to avoid a breakdown

or go to a PEUGEOT dealer or a qualified workshop.
You can add up to 10 litres of AdBlue

to its tank.

Flashing,
accompanied by an
audible signal and a
message indicating
that starting is
prevented.

The AdBlue

tank is empty:

the starting inhibition system
required by legislation prevents
starting of the engine.

To be able to start the engine, you must top up the
AdBlue

or go to a PEUGEOT dealer or a qualified

workshop.
It is essential to add at least 4 litres of AdBlue

to its

tank.

Dashboard instruments

Warning / indicator lamp

State

Cause

Action / Observations

SCR emissions
control system
(Diesel BlueHDi)

Fixed, on switching on the
ignition, associated with
the service and engine
diagnostic warning
lamps, accompanied by
an audible signal and a
message.

A fault with the SCR emissions
control system has been
detected.

This alert disappears once the exhaust emissions
return to normal levels.

Flashing, on switching
on the ignition,
associated with the
service and engine
diagnostic warning
lamps, accompanied by
an audible signal and a
message indicating the
remaining driving range.

After confirmation of the fault
with the emissions control
system, you can drive for up to
685 miles (1,100 km) before the
engine starting inhibition system
is triggered.

Contact a PEUGEOT dealer or a qualified workshop
without delay, to avoid a breakdown.

Flashing, on switching
on the ignition,
associated with the
service and engine
diagnostic warning
lamps, accompanied
by an audible signal
and a message.

You have exceeded the
authorised driving limit following
confirmation of a fault with the
emissions control system: the
engine starting inhibition system
prevents starting of the engine.

To be able to start the engine, you must call on a
PEUGEOT dealer or a qualified workshop.

For topping up or for more information on AdBlue

and the SCR system, refer to the corresponding section.

Dashboard instruments

Diesel engine
pre-heating

Fixed.

When the ignition is switched
on with a key in the ignition
switch or a starting instruction is
made using the "START/STOP"
button, the engine temperature
makes engine pre-heating
necessary.

The period of illumination of the indicator lamp is
determined by the ambient conditions (up to about
thirty seconds in severe winter conditions).
With an ignition switch and key, wait until the indicator
lamp goes off before starting.
With Keyless Entry and Starting, once it goes off,
starting is immediate, on the condition that the brake
pedal remains pressed with an automatic gearbox.
With Keyless Entry and Starting, once it goes off,
starting is immediate, on the condition that the clutch
pedal remains pressed with a manual gearbox.
If the engine does not start, switch the ignition off and
then on, wait until the indicator lamp goes off again,
then start the engine.

Warning / indicator lamp

State

Cause

Action / Observations

Stop & Start

Fixed, accompanied
by the display of a
message.

The Stop & Start system is
deactivated.

The engine will not switch off at the next traffic stop.
Reactivate the system by pressing the button again.
For more information on Stop & Start, refer to the
corresponding section.

Stop & Start

Fixed.

When the vehicle stops (red lights, traffic
jams, etc.), the Stop & Start system puts
the engine into STOP mode.

The warning lamp goes off and the engine restarts
automatically in START mode, as soon as you want
to move off.

Flashes for a few
seconds, then goes
off.

STOP mode is temporarily
unavailable.
or
START mode is invoked automatically.

For more information on Stop & Start, refer to the
corresponding section.

Dashboard instruments

Hill Assist
Descent Control

Fixed.

The system has been activated,
but is paused because the
speed is too high.

Between 20 and 30 mph (30 and 50 km/h), the
system is paused.
Reduce the speed of the vehicle.

Fixed.

The system has been activated,
but the conditions for regulation
are not met (gradient, gear
engaged).

Flashing.

The system is regulating the
speed of the vehicle.

The vehicle is being braked; the brake lamps come on
during the descent.
For more information on the Hill Assist Descent
Control function, refer to the corresponding section.

Warning / indicator lamp

State

Cause

Action / Observations

Blind Spot
Monitoring
System

Fixed.

The function has been activated.

For more information on the Blind Spot Monitoring
System, refer to the corresponding section.

Park Assist

Fixed.

The system has been activated.

For more information on Park Assist, refer to the
corresponding section.

Automatic
wiping

Fixed.

The wiper control stalk has been
pushed down.
Automatic front wiping is
activated.

To deactivate automatic wiping, push the wiper
control stalk down again or put the wiper control stalk
in another position.

Rear foglamps

Fixed.

The rear foglamps have been
switched on using the ring on the
lighting control stalk.

Turn the ring on the lighting control stalk rearwards to
switch off the rear foglamps.

Dashboard instruments

Warning / indicator lamp

State

Cause

Action / Observations

Front foglamps

Fixed.

The front foglamps have been
switched on using the ring on the
lighting control stalk.

Turn the ring on the lighting control stalk rearwards to
switch off the foglamps.

Left-hand
direction
indicator

Flashing with audible
signal.

The lighting control stalk has
been moved down.

Right-hand
direction
indicator

Flashing with audible
signal.

The lighting control stalk has
been moved up.

Hazard warning
lamps

Flashing with buzzer.

The hazard warning lamps
switch, located on the
dashboard, has been operated.

The left-hand and right-hand direction indicators and
their associated warning lamps flash simultaneously.

Sidelamps

Fixed.

The lighting control stalk is in the
"Sidelamps" position.

Dipped beam
headlamps

Fixed.

The lighting control stalk is in
the "Dipped beam headlamps"
position.

Main beam
headlamps

Fixed.

The lighting control stalk has
been pulled towards you.

Pull the lever to return to dipped beam headlamps.

Dashboard instruments

Warning / indicator lamp

State

Cause

Action / Observations

Automatic
headlamp
dipping

Fixed.

The function has been activated
via the Vehicle / Driving menu
of the touch screen.
The lighting control stalk is in the
"AUTO" position.

The camera, placed at the top of the windscreen,
manages the main beam headlamps or dipped
headlamps operation, according to the outside
lighting and the driving conditions.
For more information on Automatic headlamp
dipping, refer to the corresponding section.

For more information on the Lighting control stalk, refer to the corresponding section.

Dashboard instruments

Electric parking brake

Warning /
indicator lamp

State

Cause

Action / Observations

It lights up,
accompanied by the
display of the "Parking
brake fault" message.

Automatic release is not
available.

If you try to effect an automatic release, a help message is displayed
upon acceleration when the parking brake is applied, prompting you to
use manual release.

They light up,
accompanied by the
display of the "Parking
brake fault" message.

Emergency braking does not
have full power.

If automatic release is not available, a help message is displayed upon
acceleration when the parking brake is applied, prompting you to use
manual release.

They light up,
accompanied by the
display of the "Parking
brake fault" message.

Automatic application is not
available.

The electric parking brake control lever must be used.
The electric parking brake can only be used manually.
If automatic release is also not available, a help message is displayed
upon acceleration when the parking brake is applied, prompting you to
use manual release.

They light up,
accompanied by the
display of the "Parking
brake fault" message.

You can no longer immobilise
the vehicle with the engine
running.

If manual application and release are not working, the electric parking
brake control lever is faulty.
The automatic functions must be used at all times: they are automatically
reactivated in the event of failure of the control lever.

Dashboard instruments

Warning /
indicator lamp

State

Cause

Action / Observations

They light up,
accompanied by the
display of the "Parking
brake fault" message.

The parking brake is faulty:
manual and automatic
functions may not be working.

When stationary, to immobilise your vehicle:
F Pull and hold the control lever for approximately 7 to 15 seconds, until

the warning lamp comes on in the instrument panel.

If this procedure does not work, you should secure your vehicle as
follows:
F  Park on a level surface.
F  With a manual gearbox, engage a gear.
F  With an automatic gearbox, select mode P, then put the supplied

chocks against one of the wheels.

Call a PEUGEOT dealer or a qualified workshop.

They light up,
accompanied by the
display of the "Parking
brake fault" message.

The parking brake is not
operating at maximum
efficiency and cannot secure
the vehicle in every situation.

You should secure your vehicle as follows:
F  Park on a level surface.
F  With a manual gearbox, engage a gear.
F  With an automatic gearbox, select mode P, then put the supplied

chocks against one of the wheels.

Call a PEUGEOT dealer or a qualified workshop.

They flash when the
vehicle has been
started.

The parking brake has not
been properly released.

As soon as possible, stop the vehicle and try to completely release the
parking brake using the control lever, with your foot on the brake pedal.
If the problem persists, call a PEUGEOT dealer or a qualified workshop.

For more information on the use of the Electric parking brake, refer to the corresponding section.

Dashboard instruments

Indicators

Service indicator

Warning / indicator lamp

State

Cause

Action / Observations

Service spanner

Fixed, temporary
when the ignition is
switched on.

There are between 620 miles
(1,000 km) and 1,860 miles
(3,000 km) before the next
service is due.

The service indicator is displayed for a few seconds on
the instrument panel. Depending on the version:
- the distance recorder display line indicates the

distance remaining (in kilometres or miles) before
the next service is due.

- an alert indicates the distance remaining (in

kilometres or miles) as well as the period before
the next service is due.

The service spanner goes off after a few seconds.
The alert may be triggered close to the due date.

Fixed, when the
ignition is switched on.

Less than 620 miles (1,000 km)
remain before the next service
is due.

The service indicator is displayed for a few seconds on
the instrument panel. Depending on the version:
- the distance recorder display line indicates the

distance remaining before the next service is due.

- an alert message indicates the distance remaining

as well as the period before the next service is due.

The service spanner remains on to indicate that the
service is required very soon.
The alert may be triggered close to the due date.

Dashboard instruments

Warning / indicator lamp

State

Cause

Action / Observations

Service spanner

Flashing then fixed,
when the ignition is
switched on.

The servicing interval has been
exceeded.

The service indicator is displayed for a few seconds on
the instrument panel. Depending on version:
- the total distance recorder display line indicates the

distance travelled since the due date was reached.
Value preceded by the "-" sign.

- an alert message indicates that the due date has

passed.

The service spanner remains on until the service has
been performed.
The alert is triggered when the due date has been
exceeded.

Flashing then fixed,
when the ignition
is switched on,
associated with the
Service warning lamp.

The servicing interval has been
exceeded for Diesel BlueHDi
versions.

The service indicator is displayed for a few seconds on
the instrument panel. Depending on version:
- the total distance recorder display line indicates the

distance travelled since the due date was reached.
Value preceded by the "-" sign.

- an alert message indicates that the due date has

passed.

The service spanner remains on until the service has
been performed.
The alert is triggered when the due date has passed.

The distance indicated (in kilometres or miles) is calculated according to the mileage covered and the time elapsed since the last service.

Dashboard instruments

Resetting the service indicator

The service indicator must be reset after each
service.
If you have carried out the service on your
vehicle yourself:
F switch off the ignition,

If you have to disconnect the battery
following this operation, lock the vehicle
and wait at least 5 minutes for the reset to
be registered.

Retrieving the service
information

You can access the service information at any
time.

Engine oil level indicator

F press and hold the trip distance recorder

reset button,

F switch on the ignition; the distance recorder

display begins a countdown,

F release the button when "=0" is displayed;

the spanner disappears.

F Press the trip distance recorder reset

button.

The service information is displayed for a
few seconds, then disappears.

(depending on version)

On versions fitted with an electric oil level
indicator, the state of the engine oil level is
displayed in the instrument panel for a few
seconds, after the servicing information.

The level read will only be correct if the
vehicle is on level ground and the engine
has been off for more than 30 minutes.

Peugeot 5008 (2017 year). Manual - part 2
