Peugeot 508 (2016 year). Manual - part 23





.

Audio and Telematics

351

508_en_Chap10d_RD5_ed01-2016

QUESTION

ANSWER

SOLUTION

the CD is ejected
automatically or is not
played by the player.

the CD is inserted upside down, is unplayable, does not contain any
audio data or contains an audio format which the player cannot play.
the CD is protected by an anti-pirating protection system which is
not recognised by the audio equipment.

Check that the CD is inserted in the player the
right way up.

Check the condition of the CD: the CD cannot
be played if it is too damaged.

Check the content in the case of a recorded
CD: consult the advice in the "Audio" section.

the audio equipment's CD player does not
play DVDs.

Due to their quality level, certain writeable
CDs will not be played by the audio system.

the CD player sound is
poor.

the CD used is scratched or of poor quality.

Insert good quality CDs and store them in suitable
conditions.

the audio settings (bass, treble, ambience) are unsuitable.

Set the treble or bass level to 0, without selecting
an ambience.

the message "uSB
peripheral error" or
"Peripheral not recognised"
is displayed in the screen.

the uSB memory stick is not recognised.
the memory stick may be corrupt.

Reformat the memory stick (FAt 32).

the Apple

®

 player is

not recognised when
connecting to the uSB
port.

the Apple

®

 player is of a generation that is not compatible with the

uSB.

Connect the Apple

®

 player to the AuX Jack socket

using a suitable cable (not supplied).

Audio and Telematics

352

508_en_Chap10d_RD5_ed01-2016

QUESTION

ANSWER

SOLUTION

the hard disk or device
is not recognised when
connecting to the uSB
port.

Some hard disks and devices need a power supply greater than is
provided by the audio system.

Connect the device to the 230 V socket, the 12 V
socket or an external power supply.
Caution: ensure that the device does not transmit
a voltage greater than 5 V (risk of destruction of
the system).

In "Random all" play, not all
of the tracks are played.

In "Random all" play, the system can only take into account up to
999 tracks.

With the engine off, the
audio system switches off
after a few minutes of use.

When the engine is switched off, the audio system operating time
depends on the battery charge.
the switch-off is normal: the audio system switches to economy
mode and switches off to prevent discharging the vehicle's battery.

Start the vehicle's engine to increase the battery
charge.

the message "the audio
system is overheated"
appears on the display.

In order to protect the installation if the surrounding temperature
is too high, the audio system switches to an automatic thermal
protection mode leading to a reduction of the volume or stopping of
the playing of the CD.

Switch the audio system off for a few minutes to
allow the system to cool.

353

.

Alphabetical index

508_en_Chap11_index-alpha_ed01-2016

ABS ...............................................................133
Accessories .................................................. 131
Adaptive lighting ............................................122
AdBlue

®

 .............................................24, 32, 223

Additive, Diesel .....................................220, 221
Adjusting headlamps ....................................126
Adjusting head restraints ..........................75, 78
Adjusting seats ..........................................75, 76
Adjusting the date ..................................... 47, 48
Adjusting the height and reach

of the steering wheel ....................................79

Adjusting the seat belt height ....................... 137
Adjusting the time ..................................... 47, 48
Advice on driving ..................................159, 160
Airbags .................................................... 27, 139
Airbags, curtain ..................................... 141, 142
Airbags, front......................................... 139, 142
Airbags, lateral ...................................... 141, 142
Air conditioning .............................11, 86, 88, 91
Air conditioning, dual-zone .............................88
Air conditioning, manual .................................86
Air conditioning, quad-zone ............................91
Air vents ..........................................................83
Alarm ...............................................................70
Anti-lock braking system

(ABS) ..........................................................133

Anti-theft .....................................52, 61, 69, 167
Armrest ............................................................99
Armrest, front ................................................107
Armrest, rear ................................................. 111
ASR ...............................................................133
Assistance call ...................................... 132, 274
Audio streaming (Bluetooth) .........................294
Audio system  ................................................337
Auxiliary socket ............................ 108, 292, 346

Cable, audio ......................................... 292, 346
Capacity, fuel tank ........................................200
Cap, fuel filler ................................................200
CD ........................................................ 292, 343
Central locking ................................... 49, 55, 64
Centre console ..............................................107
Changing a bulb ............................................242
Changing a fuse ............................................249
Changing a wheel .........................................235
Changing a wiper blade ........................ 130, 211
Changing the remote control battery ........54, 63
Checking the engine oil level .................. 31, 218
Checking the levels ....................................... 218
Checking tyre pressures (using the kit) ........234

DAB (Digital Audio Broadcasting) -

Digital radio .................................................290

Date (setting) ............................................. 47, 48
Daytime running lamps ......... 118, 120, 242, 243
Deactivating ASR ..........................................135
Deactivating the passenger airbag ...............140
Deadlocking .............................................. 51, 60
Demisting/defrosting, front, rear .....................96
Dimensions ................................................... 271
Dipstick .................................................... 31, 218
Direction indicators ................120, 125, 242-246
Display screen, instrument panel .............13, 28
Driving economically....................................... 11

Checks .................................................. 215-222
Child lock .......................................................158
Children ..................................138, 140, 143-158
Child seats, general  ......................138, 143-145
Child seats, conventional ......................149, 150
Child seats, ISOFIX ...............................152-155
Closing the boot ..............................................65
Configuration, vehicle .....................................28
Connection, Bluetooth ..........................324, 325
Control, back-up boot release ........................68
Control, back-up door .....................................53
Control, heated seats ......................................78
Control stalk, lighting .................................... 117
Control stalk, wipers .....................................127
Courtesy lamps .............................................102
Cover, load space ......................................... 114
Cruise control ........................................190, 192
Cup holder ............................................... 99, 111

A

C

D

B

Battery ........................................... 221, 253-260
Battery, charging ...........................................255
Battery, remote control ...................... 54, 63, 69
Blanking screen

(snow shield) ...................................... 204, 205

Blind, sunroof ................................................104
Blind, panoramic roof ....................................106
Blind spot monitoring system ........................196
BlueHDi ...........................................35, 175, 223
Bluetooth (telephone) ............................324, 325
Boot ...............................................55, 57, 65, 68
Boot monitoring system ............................65, 68
Boot, motorised .........................................66, 68
Brake discs, pads ..........................................222
Brake lamps ..........................................245, 246
Brake warning lamp ........................................22
Braking assistance, emergency ...................133
Bulbs (changing) ...........................................242

354

Alphabetical index

508_en_Chap11_index-alpha_ed01-2016

gauge, fuel..............................................13, 200
gearbox,

automatic ........11, 16, 176, 180, 183, 222, 253

gearbox, manual ...... 11, 16, 174, 180, 183, 222
gear lever, automatic gearbox ..................... 176
gear lever, manual gearbox ......................... 174
gear shift indicator ....................................... 175
glove box ......................................................101
ground clearance .........................................272
guide-me-home .................................... 121, 124

Identification, vehicle ....................................273
Immobiliser, electronic ................52, 61, 69, 167
Indicator, coolant temperature ........................30
Indicator, engine oil level ................................31
Indicator lamps ................................................ 14
Indicators, direction ......................................120
Inflating tyres .......................................... 11, 273
Inflating tyres and accessories

(using the kit) ..............................................234

Input, auxiliary .............................. 108, 292, 346
Instrument panel ............................................. 13
Instruments and controls ..................................7
Intelligent traction Control ............................134
ISOFIX ...................................................152-156

Hazard warning lamps ..........................132, 227
Headlamp adjustment ...................................126
Headlamps, automatic illumination ...... 118, 121
Headlamps, dipped beam ............. 117, 242, 244
Headlamps, halogen .............................242, 244
Headlamps, main beam ................ 117, 242, 244
Headlamp wash ............................................128
Head restraints, front ................................75, 78
Head restraints, rear .....................................109
Head-up display ............................184, 188, 190
Heating ......................................... 83, 86, 88, 91
Heating, programmable (Webasto) ................97
Hill start assist ...............................................183
Horn............................................................... 132

Filling the fuel tank ............................... 200, 202
Filter, air ........................................................221
Filter, oil .........................................................221
Filter, particle ........................................220, 221

G

I

E

H

F

Driving positions (storing) ...............................77
Dynamic stability control (DSC) ........18, 22, 133

Filter, passenger compartment .....................221
Fitting a wheel ...............................................240
Fitting roof bars ............................................. 212
Fittings, boot ......................................... 112, 113
Fittings, front ...................................................99
Fittings, rear .................................................. 111
Flap, fuel filler ................................................200
Flashing indicators ................................ 120, 125
Foglamps, front ............................. 119, 123, 242
Foglamps, rear .............................. 119, 245, 246
Folding the rear seats ...................................109
Folding/unfolding the door mirrors .................80
Frequency (radio) ..........................................288
Fuel................................................................202
Fuel consumption ............................................ 11
Fusebox, dashboard .....................................250
Fusebox, engine compartment .....................252
Fuses .............................................................249

eBA ...............................................................133
eco-driving (advice) ........................................ 11
electronic brake force distribution

(eBFD) ........................................................133

emergency call ..................................... 132, 274
emergency switching off ...............................166
emergency warning lamps ...................132, 227
emissions control system, SCR .............25, 223
energy economy mode .................................261
engine compartment .............................215-217
engine,

Diesel ............16, 202, 216, 217, 228, 266, 268

engine, petrol ....................... 202, 215, 264, 265
environment .........................11, 54, 63, 96, 179,

186, 220, 226, 253

355

.

Alphabetical index

508_en_Chap11_index-alpha_ed01-2016

Keyless entry and

Starting electronic key ..................... 55, 56, 69

Key not recognised .......................... 54, 62, 166
Key with remote control ............................49, 69
Kit, hands-free ......................................324, 325
Kit, temporary puncture repair ......................229

Labels, identification .....................................273
Lamps, parking .............................................125
LeDs - light-emitting diodes .........242, 245, 246
Level, AdBlue

®

 additive .................................223

Level, brake fluid ........................................... 219
Level, Diesel additive ............................220, 221
Level, engine coolant ..............................30, 220
Level, engine oil ...................................... 31, 218
Level, headlamp wash ..........................129, 220
Level, power steering fluid ............................ 219
Levels and checks ................................ 215-220

Jack ...............................................................235
JBL (audio system) .......................................276
Jump starting ................................................254

Level, screenwash fluid ........................129, 220
Lighting, cornering ........................................123
Lighting dimmer ..............................................32
Lighting, guide-me home ...................... 121, 124
Lighting, interior ....................................102, 103
Lighting, mood ..............................................103
Lighting, welcome .........................................125
Loading ................................................... 11, 212
Load reduction mode ....................................261
Locating your vehicle ................................52, 61
Locking ............................................... 50, 58, 64
Locking, manual (back-up) .............................62
Long objects, transporting ............................ 111
Low fuel level ..........................................23, 201
Luggage retaining strap ................................ 112

K

L

J

Maintenance, routine ...................................... 11
Map reading lamps .......................................102
Markings,

identification ...............................................273

Massage function  ...........................................79
Mat ................................................................100
Memorising a speed .....................................192
Menu, touch screen .....277, 281, 282, 284, 286

296, 298, 302, 310, 320, 322

Menu, audio system ............................. 340, 348
Mirror, rear view ..............................................82
Mirrors, door......................................80, 81, 196
Mirror, vanity ................................................. 101
Misfuel prevention .........................................201
Mountings, Isofix ...........................................152
MP3 CD ................................................ 343, 344

M

Navigation .....................................................296
Net, high load retaining ................................. 115
Number plate lamps ......................................248

Oil consumption ............................................ 218
OIl, engine ..................................................... 218
Opening the boot ................................ 50, 57, 65
Opening the doors ....................................49, 55
Opening the roof blind ..........................104, 106

Pads, brake ...................................................222
Paint colour code ..........................................273
Panoramic glass sunroof ..............................106
Parking brake ........................................ 167, 222
Parking brake, electric ............................ 21, 168
Parking sensors, front ...................................194
Parking sensors, rear....................................193
PeugeOt Connect Apps ............................. 319
PeugeOt Connect Assistance ................... 274
PeugeOt Connect Packs ........................... 274
PeugeOt Connect SOS ............................. 274
Plates, identification......................................273

O

P

N

356

Alphabetical index

508_en_Chap11_index-alpha_ed01-2016

Player, Apple

®

 ...................................... 294, 345

Player, MP3 CD ............................ 292, 343, 344
Port, uSB ..................................... 108, 292, 345
Pressures, tyres ............................................273
Pre-tensioning seat belts ..............................138
Priming the fuel system ................................228
Protecting

children ................................138, 140, 143-158

Puncture ........................................................229

Reservoir, headlamp wash /

screenwash.................................................220

Resetting the service indicator .......................34
Reversing camera .........................................199
Reversing lamp .....................................245, 246
Risk areas (update) .......................................307
Roof bars ....................................................... 212
Roof, opening ........................................104, 106
Running out of fuel (Diesel) ..........................228

Safety,

children ................................138, 140, 143-158

Saturation of the particle filter (Diesel) .........221
Screen, cold climate .....................................204
Screen, touch ................................................ 271
Screen, instrument panel ..........................28, 39
Screen menu map ............... 282, 284, 286, 296

298, 302, 310, 320, 322

Screen, multifunction

(with audio system) ............................ 340, 348

Screenwash, front/rear .................................128
SCR (Selective Catalytic Reduction) ............223
Seat belts ...............................................136-138
Seats, front ................................................ 75-77
Seats, heated ..................................................78
Seats, rear .....................................................109
Serial number, vehicle ..................................273
Service indicator .............................................33
Service warning lamp .....................................20
Servicing ......................................................... 11
Settings, system ......................................28, 310
Sidelamps ..................... 117, 125, 242, 245, 246

table of weights ................................... 265, 268
tables of engines ..................................264, 267
tables of fuses ..............................................249
tank, AdBlue

®

 additive .................................223

tank, fuel .......................................................200
technical data ...............................................264
telephone .....................................................320
temperature, coolant ......................................30
third brake lamp ...........................................248

S

T

Side repeater ................................................244
Ski flap .......................................................... 111
Snow chains ..................................................203
Socket, 12 V accessory ................ 101, 108, 111
Sockets, audio ..................... 108, 292, 345, 346
Speed limiter .........................................188, 192
Spotlamps, side ....................................125, 244
Stability control (DSC) ............................18, 133
Starting the engine ............................... 161, 165
Starting using another battery ......................254
Station, radio ........................................ 288, 340
Steering mounted controls, audio ....... 280, 339
Steering wheel, adjustment ............................79
Stop & Start ....................17, 42, 89, 92, 96, 180,

200, 214, 221, 253, 256

Storage .............................. 99, 101, 107, 111-113
Storage wells ................................................ 113
Storing driving positions .................................77
Stowing rings ........................................ 112, 113
Sun visor .......................................................101
Switching off the engine ....................... 161, 165
Synchronising the remote control .............54, 63

Radio .................................................... 288, 340
Radio, digital (Digital Audio

Broadcasting - DAB) ...................................290

Range, AdBlue ..........................................35, 36
RDS .......................................................289, 341
Rear screen, demisting ...................................96
Recharging the battery .................................255
Reduction of electrical load ..........................261
Regeneration of

the particle filter ..........................................221

Reinitialising the remote control ...............54, 63
Reminder, lighting on .................................... 119
Remote control ....................................49, 55, 69
Removing a wheel ........................................238
Removing the battery....................................257
Removing the mat .........................................100
Replacing bulbs ............................................242
Replacing fuses ............................................249
Replacing the air filter ...................................221
Replacing the oil filter ...................................221
Replacing the passenger

compartment filter ......................................221

R

357

.

Alphabetical index

508_en_Chap11_index-alpha_ed01-2016

three flashes

(direction indicators) ...................................120

time (setting) ............................................ 47, 48
tMC (traffic info) ..........................................308
tools ..................................................... 229, 235
topping-up the  AdBlue

®

 additive .................224

total distance recorder ...................................29
touch screen...............................41, 43, 48, 277
towball, quickly detachable ..........................206
towbar ...................................................160, 205
towbar with quickly detachable

towball .........................................................206

towed loads ......................................... 265, 268
towing another vehicle .................................263
traction control (ASR) ......................18, 22, 133
traffic information (tA) .........................309, 341
traffic information (tMC) ..............................308
trailer ....................................................160, 205
triangle, warning...........................................227
trip computer ............................................39, 41
trip distance recorder .....................................29
tyres ........................................................ 11, 273
tyre under-inflation

detection ....................................... 27, 186, 237

Ventilation ................................................. 83-86

V

Warning and indicator lamps .......................... 14
Warning lamp, braking system .......................22
Warning lamp, Diesel engine pre-heater .......16
Warning lamp, SCR emissions

control system ..............................................25

Warning lamp, Service....................................20
Weights ................................................ 265, 268
Welcome function ...........................................77
Wheel, spare ......................................... 235-237
Wiper blades (changing) ....................... 130, 211
Wiper, rear.....................................................128
Wipers ..................................................... 17, 127
Wipers, automatic rain sensitive ...................129

W

U

under-inflation (detection) .............. 27, 186, 237
unlocking ........................................... 49, 55, 64
unlocking the boot ....................................50, 57
updating risk areas .......................................307
updating the date ...................................... 47, 48
updating the time ...................................... 47, 48
uReA ......................................................35, 223
uSB (PeugeOt Connect) ...................108, 292

358

508_en_Chap11_index-alpha_ed01-2016

359

508_en_Chap11_index-alpha_ed01-2016

360

508_en_Chap11_index-alpha_ed01-2016

01-16

508_en_Chap12_Couv-fin_ed01-2016

Automobiles PeugeOt declares, by
application of the provisions of the european
regulation (Directive 2000/53) relating
to end of Life Vehicles, that it achieves
the objectives set by this regulation and
that recycled materials are used in the
manufacture of the products that it sells.

Reproduction or translation of all or part of
this document is prohibited without written
authorisation from Automobiles PeugeOt.

Labels are applied at various
points on your vehicle. they carry
safety warnings as well as vehicle
identification information. Do not
remove them: they form an integral
part of your vehicle.

Printed in the eu

Anglais

508_en_Chap12_Couv-fin_ed01-2016

Anglais

AN. 16508.0040

www.peugeot.com

2

Ease of use and comfort

508-additif_en_Chap03_ergonomie-et-confort_ed01-2016

 In order for these systems to be fully effective, follow the operation and maintenance
guidelines below:

   To obtain an even air distribution, take care not to obstruct the exterior air intake grilles

located at the base of the windscreen, the nozzles, the vents and the air outlets, as well
as the air extractor located in the boot.

   Do not cover the sunshine sensor, located on the dashboard; this is used for regulation

of the air conditioning system.

   Operate the air conditioning system for at least 5 to 10 minutes, once or twice a month

to keep it in perfect working order.

   Ensure that the passenger compartment filter is in good condition and have the filter

elements replaced regularly.



We recommend the use of a combined passenger compartment filter. Thanks to its
special active additive, it contributes to the purification of the air breathed by the
occupants and the cleanliness of the passenger compartment (reduction of allergic
symptoms, bad odours and greasy deposits).

   To ensure correct operation of the air conditioning system, you are also advised to have

it checked regularly as recommended in the warranty and maintenance record.

   If the system does not produce cold air, switch it off and contact a PEUGEOT dealer or

a qualified workshop.

         Recommendations  for  ventilation  and  air  conditioning

  The condensation created by the air
conditioning results in a discharge
of water under the vehicle which is
perfectly  normal.

Contains fluorinated greenhouse

gas R134A.

 Depending on version and country
of sale, the air conditioning system
contains fluorinated greenhouse
gas R134A. Gas capacity 0.525 kg
(+/- 0.025 kg), GWP index 1 430 t
(equivalent CO

2

: 0.751 t).

  If after an extended stop in sunshine,
the interior temperature is very
high, first ventilate the passenger
compartment for a few moments.
Put the air flow control at a setting high
enough to quickly change the air in the
passenger  compartment.

 When towing the maximum load on a steep gradient in high temperatures, switching off the
air conditioning increases the available engine power and so improves the towing ability.

3

7

Practical information

508-additif_en_Chap07_info-pratiques_ed01-2016

 Compatibility  of

fuels

          Fuel  used  for  petrol  engines

  The petrol engines are compatible with
bio-fuels that conform to current and future
European standards and can be obtained from
filling stations.

  The use of any other type of (bio)
fuel (vegetable or animal oils, pure
or diluted, domestic fuel...) is strictly
prohibited (risk of damage to the engine
and fuel system).

  The only Diesel additives authorised for
use are those that meet the B715000
standard.

   Travelling  abroad

Certain fuels could damage the

engine of your vehicle. In certain

countries, the use of a particular fuel

may be required (specific octane

rating, specific sales name…) to

ensure correct operation of the

engine.

 For any additional information, contact

your  dealer.

  The only petrol additives authorised for
use are those that meet the B715001
standard.

          Fuel  used  for  Diesel

engines

  The Diesel engines are compatible with
biofuels that conform to current and future
European standards and can be obtained from
filling stations.

 Diesel fuel that meets standard
EN590 mixed with a biofuel that meets
standard EN14214 (possibly containing
up to 7% Fatty Acid Methyl Ester).

 Paraffinic Diesel fuel that meets
standard EN15940 mixed with a biofuel
that meets standard EN14214 (possibly
containing up to 7% Fatty Acid Methyl
Ester).

 Diesel fuel that meets standard
EN16734 mixed with a biofuel that
meets standard EN14214 (possibly
containing up to 10% Fatty Acid Methyl
Ester).

  The use of B20 or B30 fuel meeting
standard EN16709 is possible in your
Diesel engine. However, this use, even
occasional, requires strict application
of the special servicing conditions
referred to as "Arduous conditions".

 Petrol that meets the EN228 standard,
mixed with a bio-fuel meeting the
EN15376  standard.

 For more information, contact a PEUGEOT
dealer or a qualified workshop.

           Diesel  fuel  at  low  temperature

In temperatures below 0°C (+32°F), the

formation of paraffins in the summer diesel

fuels may result in abnormal operation of the

fuel supply system. To avoid this, the use of

winter diesel fuels is recommended, keeping

the tank topped up to more than 50% of its

capacity.

 If in spite of this you experience difficulties

starting the engine in temperatures below -15°C

(+5°F), simply leave the vehicle in a garage or a

heated workshop for a while.

4

Technical data

508-additif_en_Chap09_caracteristiques-techniques_ed01-2016

                 Identifi cation markings

 Various visible markings for the identification of your vehicle.

A.    Vehicle Identification Number (VIN)

under the bonnet.



This number is engraved on the bodywork
near the damper mounting.

  The tyre pressures must be checked
when the tyres are cold, at least once
a month.

  Low tyre pressures increase fuel
consumption.

  The original tyres fitted to the vehicle
may have a load index or speed rating
higher than those given on the label;
this has no effect on the inflation
pressures.

B.    Vehicle identification Number (VIN) on

the windscreen lower crossmember.



This number is given on a self-adhesive label
which is visible through the windscreen.

C.    Manufacturer's label.



The VIN is marked on a self-destroying
label affixed to the centre pillar, on the left-
hand or right-hand side.

D.    Tyre/paint label.



This label is fitted to the middle pillar, on
the driver's side.

 It bears the following information:
   -   the tyre inflation pressures with and without

load,

  -   the tyre sizes,
  -   the inflation pressure of the spare wheel,
  -   the paint colour code.

.

 Audio and Telematics

5

508-additif_en_Chap10a_BTA-2_BTA-3R_ed01-2016

       Emergency  or  assistance  call

        PEUGEOT  Connect  SOS

             In  an  emergency,  press  this
button for more than 2 seconds.
 Flashing of the green indicator
lamp and a voice message
confirm that the call has been
made to the "PEUGEOT Connect
SOS" *   centre.

  Pressing this button again immediately cancels
the call.
 The green indicator lamp goes off.

  The green indicator lamp remains on (without
flashing) when communication is established.
 It goes off at the end of the call.

  PEUGEOT Connect SOS immediately locates
your vehicle, makes contact with you in your
language **  and - if necessary - organises
sending of the appropriate emergency
services ** . In countries where the service is not
operational, or if the locating service has been
expressly declined, the call is directed straight
to the emergency services (112) without
location.

  **    Depending on the geographic cover for

"PEUGEOT Connect SOS", "PEUGEOT
Connect Assistance" and the official national
language selected by the owner of the
vehicle.
The list of countries covered by PEUGEOT
CONNECT services is available at dealers or
on the website in your country.

  *    Depending on the terms and conditions for

the service, available from dealers, and
technological and technical limits.

  If an impact is detected by the airbag
control unit, and independently of
the deployment of any airbags, an
emergency  call  is  made  automatically.

      If  you  benefit  from  the  PEUGEOT
Connect Packs offer with the SOS and
assistance pack included, there are
additional services available to you in
your personal space, via the Internet
website for your country.

  Type  1















Content   ..  21  22  23  24   ..
