Peugeot 301 (2017 year). Manual - part 18

PEUGEOT Connect Nav

Telephone

QUESTION

RESPONSE

SOLUTION

I cannot connect my Bluetooth telephone.

The telephone's Bluetooth function may be
switched off or the telephone may not be visible.

Check that your telephone has Bluetooth
switched on.
Check in the telephone settings that it is "visible
to all".

The Bluetooth telephone is not compatible with
the system.

You can check the compatibility of your
telephone on the Brand's website (services).

The volume of the telephone connected in
Bluetooth mode is inaudible.

The sound depends on both the system and the
telephone.

Increase the volume of the audio system, to
maximum if required, and increase the volume
of the telephone if necessary.

Ambient noise affects the quality of the
telephone call.

Reduce the ambient noise level (close the windows,
reduce the booster fan speed, slow down, ...).

Some contacts are duplicated in the list.

The options for synchronising contacts are
synchronising the contacts on the SIM card, the
contacts on the telephone, or both. When both
synchronisations are selected, some contacts
may be duplicated.

Select "Display SIM card contacts" or "Display
telephone contacts".

The contacts are listed in alphabetical order.

Some telephones offer display options.
Depending on the settings chosen, contacts can
be transferred in a specific order.

Modify the telephone directory display settings.

The system does not receive SMS.

The Bluetooth mode does not permit sending
SMS text messages to the system.

PEUGEOT Connect Nav

Settings

QUESTION

RESPONSE

SOLUTION

When changing the setting of treble and bass,
the equalizer setting is deselected.
When changing the equalizer setting, the treble
and bass settings are reset.

The selection of an equalizer setting imposes
the settings for treble and bass and vice-versa.

Modify the treble and bass or equalizer settings
to obtain the desired musical ambience.

When changing the balance setting, distribution
is deselected.
When changing the distribution setting, the
balance setting is deselected.

The selection of a distribution setting imposes
the balance settings and vice-versa.

Modify the balance setting or the distribution
setting to obtain the desired sound quality.

There is a difference in sound quality between
the different audio sources.

To allow for optimal listening quality, the
audio settings can be tailored to different
sound sources, which can generate audible
differences when changing source.

Check that the audio settings are adapted to
the sources listened to. It is recommended
that the audio settings (Bass, Treble, Balance)
be adjusted to the middle position, select the
"None" musical ambience and set the loudness
correction to the "Active" position in CD mode or
to the "Inactive" position in radio mode.

When the engine is off, the system stops after
several minutes of use.

When the engine is switched off, the system's
operating time depends on the state of charge
of the battery.
In normal off state, the system automatically
goes into energy economy mode to maintain an
adequate charge in the battery.

Turn the ignition on to increase the charge of
the battery.

The date and time cannot be set.

Setting of the date and time is only available
if the synchronisation with the satellites is
deactivated.

Settings menu / Options / Time-Date setting.
Select the "Time" tab and deactivate the "GPS
synchronisation" (UTC).

PEUGEOT Connect Nav

PEUGEOT Connect Nav

PEUGEOT Connect Nav

PEUGEOT Connect Radio

Multimedia audio system -

Applications - Bluetooth

telephone

Contents

First steps

Steering mounted controls

Menus

Applications

Radio

DAB radio (Digital Audio Broadcasting)

Media

Telephone

Configuration

Frequently asked questions

The different functions and settings
described vary according to the version
and configuration of your vehicle.

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-free
system of your audio system must be
done with the

vehicle stationary and the

ignition on.

The system is protected in such a way that
it will only operate in your vehicle.
The display of the

Energy Economy

Mode message signals that a change to

standby is imminent.

The link below gives access to OSS (Open
Source Software) codes for the system.
https://www.groupe-psa.com/fr/oss/
https://www.groupe-psa.com/en/oss/

PEUGEOT Connect Radio

First steps

With the engine running, a press
mutes the sound.
With the ignition off, a press turns
the system on.

Adjustment of the volume.

Use the buttons either side of or below the
touch screen for access to the menus, then
press the virtual buttons in the touch screen.

Depending on the model, use the "Source" or
"Menu" buttons on the left of the touch screen
for access to the menus, then press the virtual
buttons in the touch screen.

You can display the menus at any time by
pressing the screen briefly with three fingers.

All of the touch areas of the screen are white.
Press in the grey zone to go back a level or
confirm.
Press the back arrow to go back a level or
confirm.

The touch screen is of the "capacitive"
type.
To clean the screen, use a soft, non-
abrasive cloth (spectacles cloth) with no
additional product.
Do not use sharp objects on the screen.
Do not touch the screen with wet hands.

* Depending on equipment.

Certain information is displayed permanently in
the upper band of the touch screen:
- Repeat of the air conditioning information

(depending on version), and direct access to
the corresponding menu.

- Reminder of the Radio Media and

Telephone menu information.

- Access to the Settings of the touch screen

and digital instrument panel.

Selecting the audio source (depending on
version):
- FM / DAB radio stations* / AM*.
- Telephone connected via Bluetooth and

Bluetooth multimedia broadcasting*
(streaming).

-  CD player (depending on model).
-  USB key.
-  Media player connected via the auxiliary

socket (depending on model).

In the "Settings" menu you can create
a profile for just one person or a group
of people with common features, with
the possibility of entering a multitude of
settings (radio presets, audio settings,
ambiences, ...); these settings are taken
into account automatically.

PEUGEOT Connect Radio

In very hot conditions, the volume may
be limited to protect the system. It may go
into standby (screen and sound off) for at
least 5 minutes
The return to normal takes place when
the temperature in the passenger
compartment has dropped.

Steering mounted controls

Steering mounted

controls - Type 1

Radio:

Select the previous / next preset
radio station.
Select the previous / next item in a
menu or a list.

Media:

Select the previous / next track.
Select the previous / next item in a
menu or a list.

Radio:

Short press: display the list of radio
stations.
Long press: update the list.

Media:

Short press: display the list of
folders.
Long press: display the available
sorting options.

Change audio source (radio; USB;
AUX if equipment connected; CD;
streaming).

Confirm a selection.

Increase volume.

Decrease volume.

Mute / Restore sound by
simultaneously pressing the
increase and decrease volume
buttons.

Steering mounted

controls - Type 2

Depending on model.

Voice commands:

This control is located on the
steering wheel or at the end of the
lighting control stalk (depending on
model).
Short press, smartphone voice
commands via the system.

21,5

18,5

PEUGEOT Connect Radio

Increase volume.

Mute / Restore the sound.
Or
Mute by pressing the volume
increase and decrease buttons
simultaneously.
Restore the sound by pressing one
of the two volume buttons.

Decrease volume.

Media (short press): change the

multimedia source.

Telephone (short press): start

telephone call.

Call in progress (short press):

access telephone menu.

Telephone (long press): reject an

incoming call, end call; when no call is
in progress, access telephone menu.

Radio (rotate): previous / next

preset.

Media (rotate): previous / next track,

move in a list.

Short press: confirm a selection; if

nothing selected, access to presets.

Radio: display the list of stations.

Media: display the list of tracks.

Radio (press and hold): update the

list of stations received.

Menus

Depending on model / Depending on version

Air conditioning

Manage the different temperature
and air flow settings.

PEUGEOT Connect Radio

Applications

Access configurable equipment.

Radio Media

Select an audio source or radio
station.

Telephone

Connect a telephone by Bluetooth

Operate certain applications on
a smartphone connected via
MirrorLink

, CarPlay

or Android

Auto.

Settings

Configure a personal profile and/
or configure the sound (balance,
ambience, ...) and the display
(language, units, date, time, ...).

Driving

Activate, deactivate or configure
certain vehicle functions.

PEUGEOT Connect Radio

Applications

Viewing photos

Insert a USB memory stick in the USB port.

To protect the system, do not use a USB
hub.

The system can read folders and image files in
the formats: .tiff; .gif; .jpg/jpeg; .bmp; .png.

Press

Applications to display the

primary page.

Press "Photos".

Select a folder.

Select an image to view.

Press this button to display the
details of the photo.

Press the back arrow to go back a
level.

Managing messages

Press

Applications to display the

primary page.

Press "SMS"..

Select the "SMS" tab.

Press this button to select the
display settings for messages.

Press this button to search for a
contact.

Select the "Quick messages" tab.

Navigation

Configure the guidance and select
your destination via MirrorLink

CarPlay

or Android Auto.

Press this button to select the
display settings for messages.

PEUGEOT Connect Radio

Radio

Selecting a station

Press

Radio Media to display the

primary page.

Press one of the buttons for an
automatic search for radio stations.

Move the cursor for a manual search
for frequencies up or down.

Press the frequency.

Enter the FM and AM waveband
values using the virtual keypad.

Press "

OK" to confirm.

Radio reception may be affected by the
use of electrical equipment not approved
by the Brand, such as a USB charger
connected to the 12 V socket.
The external environment (hills, buildings,
tunnels, basement car parks, ...) may
block reception, including in RDS mode.
This is a normal effect of the way in
which radio waves are transmitted and
does not indicate any failure of the audio
equipment.

Changing waveband

Press

Radio Media to display the

primary page.

Press the "

OPTIONS" button to go to the

secondary page.

Press "

Band" to change waveband.

Press in the grey zone to confirm.

Presetting a station

Select a radio station or frequency.

Make a short press on the star
outline. If the star is solid, the radio
station is already preset.

Select a radio station or frequency.

Press "

Preset".

Make a long press on one of the
buttons to preset the station.

Activating / Deactivating RDS

Press

Radio Media to display the

primary page.

Press the "

OPTIONS" button to go to the

secondary page.

Activate / Deactivate "

RDS".

Press in the grey zone to confirm.

PEUGEOT Connect Radio

The RDS, if activated, enables you to
continue listening to the same station
by automatically retuning to alternative
frequencies. However, in certain
conditions, coverage of this RDS station
may not be assured throughout the entire
country as radio stations do not cover
100% of the territory. This explains the loss
of reception of the station during a journey.

Display text information

The "Radio Text" function allows
information transmitted by the radio
station and related to the station or the
song playing to be displayed.

Press

Radio Media to display the

primary page.

Press the "

OPTIONS" button to go to the

secondary page.

Activate / Deactivate "

News".

Press in the grey zone to confirm.

Play TA messages

The TA (Traffic Announcement) function
gives priority to TA alert messages.
To operate, this function needs good
reception of a radio station that carries
this type of message. While traffic
information is being broadcast, the current
media is automatically interrupted so that
the TA message can be heard. Normal
play of the media previously playing is
resumed at the end of the message.

Press

Radio Media to display the

primary page.

Press the "

OPTIONS" button to go to the

secondary page.

Activate / Deactivate "

TA".

Press in the grey zone to confirm.

Audio settings

Press

Radio Media to display the

primary page.

Press the "

OPTIONS" button to go to the

secondary page.

Press "

Audio settings".

Select the "

Tone" or "Balance"

or "

Ringtones" or "Sound" tab to

configure the audio settings.

Press the back arrow to confirm.

On the "

Tone" the Ambience audio

settings, as well as

Bass, Medium and

Treble are different and independent for

each audio source.
On the "

Balance" tab, the All

passengers, Driver and Front only

settings are common to all sources.
On the "

Sound" tab, activate or deactivate

Volume linked to speed", "Auxiliary

input" and "Touch tones".

PEUGEOT Connect Radio

The sound distribution (or spatialisation
with the Arkamys

system) is audio

processing that allows the quality of the
sound to be adapted according to the
number of passengers in the vehicle.

Onboard audio: the Arkamys

Sound

Staging optimises the distribution of sound
in the passenger compartment.

DAB (Digital Audio

Broadcasting) radio

Terrestrial Digital Radio

Digital radio provides higher quality
reception.
The different multiplexes offer a choice
of radio stations arranged in alphabetical
order.

Press

Radio Media to display the

primary page.

Press the "

OPTIONS" button to go to the

secondary page.

Press "

Waveband" to select the

DAB band".

Press in the grey zone to confirm.

FM-DAB auto tracking

"DAB" does not cover 100% of the
territory.
When the digital radio signal is poor,
the "FM-DAB auto tracking" allows
you to continue listening to the same
station, by automatically switching to the
corresponding "FM" analogue station
(if there is one).

Press

Radio Media to display the

primary page.

Press the "

OPTIONS" button to go to the

secondary page.

Activate / Deactivate "

FM-DAB auto

tracking".

Press in the grey zone to confirm.

PEUGEOT Connect Radio

Media

USB port

Insert the USB memory stick in the USB port or
connect the USB device to the USB port using
a suitable cable (not supplied).

To protect the system, do not use a USB
hub.

The system builds playlists (in temporary
memory), an operation which can take from
a few seconds to several minutes at the first
connection.
Reduce the number of non-music files and the
number of folders to reduce the waiting time.
The playlists are updated every time the
ignition is switched off or a USB memory stick
is connected. The lists are memorised: if they
are not modified, the subsequent loading time
will be shorter.

Auxiliary socket (AUX)

(depending on model / depending on
equipment)

This source is only available if "Auxiliary input"
has been checked in the audio settings.

Connect the portable device (MP3 player…) to
the auxiliary jack socket using an audio cable
(not supplied).

First, adjust the volume on your portable device
(to a high level). Then adjust the volume of your
audio system.
Display and management of the controls are
via the portable device.

If "FM-DAB auto tracking" is activated,
there is a difference of a few seconds
when the system switches to "FM"
analogue radio with sometimes a variation
in volume.
When the digital signal quality becomes
good, the system automatically switches
back to "DAB".

If the "DAB" station being listened to is not
available on "FM", or if the "FM-DAB auto
tracking" is not activated, the sound will
cut out while the digital signal is too weak.

Content .. 16 17 18 19 ..
