B1088 PRE-TEN FRONT LH SRC-91 < COMPONENT DIAGNOSIS > C D E F G I J K L M A B SRC N O P With CONSULT-III CAUTION: • Before servicing, turn ignition switch OFF, disconnect both battery terminals and wait at least 3 min- utes. (To discharge backup capacitor.) • Do not use unspecified tester or other measuring device. DIAGNOSTIC PROCEDURE 1. CHECK HARNESS CONNECTOR Are connections of harness connectors and terminals correct? YES >> GO TO 2. NO >> Repair or replace harness connector. 2. CHECK WIRING HARNESS Is the outside of wire harness normal, without any damage? YES >> GO TO 3. NO >> Replace wiring harness. 3. CHECK SEAT BELT PRE-TENSIONER Is “SEAT BELT PRE-TENSIONER” displayed on CONSULT-III? YES >> Replace seat belt pre-tensioner. NO >> Replace diagnosis sensor unit (ACU). |
