STR-10

< COMPONENT DIAGNOSIS >

B TERMINAL CIRCUIT

COMPONENT DIAGNOSIS

B TERMINAL CIRCUIT

Description

INFOID:0000000000955268

The “B” terminal is constantly supplied with battery power.

Diagnosis Procedure

INFOID:0000000000955269

CAUTION:

Perform diagnosis under the condition that engine cannot start by the following procedure.
1.

Remove fuel pump fuse.

2.

Crank or start the engine (where possible) until the fuel pressure is released.

1.

CHECK “B” TERMINAL CIRCUIT

1.

Turn ignition switch OFF.

2.

Check that starter motor “B” terminal connection is clean and tight.

3.

Check voltage between starter motor “B” terminal and ground.

Is the inspection result normal?

YES

>> GO TO 2.

NO

>> Check harness between battery and starter motor for open circuit.

2.

CHECK BATTERY CABLE CONNECTION STATUS (VOLTAGE DROP TEST)

1.

Shift CVT selector lever to “P” or “N” position. (CVT models)

2.

Check voltage between battery positive terminal and starter motor “B” terminal.

Is the inspection result normal?

YES

>> GO TO 3.

NO

>> Check harness between the battery and the starter motor for poor continuity.

3.

CHECK GROUND CIRCUIT STATUS (VOLTAGE DROP TEST)

1.

Shift CVT selector lever to “P” or “N” position. (CVT models)

2.

Check voltage between starter motor case and battery negative terminal.

Is the inspection result normal?

YES

>> “B” terminal circuit is OK. Further inspection is necessary. Refer to

STR-4, "HR16DE/MR20DE

MODELS : Work Flow"

.

NO

>> Check the starter motor case and ground for poor continuity.

Terminals

Voltage (Approx.)

(+)

(–)

Starter motor “B” terminal

Terminal

F49 (K9K)

F52 (HR16DE)

F10 (MR20DE)

2 Ground

Battery

voltage

Terminals

Condition

Voltage (Approx.)

(+)

(–)

Starter motor

“B” terminal

Terminal

Battery positive terminal

F49 (K9K)

F52 (HR16DE)

F10 (MR20DE)

When the ignition switch is

in START position

Less than

 0.5 V

Terminals

Condition

Voltage (Approx.)

(+)

(–)

Starter motor case

Battery negative terminal

When the ignition switch is in

START position

Less than 0.2 V

S TERMINAL CIRCUIT

STR-11

< COMPONENT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

A

STR

N

P

O

S TERMINAL CIRCUIT

Description

INFOID:0000000000955270

The starter motor magnetic switch is supplied with power when the ignition switch is turned to START with the
selector lever P or N for CVT models.

Diagnosis Procedure

INFOID:0000000000955271

CAUTION:

Perform diagnosis under the condition that engine cannot start by the following procedure.
1.

Remove fuel pump fuse.

2.

Crank or start the engine (where possible) until the fuel pressure is released.

1.

CHECK “S” CONNECTOR CIRCUIT

1.

Turn ignition switch OFF.

2.

Disconnect “S” terminal.

3.

Shift CVT selector lever to “P” or “N” position. (CVT models)

4.

Check voltage between starter motor harness connector and ground.

Is the inspection result normal?

YES

>> “S” terminal circuit is OK. Further inspection is necessary. Refer to

STR-2, "K9K MODELS : Work

Flow"

 (K9K models) or

STR-4, "HR16DE/MR20DE MODELS : Work Flow"

 (HR16DE/MR20DE

models).

NO

>> GO TO 2.

2.

CHECK CONNECTOR

1.

Turn ignition switch OFF.

2.

Check the following terminals and connectors for damage, bend and loose connection.

-

Harness connector E8 (M/T models)

-

Harness connector F122 (M/T models)

-

Harness connector E6 (CVT models)

-

Harness connector F123 (CVT models)

Is the inspection result normal?

YES

>> GO TO 3.

NO

>> Repair the terminal and connector.

3.

CHECK HARNESS CONTINUITY (OPEN CIRCUIT)

1.

Disconnect IPDM E/R connector.

2.

Check continuity between starter motor “S” terminal and IPDM E/R harness connector.

Is the inspection result normal?

YES

>> Inspect IPDM E/R and power supply circuit. Refer to

SEC-5, "Work Flow"

.

NO

>> Repair the harness.

Terminals

Condition

Voltage (Approx.)

(+)

(–)

Starter motor har-

ness connector

Terminal

F50 (K9K)

F53 (HR16DE)
F11 (MR20DE)

1 Ground

When the ignition switch is in

START position

Battery voltage

Starter motor “S” terminal

IPDM E/R harness connector

Continuity

Connector No.

Terminal No.

Connector No.

Terminal No.

F50 (K9K)

F53 (HR16DE)
F11 (MR20DE)

1

E14

50

Existed

STR-12

< COMPONENT DIAGNOSIS >

STARTING SYSTEM

STARTING SYSTEM

Wiring Diagram - STARTING SYSTEM (M/T MODELS) -

INFOID:0000000001059516

JCBWA0212GB

STARTING SYSTEM

STR-13

< COMPONENT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

A

STR

N

P

O

JCBWA0213GB
