BCM (BODY CONTROL MODULE) PWC-41 < ECU DIAGNOSIS > C D E F G H I J L M A B PWC N O P 31 (BR) Ground Combination switch Input Combination All switch OFF 1.3 V Front fog lamp switch ON 1.3 V Rear fog lamp switch ON 1.3 V Rear wiper switch ON 1.3 V Any of the condition below 1.3 V Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + − JPMIA0165GB JPMIA0167GB JPMIA0168GB JPMIA0169GB JPMIA0196GB |
